- Page 1 OPTICAL BEAM SMOKE DETECTOR DOP-6001R _________________________________________________________________________________ INSTALLATION AND MAINTENANCE MANUAL IK-E343-002GB Edition III...
- Page 2 The DOP-6001R beam smoke detector, covered by this manual, complies with the requirements of the following European Union directives: Regulation (EU) No. 305/2011 of the European Parliament and of the Council of 9 March 2011 laying down harmonised conditions for the marketing of construction products and repealing Council Directive 89/106/EWG;...
-
Page 3: Table Of Contents
Table of contents 1. PURPOSE…………………………………………………………………………………………………………………………………………… 2. TECHNICAL SPECIFICATIONS……………………………………………………………………………………………………………… 3. PRINCIPLE OF OPERATION…………………………………………………………………………………………………………………. 4. DESIGN………………………………………………………………………………………………………………………………………………. 5. INSTALLATION…………………………………………………………………………………………………………………………………….. 6. OPERATING CONDITIONS AND MAINTENANCE…………………………………………………………………………………… 7. SAFETY CONDITIONS…………………………………………………………………………………………………………………………… 7.1 Repairs and maintenance 7.2 Works at height 7.3 Anti-dusting eye protection 7.4 Eye protection against laser beam operating equipment 8. -
Page 4: Purpose
PURPOSE The DOP-6001R Beam Smoke Detector is designed for smoke detection at the start of a fire. It is especially suitable for protection of premises where, in the first phase of the fire, smoke appearance is expected and in which, due to a large space area, installation of a greater number of spot smoke detectors would be necessary. -
Page 5: Principle Of Operation
Fig. 1 DOP-6001R detector with prism reflector PRINCIPLE OF OPERATION The DOP-6001R detector consists of an infrared (IR) light transmitter and a receiver located in a single enclosure, and an interoperating separate E39-8R prism reflector or 4xE39-8R reflector panel. The detector operation principle consists in continuous analysis of optical air transparency in the space between the detector and the reflector (reflector panel). -
Page 6: Design
DESIGN The DOP-6001R detector design is shown in Fig. 1 and Fig. 3. The detector casing, made of plastic, embraces electronic circuits and optical elements of the transmitter and receiver as well as a laser diode that facilitates the detector easy optical alignment. The lenses for infrared beam focusing are covered with a detachable filter. -
Page 7: Operating Conditions And Maintenance
Fig. 2 DOP-6001R detector during optical path alignment OPERATING CONDITIONS AND MAINTENANCE The DOP-6001R smoke detector long-lasting operation, especially in dusty premises, may result in contamination (dust, dirt accumulation) of the optical part of the detector and of the reflector/reflector panel. -
Page 8: Safety Conditions
18%; 30%; 50% (Fig. 10). A plastic sheet with overprint consistent with the detector set sensitivity level should be put on the detector front plate, what should trigger an alarm mode. The DOP-6001R detector testing foil with overprints is included in the service kit. -
Page 9: Design Recommendations
DESIGN RECOMMENDATIONS The DOP-6001R beam smoke detector operates properly, similarly to all other smoke detectors, in case it is installed at the height not exceeding 12 m. When it is mounted higher (up to 20 m), another row of detectors shall be provided at an intermediate level, with adequately larger number of detectors. - Page 10 Fig. 3 DOP-6001R design and overall dimensions...
- Page 11 Fig. 4 DOP-6001R detector installation wires connection Fig. 5 DOP-6001R detector internal connections and output terminals diagram...
- Page 12 Declared sensitivity levels: - jumper in position 50 % – low sensitivity - jumper in position 30 % – medium sensitivity - jumper in position 18 % – high sensitivity Alarm mode declaration: - jumper in W1 position - supported W2 jumper must be always in place.
- Page 13 Fig. 7 DOP-6001R detectors connection in detection line...
- Page 14 Fig. 8 E39-R8 prism reflector Fig. 9 Reflector panel...
- Page 15 Fig. 10 DOP-6001R detector testing foil with overprints...
- Page 16 Fig. 11 Reflector panel assembly IK-E343-002GB 10/2021...
- Page 17 NOTES:...
