Related Manuals for VIGO VG08007
Summary of Contents for VIGO VG08007
- Page 1 MODEL VG08007 CONTENT PACKING LIST / TOOLS NEEDED PANEL DIMENSIONS FITTINGS / TECHNICAL DATA WALL/CORNER INSTALLATION CARE AND TROUBLE SHOOTING WARRANTY...
- Page 2 TOOLS (NOT INCLUDED) NOTE: INSTALLATION MUST BE DONE BY A FREE FROM ACETIC ACID QUALIFIED, LICENSED PLUMBER. SILICONE PRESSURE GAUGE TO ASSURE PROPER PRESSURE ( MAX 60 PSI) MODEL VG08007...
-
Page 3: Panel Dimensions
10" CORNER INSTALLATION (TOP VIEW) NOTE: Dimension may vary up to 3/8". It is highly recommended to pull all dimensions off actual model for installation and measuring purposes. MODEL VG08007 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"... -
Page 4: Front View
SIDE VIEW FROM CENTER POINT TECHNICAL DATA MIN. FLOW PRESSURE 30 PSI MAX OPERATING PRESSURE 60 PSI OVERALL WATER PRESSURE IS 2.5 GALLONS PER MINUTE AT 60 PSI MODEL VG08007 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"... -
Page 5: Wall Installation
WALL INSTALLATION 88006 88074 MODEL VG08007... - Page 6 Please disconnect the hoses, reattach them to the correct supplies and test the unit before calling the Vigo Technical Service center. MODEL VG08007...
-
Page 7: Corner Installation
CORNER INSTALLATION 88074 88007D 88006 88074 Place the larger of the two corner brackets on the top portion of the wall and the smaller of the two brackets near the bottom of the wall. 88007D 88074 MODEL VG08007... - Page 8 84044 84001 84038 84029 84000 88009 84028 84001 84044 MODEL VG08007...
-
Page 9: Troubleshooting
*** Vigo is not responsible for pressure related issues stemming from the home's water supply. The customer should read, understand and/or ask a certified plumber prior to installation. If these steps are not taken the product may not work at optimum efficiency. - Page 10 VIGO warrants the mechanical components of the Product to be free from defects in workmanship and materials under normal use and service for a period of two (2) years from the initial date of purchase by the owner or end-user, contractor, or builder, from VIGO or an authorized VIGO dealer.
