- Page 1 ASSEMBLY INSTRUCTION ITEM#: SVS30US SKU#: 810499292 T H O R N W O O D S W I V E L G L I D E R 1 (877) 539 – 7436 Need help? We are here for you! • Toll Free service.cci@polywares.com •...
- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY: Read all instructions before starting Clear a flat covered space to begin assembly Always best to do it with a friend Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its letter in the package Helpful hints provided along the way Retain these assembly instructions for future reference.
- Page 3 RVS9536 PARTS LIST PART MATERIAL CODE PART Q’TY 17C33A0706001YX BOLT M6*15 17C33A0714001YX RVS9536-CS03-1 BACK ASSEMBLY BOLT M6*40 RVS9536-CS02-1 17FA05040301-YX SEAT ASSEMBLY WASHER d6.5*D13*1.0 RVS9536-CS01-2 61R9536X00001BA LEFT ARM BACK CUSHION RVS9536-CS01-3 61R9536Y00001BA RIGHT ARM SEAT CUSHION Tools Ⅱ Ⅰ STEP 1 PARTS REQUIRED: 1, 2, 6, &...
- Page 4 STEP 2 PARTS REQUIRED: 2, 3, 4, 5, & 7 Keep the bolts loose. Note: The labels marked “L” and “R” on arms (#3 and #4) should coincide with Figure 2 to ensure proper assembly. STEP 3 PARTS REQUIRED: 1, 3, 4, 5, & 7 Tighten all bolts by using the supplied Hex key.
- Page 5 STEP 4 PARTS REQUIRED: 8 & 9 PAGE 4 OF 6 E-320...
- Page 6 TMS20LQ PARTS LIST PART MATERIAL CODE PART Q’TY 62TMS20LQY101 SUPPORT 17C33A0706001YX TMS20LQ-CS05-1 BOLT M6*15 TABLE TOP 17FA05040301-YX TMS20LQ-CS04-1 WASHER d6.5*D13*1.0 STEP 1 PARTS REQUIRED: 1, 2, 4, & 5 Keep the bolts loose. PAGE 5 OF 6...
- Page 7 STEP 2 PARTS REQUIRED: 2, 3, 4, & 5 Tighten all bolts by using the supplied Hex key. STEP 3 Warranty • One–year limited warranty. • Proof of purchase (dated register receipt) is required for warranty claims. • It remains the customer’ s responsibility for freight and packing charges to and from the service center. PAGE 6 OF 6...
