- Page 1 MODEL VG08005 CONTENT PACKING LIST / TOOLS NEEDED PANEL DIMENSIONS FITTINGS / TECHNICAL DATA WALL/CORNER INSTALLATION CARE AND TROUBLE SHOOTING WARRANTY...
-
Page 2: Packing List
84000 88008 - HAND SHOWER HOLDER 88018 - BODY JETS 88038 84001 88060 88092 84044 88074 TOOLS (NOT INCLUDED) PRESSURE GAUGE TO ASSURE PROPER PRESSURE ( MAX 60 PSI) RECOMMENDED - SHUT OFF VALVES FOR HOT AND COLD MODEL VG08005... -
Page 3: Panel Dimensions
PANEL DIMENSIONS 6 3/8" 16 1/2" NOTE: Dimension may vary up to 3/8". It is highly recommended to pull all dimensions off actual model for installation and measuring purposes. MODEL VG08005 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"... -
Page 4: Technical Data
SHOWER HOSE - 88004 TECHNICAL DATA MIN.FLOW PRESSURE 30 PSI MAX OPERATING PRESSURE 60 PSI FRONT VIEW OVERALL WATER PRESSURE IS 2.5 GALLONS PER MINUTE AT 60 PSI MODEL VG08005 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"... -
Page 5: Wall Installation
WALL INSTALLATION 88006 88074 MODEL VG08005... - Page 6 Please disconnect the hoses, reattach them to the correct supplies and test the unit before calling the Vigo Technical Service center. MODEL VG08005...
-
Page 7: Corner Installation
CORNER INSTALLATION 88074 88007C 88006 88074 88007C 88074 MODEL VG08005... -
Page 8: Troubleshooting
*** Vigo is not responsible for pressure related issues stemming from the home's water supply. The customer should read, understand and/or ask a certified plumber prior to installation. If these steps are not taken the product may not work at optimum efficiency. - Page 9 VIGO warrants the mechanical components of the Product to be free from defects in workmanship and materials under normal use and service for a period of two (2) years from the initial date of purchase by the owner or end-user, contractor, or builder, from VIGO or an authorized VIGO dealer.
