Cabletron Systems BRIM-T6 User Manual

Cabletron systems snmp-manageable daughterboard user's guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BRIM-T6
USER'S GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Cabletron Systems BRIM-T6

Summary of Contents for Cabletron Systems BRIM-T6

  • Page 1 BRIM-T6 USER’S GUIDE...
  • Page 3 NOTICE Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice.

  • Page 4: Fcc Notice

    NOTICE FCC NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 PROGRAM LICENSE AGREEMENT IMPORTANT: Before utilizing this product, carefully read this License Agreement. This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (the “Program”) contained in this package.
  • Page 6 52.227-7013 (c) (1) (ii) and its successors, and use, duplication, disclosure by the Government is subject to restrictions as set forth in subparagraph (c) (1) (ii) of the Rights in Technical Data and Computer Software clause at 252.227-7013. Cabletron Systems, Inc., 35 Industrial Way, Rochester, New Hampshire 03867...

  • Page 7: Table Of Contents

    UNPACKING THE BRIM-T6......2-1 INSTALLING THE BRIM-T6 ......2-1 2.2.1 Installing the BRIM-T6 into a MIM .
  • Page 8 CONTENTS APPENDIX B MEDIA SPECIFICATIONS AND REQUIREMENTS B.1 FIBER OPTIC ........B-1 B.2 SHIELDED TWISTED PAIR (STP) .

  • Page 9: Chapter 1 Introduction

    If you are unfamiliar with Cabletron Systems’ networking products, please read this manual completely to gain an understanding of the features and capabilities of the BRIM-T6. Also, you should have a general knowledge of Token Ring (IEEE 802.5) data communications networks and their physical layer components before operating the BRIM-T6.

  • Page 10: Introducing The Brim-T6

    Media Flexibility Used in conjunction with Cabletron Systems’ series of hot swappable TPIMs, the BRIM-T6 can be configured for connection to all standard network media. See Section 2.4 for instructions on how to configure and install TPIMs. Table 1-1 lists TPIMs and their corresponding media and connector types.
  • Page 11 The BRIM-T6 operates in compliance with the functional specifications of the 802.1d STA, which is included in the firmware of the host device in which the BRIM-T6 is installed. The STA is used to manage primary and backup bridges and to maintain the reliability of the multi-bridged internetwork by detecting and preventing potential data loops.

  • Page 12: Brim Specifications

    1 through 4, and IEC 801-4 (EFT/B) levels 1 through 4. NOTE: It is the network system vendor’s responsibility to ensure that the total network system, including the BRIM-T6, meets allowed limits of conducted and radiated emissions. 1.4 RELATED DOCUMENTATION The following documents provide supplementary information related to the procedures and technical data in this manual.

  • Page 13: Getting Help

    Local Area Networks, Token Ring Access Method, IEEE Standard 802.5 (1989) 1.5 GETTING HELP If you need help using the BRIM-T6 or have any questions, comments, or suggestions concerning this manual, please contact Cabletron Systems Technical Support Department: By telephone: ®...
  • Page 14 INTRODUCTION...

  • Page 15: Chapter 2 Installation

    1. Carefully remove the BRIM-T6 from the shipping box and leave it in its non-conductive bag until ready for inspection and installation. 2. Attach the wrist strap provided with the BRIM-T6 to your wrist and to a proper ground. 3. Inspect the BRIM-T6 after removing it from the bag. If there is any damage, notify Cabletron Systems Technical Support Department (see Section 1.5).

  • Page 16: Installing The Brim-T6 Into A Mim

    INSTALLATION 2.2.1 Installing the BRIM-T6 into a MIM To install the BRIM-T6 into a Media Interface Module (MIM), refer to Figure 2-1 and Figure 2-2 and follow these steps: 1. Disconnect all cables from the MIM as necessary. Note all prior cable-to-port connections to ensure proper reconnection.
  • Page 17 Connector pins under BRIM Connector Figure 2-2. Installing the BRIM-T6 5. Insert the connector pins on the underside of the BRIM into the motherboard connector on the MIM by pressing down firmly on the rear section of the BRIM until the pins slide all the way into the connector holes.

  • Page 18: Installing The Brim-T6 Into A Standalone Device

    6. Reinstall the device chassis cover and then power on the device. 2.3 CONFIGURING THE BRIM-T6 RING SPEED You must configure the BRIM-T6 ring speed to match the ring speed of the Token Ring to which it is physically linked. The BRIM-T6 ring speed setting does not, however, have to match the ring speed setting of its host device.
  • Page 19 4 Mbps. To configure the ring speed, refer to the settings illustrated in Figure 2-3 and follow these steps: 1. Remove the MIM from the MMAC; if the BRIM-T6 is installed in a standalone device, remove the chassis cover from the device to provide access to the BRIM-T6’s component board surface.

  • Page 20: Configuring And Installing Tpims

    Refer to the TPIM-F2/TPIM-F3 part number location shown in Figure 2-4 to determine functional compatibility with the BRIM-T6. To configure TPIMs for use with the BRIM-T6, refer to Figure 2-4 and follow these steps: 1. Move the RI/RO and Station switch on the TPIMs to the Station (S or STN) position using a blunt, narrow-tipped instrument such as a screwdriver or similar instrument.
  • Page 21 NOTE: If the switch locations on a TPIM do not match the example locations illustrated in Figure 2-4, refer to the TPIM Reference Card included with the TPIM. The TPIM Reference Card outlines switch locations and settings. For additional help, call Cabletron Systems Technical Support Department (see Section 1.5). Top View...

