Summary of Contents for Broyhill Legacy SVS50UM
- Page 1 ASSEMBLY INSTRUCTION ITEM#: SVS50UM SKU#: 810487342 T H O R N W O O D 5 P C S E T 1 (877) 539 – 7436 Need help? We are here for you! • Toll Free service.cci@polywares.com • Email Address...
-
Page 2: Maintenance
GENERAL BEST PRACTICES FOR ASSEMBLY: Read all instructions before starting Clear a at covered space to begin assembly Always best to do it with a friend Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its letter in the package Helpful hints provided along the way Retain these assembly instructions for future reference. -
Page 3: Parts List
KVS966M PARTS LIST PART PART MATERIAL CODE PART Q’TY MATERIAL CODE PART Q’TY KVS966M-CS03-1 17C33A0710001YX BOLT M6*30 BACK ASSEMBLY KVS966M-CS02-1 17C33A0716001YX SEAT ASSEMBLY BOLT M6*45 KVS966M-CS01-1 17C01A0845011YX LEFT ARM BOLT M8*100 KVS966N-CS04-1 17FA05040301-YX WASHER d6.5*D13*1.0 62KVS966MQ101 17D03A030301-YX SUPPORT JAM NUT M6*1.0 18090102101 18000221050 PROTECT COVER... - Page 4 STEP 1 PARTS REQUIRED: 1, 3, 7, & 14 STEP 2 PARTS REQUIRED: 1, 3, 9, & 12 Keep the bolts loose. PAGE 3 OF 12 E-320...
- Page 5 STEP 3 PARTS REQUIRED: 1, 2, 10, 12, & 13 Keep the bolts loose. STEP 4 PARTS REQUIRED: 1, 2, 9, & 12 Keep the bolts loose. PAGE 4 OF 12 E-320...
- Page 6 STEP 5 PARTS REQUIRED: 1, 2, 3, 6, & 11 Keep the bolts loose. STEP 6 PARTS REQUIRED: 2, 3, 8, & 12 Keep the bolts loose. PAGE 5 OF 12 E-320...
- Page 7 STEP 7 PARTS REQUIRED: 1, 2, 4, 5, 8, & 12 Tighten all bolts by using the supplied Hex key. STEP 8 PARTS REQUIRED: 15 & 16 PAGE 6 OF 12 E-320...
- Page 8 KVS966N PARTS LIST PART PART MATERIAL CODE PART Q’TY MATERIAL CODE PART Q’TY KVS966N-CS11-2 17FA05040301-YX WASHER d6.5*D13*1.0 CHAIR ASSEMBLY 61K966NX00001BA KVS966N-CS04-1 LEFT BACK CUSHION 61K966NX50001BA 18000221050 LEG CAP RIGHT BACK CUSHION 17C33A0706001YX 61K966NX60001BA BACK CUSHION BOLT M6*15 17C01A0845011YX 61K966NY00001BA BOLT M8*100 SEAT CUSHION STEP 1 PARTS REQUIRED: 1, 2, 3, 4, 5, &...
- Page 9 STEP 2 PARTS REQUIRED: 7, 8, 9, & 10 PAGE 8 OF 12 E-320...
- Page 10 TVS59LM PARTS LIST PART MATERIAL CODE PART Q’TY 18000221050 PLASTIC LEG CAP TVS59LM-CS05-1 17C33A0706001YX TABLE TOP BOLT M6*15 TVS59LM-CS04-1 17C01A0845011YX LEG A BOLT M8*100 TVS59LM-CS04-1 17FA05040301-YX LEG B WASHER d6.5*D13*1.0 Tools Ⅴ STEP 1 PARTS REQUIRED: 2, 3, 4, & 6 Tighten all bolts by using the supplied Hex key.
- Page 11 STEP 2 PARTS REQUIRED: 1 ,2, 3, 5 & 7 Tighten all bolts by using the supplied Hex key. STEP 3 PAGE 10 OF 12 E-320...
- Page 12 XVM0182 PARTS LIST PART PART MATERIAL CODE PART Q’TY MATERIAL CODE PART Q’TY XVM0182-CS04-H 18000221050 SEAT ASSEMBLY PLASTIC LEG CAP 17C01A0845011YX 61X0182C00001BA BOLT M8*100 CUSHION STEP 1 PARTS REQUIRED: 1, 2, & 3 Tighten all bolts by using the supplied Hex key. PAGE 11 OF 12 E-320...
- Page 13 STEP 2 PARTS REQUIRED: 4 Warranty • One–year limited warranty. • Proof of purchase (dated register receipt) is required for warranty claims. • It remains the customer’s responsibility for freight and packing charges to and from the service center. Securing Clips Please use the clips to connect and secure each section together.
