- Page 1 AVA-154UX6SSH-400 ALL FRESH AVA-190UX6STH-500 AIR TYPE AVA-190UX6STH-600 P00429Q ORIGINAL INSTRUCTIONS...
- Page 2 The indoor unit has been designed for the following temperatures. Running: -7~43 Cooling Operation: 21~43 Heating Operation: -7~15 The indoor unit will stop when the temperature outside is lower than -7 The indoor unit can be only used with the outdoor unit as follows. Indoor Unit Model Outdoor Unit...
-
Page 3: Important Notice
To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. Hisense's Hisense's... - Page 5 Do not perform installation work,refrigerant Do not install the indoor unit,outdoor piping work,drain piping and electrical wiring unit,remote control switch and cable connection without referring to the installation within approximately 3 meters from manual. strong electromagnetic wave radiatoes such as medical equipment. Check that the ground wire is securely Do not touch the exchanger to avoid connected.
- Page 6 R410A...
- Page 8 (In c l u d i n g Tw o R e m o t e Te m p e r a t u r e S e n s o r s )
- Page 9 unit:mm Working Keep enough distance between the indoor unit and Space the walls around to avoid contacting each other 800 or more Air Inlet Piping Surface of the ceiling Vent-pipe Air Passage Air Strainer (Field Supply) Electrical Box Support Board (Field Supply) Service Access Panel (600)
- Page 10 unit:mm Air Inlet 1520 1520 160× 9=1440 Ø17 Ceiling Anchor Bolt Long Nut or Thread Take-up 200× 4=800 Suspension Bolts 1950 2090 Indoor Unit Air Outlet Fig4.3 Sling Bolts MODEL...
- Page 11 4.3.3 Hanging Indoor Unit Setscrew (M12) (Field Supply) Nut (Field Supply) Support Board Polyethylene Pipe (Field Supply) Polyethylene Pipe Drain Pipe Sleeve Washer (Field Supply) Nut× 2 (Field Supply) Sling Bolt Bolt: M12 Drain Pipe Sleeve Fig4.4 Hanging Methods A:0~14mm B 0~36mm Fig4.5 Installation Methods...
- Page 12 Flange Inlet Flange Outlet Thermal Insulation The Wall Thermal Insulation Outside The Indoor (Downward Slop) Air Outlet Unit Canvas Duct Air Inlet Canvas Duct (Field Supply) The Cover (Field Supply) (Field Supply) Air Inlet Air Outlet Refrigerant Gas Pipe The strainer is not standard,install it in Refrigerant Liquid Pipe the air inlet piping.
- Page 13 Discharge gas inside And remove the cap Gas Pipe Cool by a wet cloth An excess or a shortage of refrigerant is the main cause of trouble to the units. Charge the correct refrigerant quantity.
-
Page 14: Drain Piping
6.Drain Piping Indoor Unit The Bottom Drain Plug Auxiliary Drain Pan Trap (Field Supply) Common Drain Pipe (1/100 Down-Slop at least) (Do not lay into the water) - Page 15 Don not connect cable of remote control switch and operating wires with power supplyand earth wires together.Keep 50MM away from each other . Use appointed wires,and ensure the terminal fixed. switch to the connectors inside the The elecrtrical wires should not contact with gas pipe or liquid pipe.Make sure the pipe systerm insulated completely Make sure that the electrical wires are not...
- Page 16 Eletrical Box Cover 380-415V 3N~ 50Hz Cable of Remote Bolts Control Switch Operating Wires Cord Clamp Maximum Power Source Cable Size Transmitting Cable Size Model Current EN60 335-1*1 EN60 335-1*1 AVA-154UX6SSH-400 3.48A 2.5mm 0.75mm AVA-190UX6STH-500 4.46A 2.5mm 0.75mm AVA-190UX6STH-600 5.46A 2.5mm 0.75mm...
- Page 17 The wire sizes marked with *1 in the above table are selected at the maximum current of the unit according to the European Standard, EN60335-1.Use the wires which are not lighter than the ordinary polyvinyl chloride sheathed flexible cord (code designation H05VV-F). EN60 335-1 ※...
- Page 18 Model...
- Page 19 DSW5&RSW2 DSW6&RSW1 Fuse Recover (DSW7) Optional Function Setting (DSW8)
- Page 20 P00429Q 201 .0...
