Trynex SnowEx Vee Pro 3000 Owner's/Operator's Manual

Spreaders for snow & ice control

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

This Manual Must Be Read Before Operating The Equipment

Owner / Operator's Manual

Warren, Michigan 48089

800-725-8377

L1102

Spreaders for Snow & Ice Control

Vee Pro 3000

Vee Pro 6000

Vee Pro 8000

Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915

and other pending U.S. and foreign patent applications.

FOR MODELS

CUSTOMER COPY

5 — 1

Table of Contents

Need help?

Do you have a question about the SnowEx Vee Pro 3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trynex SnowEx Vee Pro 3000

Page 1 FOR MODELS Vee Pro 3000 Vee Pro 6000 Vee Pro 8000 CUSTOMER COPY Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915 Warren, Michigan 48089 and other pending U.S. and foreign patent applications. 800-725-8377 © Trynex International 2007 L1102 5 — 1...
Page 2: Table Of Contents
One Kit Services All: • Vee Pro 8000 • Vee Pro 6000 • Vee Pro 3000 • Sand Pro 1875 • Pivot Pro 1075 • Mini Pro 575 • Micro Pro 375 L1102 © Trynex International 2007 5 — 2...
Page 3: Introduction
(ORANGE) Information that, if not carefully followed, can cause serious personal injury or death! (YELLOW) Information that, if not carefully followed, can cause minor injury or damage to equipment. © Trynex International 2007 L1102 5 — 3...
Page 4: General Information And Registration
The spreader you have purchased is an example of snow and ice control technology at its finest! Your spreader’s innovative, self-contained design is a trademark of all Trynex products. Here’s why... SIMPLICITY: Fewer moving parts manufactured of higher quality means minimal maintenance for your SnowEx spreader.
Page 5: Safety Information
For your safety warning and information decals have been placed on this product to remind the operator of safety precautions. If anything happens to mark or destroy the decals, please request new ones from Trynex, International. Unit must be strapped down and locked into position before operating vehicle.
Page 6 Always wear safety glasses with side shields when servicing spreader. Failure to do this could result in serious injury to the eyes. CHMSL light (where applicable) must be installed and plugged in to meet DOT FMVSS-108 standards. L1102 © Trynex International 2007 5 — 6...
Page 8: Spreader Assembly And Exploded Views
Vee Pro 3000 Side and Bottom View L1102 © Trynex International 2007 5 — 8...
Page 11 D 6524 5/16" - 18 x 1-1/2" Tap Bolt D 6138 5/16" Lock Nut D 6155 5/16" Lock Washer D 6736 3000 Mounting Bracket - Right D 6737 3000 Mounting Bracket - Left © Trynex International 2007 L1102 5 — 11...
Page 13 Plastic Filler Plug D 6471 Main Baffle D 6472 Second Baffle D 6473 Third Baffle D 6137 5/16"-18 x 1-1/4" SS Pan Head D 6155 5/16" Split Lock Washer D 6168 5/16"-18 Hex Nut © Trynex International 2007 L1102 5 — 13...
Page 15 D 6537 Adj. Stop Bracket LT D 6509 Top Screen Hold Down D 6553 Top Screen Hold Down Screw D 6529 #10 Black Oxide Screw D 4121 3/8"-16 x 1" Hex Bolt © Trynex International 2007 L1102 5 — 15...
Page 17 D 6555 8000 Right Frame Weldment D 6556 8000 Left Frame Weldment D 6553 Top Screen Hold Down Screw D 6529 #10 Black Oxide Screw D 4121 3/8"-16 x 1" Hex Bolt © Trynex International 2007 L1102 5 — 17...
Page 19 Drive Enclosure Shroud D 6541 Spinner Drive Enclosure D 6543 Tubular Spinner Guard D 6563 D 4135 Hair Pin Clip D 6452 3/8"-16 x 1" Serrated HWH Type F D 6165 5/16" Flat Washer © Trynex International 2007 L1102 5 — 19...
