How to operate the unit with an optional 5.1 ch decoder/AV matrix unit connected
Adjusting sound quality
The delay time and level of the sound from each speaker can be adjusted in order to correct
any phase mismatches in the sound resulting from the listening position.
In addition, the optional 5.1 ch decoder/AV matrix unit has a function for automatically
correcting time alignment.
SETTING
Touch
adjustment screen.
SP SETTING
Touch
screen.
Touch
to adjust the delay time.
● The delay time can be adjusted within
0.0 to 10.0 ms (in units of 0.1 ms).
: Increase the time
: Decrease the time
● Touch
settings. The time alignment mode
adjustments will be saved and the
system will return to the previous
operation screen.
154

Adjusting time alignment

Manual adjustment

in the sound
in the setting
or for each speaker
BACK
after making
● When the 1 WAY speaker setting is selected
● When the 3 WAY speaker setting is selected