  • Page 22: Installing Tpims

    INSTALLATION 2.4.2 Installing TPIMs To install a TPIM into the BRIM-T6, refer to Figure 2-5 and follow these steps: 1. Slide the TPIM into the TPIM slots until the connector pins in the BRIM are fully inserted into the connector on the TPIM.

  • Page 23: Chapter 3 Connecting To The Network

    • Unshielded Twisted Pair (UTP) • Fiber Optic NOTE: Remember that the BRIM-T6 is designed and configured for connection to network concentrator Station ports only. 3.1 CONNECTING STP SEGMENTS Both the TPIM-T1 and the TPIM-T4 support connection to STP cable segments.

  • Page 24: Connecting Utp Segments

    CONNECTING TO THE NETWORK 3.2 CONNECTING UTP SEGMENTS The TPIM-T2 provides an RJ45 interface for connecting UTP cable segments (see Appendix A for pinouts). To connect a UTP segment to a TPIM-T2, insert the RJ45 connector into the RJ45 port as shown in Figure 3-2. Figure 3-2.
  • Page 25 TX port and attach the other end of the strand connected to host TX port to the destination device’s RX port. The next chapter describes how to use LANVIEW LEDs to monitor the operation of the BRIM-T6 and troubleshooting procedures. CONNECTING TO THE NETWORK RX Port...
  • Page 26 CONNECTING TO THE NETWORK...

  • Page 27: Chapter 4 Monitoring And Troubleshooting

    LANVIEW LEDs are Cabletron Systems’ built-in, visual diagnostic and status monitoring system. The comprehensive LANVIEW system for the BRIM-T6 consists of four LEDs (Light Emitting Diodes) on the face of the BRIM-T6 and one LED on the face of its attached TPIM (Figure 4-1).
  • Page 28 LNK (Media Link OK) on attached TPIM When solid Green, LNK indicates that a connection exists between the BRIM-T6 and a node at the other end of the media segment. When off, (or also when Red on the TPIM-T1/-T2/-T4) this LED indicates either that the BRIM-T6 is not connected to another device or that the port is not receiving a signal.

  • Page 29: Checking The Connection

    The LNK LED on the TPIM lights green when there is an established link between the BRIM-T6 and the device at the other end of the media connection. If, however, the LNK LED lights red or is not lighted, a link has not been established.
  • Page 30 Check that the connection meets the dB loss limit and media specifications outlined in Appendix B. • Check that the BRIM-T6 port is enabled through Local Management. Contact Cabletron Systems Technical Support if you still cannot establish a network link.

  • Page 31: Twisted Pair Tpim Pinouts: Station Mode

    TPIM SPECIFICATIONS A.1 TWISTED PAIR TPIM PINOUTS: STATION MODE Figure A-1 illustrates pinouts for TPIMs that support twisted pair cable (STP and UTP) and that are also configured to support Station applications. TPIM-T1 1 Receive + 2 Ground 3 +5V at 250mA 4 Ground 5 Transmit - 6 Receive -...
  • Page 32 TPIM SPECIFICATIONS Table A-1. TPIM-F2 Performance Specifications Typical Parameter Value Receive -30.5 dBm Sensitivity Peak Input -7.6 dBm Power Transmitter Power: 50/125 m -13.0 dBm 62.5/125 m -10.0 dBm 100/140 m -7.0 dBm Bit Error Rate: Better than 10 The transmitter power and receive sensitivity levels given in Table A-1 and Table A-2 are Peak Power Levels after optical overshoot.

  • Page 33: B.1 Fiber Optic

    MEDIA SPECIFICATIONS AND REQUIREMENTS This Appendix provides information about cabling media (Fiber, STP, UTP) used with the BRIM-T6. B.1 FIBER OPTIC Table B-1 defines total signal attenuation tolerances for both single-mode and multimode fiber cabling. Both types of cabling have a typical constant attenuation rate per km of fiber cable, and each connector on the cable...

  • Page 34: B.2 Shielded Twisted Pair (Stp)

    MEDIA SPECIFICATIONS AND REQUIREMENTS B.2 SHIELDED TWISTED PAIR (STP) STP cable categories are listed as follows: • IBM Type 1 consists of two STP lengths of 22 AWG solid wire for data. There are three versions of Type 1: Indoor, Outdoor, and Plenum. It is typically used for the longest cable runs within the walls of buildings.

  • Page 35: B.3 Unshielded Twisted Pair (Utp)

    Maximum Lobe Length Lobe length is the physical length of the cable connecting a station to its TCU port. Table B-3 shows maximum lobe length according to ring speed. The length figures are for total lengths of STP cable only. Maximum Trunk Lengths The maximum trunk cable length between active devices is equal to the maximum drive distance.
  • Page 36 MEDIA SPECIFICATIONS AND REQUIREMENTS UTP consists of four pairs of 24 AWG solid wire for data or voice communication and is typically used to wire cable runs within the walls of buildings. In some installations, existing UTP building wiring can be used for Token Ring cabling.
  • Page 37 Maximum Lobe Lengths The lobe length is the physical length of the cable connecting a station to its TCU port. Table B-5 shows maximum lobe length according to ring speed. Length figures are for total lengths of UTP cable only. Table B-5.
  • Page 38 MEDIA SPECIFICATIONS AND REQUIREMENTS...