Page 20: Wiring Instructions
It is not recommended to attach to fuel or brake lines for obvious reasons. Do not route close to exhaust system or engine, even though Trynex uses high temperature wiring, it still could melt under extreme heat and short the spreader electrical system, as well as the vehicle electrical system.
Page 21: Electrical System Information
Electrical System Complete Assembly View © Trynex International 2007 L1102 5 — 21...
Page 22 Control Power Cable D 6527 Controller D 6511 Power Cord - 54" D 6513 CHMSL Harness D 6514 CHMSL Brake Light (for 6000/8000 only) 1 D 6515 Heavy Duty Vibrator D 6118 Dust Cap L1102 © Trynex International 2007 5 — 22...
Page 23 Vee Pro 6000/8000 Electrical Routing CHMSL Spinner Main Input Auger and Vibrator (not supplied on drawing) © Trynex International 2007 L1102 5 — 23...
Page 24 White with Red Tracer (+) to battery Ring Terminal Connect to control * NOTE: mating half A) Leads must only be attached to battery. B) If fusing, must use minimum 60 Amp Maxi type fuse. L1102 © Trynex International 2007 5 — 24...
Page 25 AUGER POWER SPREADER CONNECTION White Positive (+) White Positive (+) Black Negative (–) Black Negative (–) VIBRATOR SPINNER POWER PLUG POWER PLUG * NOTE: Plug has polarity reversed for proper motor rotation © Trynex International 2007 L1102 5 — 25...
Page 26 Red Positive (+) AUGER White Wire SPINNER OUTPUT SPINNER Red Positive (+) (housing) Black Negative (–) Black Negative (–) AUGER Black Wire Green Negative (–) * NOTE: Reference Bumper Plug for Color Code L1102 © Trynex International 2007 5 — 26...
Page 27 Butt Connectors D 6513 CHMSL Vehicle Harness D 6523 Scotch Locks D 6560 Hex Head Screw White Positive (+) D 6561 Cable Mounts Black Ground (–) Splice into vehicle harness stop lamp/CHMSL circuit. © Trynex International 2007 L1102 5 — 27...
Page 28: Spreader Mounting And Assembly Views
Step 9: Connect the spreader power cord to vehicle main power plug mounted at rear of vehicle (see Electrical Installation). Step 10: Connect Center High Mount Stop Lamp (CHMSL) cord from the spreader to mating half attached to vehicle (see Electrical Installation). L1102 © Trynex International 2007 5 — 28...
Page 29 Ratchet Strap D 6536 Adj. Stop Bracket RT D 6537 Adj. Stop Bracket LT D 6499 Vee Pro 3000 Tarp D 6510 Vee Pro 6000 Tarp D 6551 Vee Pro 8000 Tarp © Trynex International 2007 L1102 5 — 29...
Page 30: Vee Pro Express Kit
5/16-18 x 1-14 Hex Bolt 006138 5/16-18 Lock Nut 006568 Wheel Foot Holder 006569 Wheel Arm 006725 Fixed Wheel 006587 3/8-16 x 2-1/2" HHCS Bolt 004124 3/8-16 Nylon Insert NE Locknut 006725 Accessory Shim L1102 © Trynex International 2007 5 — 30...
Page 31 Step 8: When everything is stable, release wheel locks and slowly move spreader to storage location. Lock wheels when final place has been established. Step 9: See photo and drawing illustrations for assembly and installation. Note: Ratchet straps must still be used as part of the mounting system. © Trynex International 2007 L1102 5 — 31...
Page 32 Step 6: Mount vibrator with cord pointing down using supplied hardware. Please note: there are SPECIAL DOMED WASHERS that must be positioned properly. Please refer to standard vibrator instructions for details regarding harness installation, etc. 6-1/2” OPTI-FLOW VIBRATOR CORD FACING DOWN L1102 © Trynex International 2007 5 — 32...
Page 33: Vibrator Kit
