Signtex Lighting CAEBB Series Installation Instructions & User Manual page 2

Crystal Accessible Exit Edge- Lit LED Sign System
Battery Backup Models
Before installing or connecting any primary power wiring,
DISCONNECT MAIN POWER SUPPLY AT THE CIRCUIT BREAKER OR FUSE.
CEILING MOUNT
NICAD
BATTERY PACK
POWER
SUPPLY
TEST PANEL ASSEMBLY
BACKBOX
BATTERY
POLARIZED
CONNECTOR
BACKBOX
TEST PANEL
BATTERY
CONNECTOR
LED LAMP
CONNECTOR
TEST PANEL
#6-32 LOCK NUT
POWER
MODULE
TEST PANEL
LOCK NUT
BACK BOX
TEST PANEL
-2-
Series CAEBB
AC POWER
INPUT 120/277 VAC
LAMP HOUSING
#6-32 SCREWS
(4 REQD)
TRIM PLATE
TRIM PLATE #8-32 SCREWS
(2 REQD)
#6-32 LOCK NUT
06.16.00
