Measurements

CAUTION HOT SURFACE! If measuring current, first make sure
that the equipment (shunt resistor, wires, connectors, and so on)
can support the amperage and power dissipation. Secondly, make
sure that the current flowing through J1 does not exceed 10 A.
Failure to do so can result in hot surfaces (> 55°C), damage to the
EVM, or personal injury.
The shunt resistor will become hot during use. Ensure proper
precautions are taken to prevent contact with R1 during operation.
Failure to do so can result in personal injury.