Step 6: Locate vibrator approx. 6" to 8" from the top of throat entry and drill four 3/8" holes in rear hopper face. Bolt the vibrator in place using special washers with domed side against hopper. IMPORTANT: It is imperative that SPECIAL DOMED WASHERS are used. Use of any other washer could cause hopper to tear. © Trynex International 2007 L1102 5 — 33...
Page 34: Adjustable Baffle Kit
5/16"-18 x 1-1/4" SS Pan Head D 6155 5/16" Split Lock Washer D 6168 5/16"-18 Hex Nut NOTE: For Vee Pro 3000 Model Only. Will Not Fit Vee Pro 6000 or Vee Pro 8000 Models. L1102 © Trynex International 2007 5 — 34...
Page 35: Spreader Operating Information
• Speed of auger and spinner may be adjusted separately to get desired flow and spread distance from spreader. • The Vibrator Switch is needed for dense material or to increase the flow to the auger. This eliminates bridging of material in hopper. © Trynex International 2007 L1102 5 — 35...
Page 36 • You may repeat Steps 1 & 2 for a second and third time. • If after the third try the controller displays “OL” — you must extract the material that is causing the problem. • Follow all warning directions when clearing jams. L1102 © Trynex International 2007 5 — 36...
Page 37: Troubleshooting Information
Motor is not getting power. Turn off. Check all connections. display shows EO. Audible alarm beeping Vehicle battery is extremely low, Turn off. Charge battery. display shows LB. or a poor connection exists. © Trynex International 2007 L1102 5 — 37...
Page 38 ON/OFF SWITCH WILL TO CONTROLLER CHECK WITH TEST KIT NOT LIGHT UP SNOWEX DIAGNOSTIC TEST KIT (STK-020) IS AVAILABLE TO ACCURATELY DIAGNOSE ANY ISSUES WITH SNOWEX SPREADERS. CALL YOUR DEALER FOR DETAILS. L1102 © Trynex International 2007 5 — 38...
Page 39 50/50 salt/sand mix with Optimum Flow Kit. NOTE: Optional Optimum Flow Kit Available, To Increase Material Flow SNOWEX DIAGNOSTIC TEST KIT (STK-020) IS AVAILABLE TO ACCURATELY DIAGNOSE ANY ISSUES WITH SNOWEX SPREADERS. CALL YOUR DEALER FOR DETAILS. © Trynex International 2007 L1102 5 — 39...
Page 40: Spreader Maintenance
If motor cover is removed for any reason, use silicone sealant to ensure weather proofing of enclosure. • Grease bearings after every 20 hours use. • After first use, tighten all nuts and bolts on spreader and mount. • WARNING: Never remove spreader with material in hopper. L1102 © Trynex International 2007 5 — 40...
Page 41: Determine Vehicle Payload Chart
3/4-10 7/8-9 Metric Grade 8.8 (ft.-lb.) SIZE TORQUE SIZE TORQUE M 12 M 14 M 10 M 16 These torque values apply to mount assembly fasteners except those noted in the instruction. © Trynex International 2007 L1102 5 — 41...
Page 42: Warranty
Neither Trynex, nor any company affiliated with it, makes any warranties, representations for promise as to the performance or quality other that what is herein contained. The liability of Trynex to the purchaser for damages arising out of the manufacture, sale, delivery, use or resale of this spreader shall be limited to and shall not exceed the costs of repair or replacement of defective parts.
Page 43 Does your Trynex Dealer stock Trynex replacement Parts? ❏ Yes ❏ No ❏ I don’t know Do you feel your Trynex Dealer sold you the correct product for your needs/application? ❏ Yes ❏ No 10) How would you rate ❏...
Page 44 Warm Up to with a F R E E F R E E Winter Hat! Simply Fill Out Your Warranty Registration and Return It to the Factory! From: Postage Required Post Office will not deliver without proper postage. 23455 REGENCY PARK DR. WARREN MI 48089-2667...
