Touch to select the Q curve
Q
pattern.
● Each time the switch is touched, the Q
curve pattern will be changed in the
order shown below.
Q1 Q2
(Sharp) (Middle Sharp)
Repeat steps
change the setting for each
channel and band.
● It is not possible to set more than one
band in the same channel to the same
median frequency.
Touch the switch you want to use
to save ( EQ1 to
hear a beep.
● Save the PEQ, time alignment, cross
over and speaker level settings for
future use.
BACK
● Touch
settings. The PEQ mode adjustments
will be saved and the system will return
to the previous operation screen.
Q3
(Normal)
through to
EQ5 ) until you
after making
Q4 Q5
(Middle Slow) (Slow)
143
