Owner's Manual
CIR-TM6000AC-G1
This product is intended for use in light commercial applications. Use in any other applications
without written consent from Green Series will void manufacturer's warranty.
(Please refer to the warranty details outlined in this manual for details)
Light Commercial
Install Date: _________________________ Serial Number: ________________________
www.GreenSeriesFitness.com
©April 2017
Call Toll free at (800) 269-7130
CIR-TM6000AC-G1
Revision 1.2
John C. Jensen

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CIR-TM6000AC-G1 and is the answer not in the manual?

Questions and answers

Related Manuals for GREEN SERIES FITNESS CIR-TM6000AC-G1

Summary of Contents for GREEN SERIES FITNESS CIR-TM6000AC-G1

  • Page 1 Owner's Manual CIR-TM6000AC-G1 This product is intended for use in light commercial applications. Use in any other applications without written consent from Green Series will void manufacturer’s warranty. (Please refer to the warranty details outlined in this manual for details)

  • Page 2: Table Of Contents

    BELT ADJUSTMENT …………………………………………………………..….…… 32-33 CARE & MAINTENANCE ……………………………………………………..…...…... 34-38 TROUBLE SHOOTING ………………………………………………………..……….. 39-40 ENGINEERING MODE ………………………………………………………..……….. 41-43 PARTS LIST …………………………………………………………………………………..44 EXPLODED DRAWINGS ………………………………………………………………..45-47 WARRANTY …..……………………………………………………………..………….. 48-50 www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 3: Safety Precautions

    These spacing recommendations should be used when positioning equipment away from sources of heat, such as radiators, heat registers, and stoves. Avoid temperature extremes. 12” 300mm 24” 24” 24” 600mm 600mm 600mm 79” 2000mm www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 4 Green Series Fitness prior to use.  Don't attempt to use this unit with an extension cord which does not meet Green Series Fitness criteria of the following; 12 gauge SO3, maximum of 25 foot length with a 20 amp rating.
  • Page 5 13. The equipment is intended for commercial use. Store the safety key in a secured location while not in use and keep away from children. Maximum user weight: 450Ibs (204 kg). www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 6 Sustained exercise conditions your heart, lungs and muscles. The longer you are able to sustain exercise within your target heart range, the greater the aerobic benefits. To begin maintain 2~3 minutes of steady, rhythmic exercise, then check your heart rate. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 7 These side platforms are an appropriate position to relax before starting the training again. For your own safety and comfort, always start your training sessions at low speed. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 8 In case of emergency, press the STOP key, hold the handrails and get off when the belt stops. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 9: Target Heart Rate Zone

    *The noise value list below is when it is at top speed with unloading status : LpAeq(dB) < 70dB www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 10: Technical Specifications

    Audio in jack. The Serial Number of the products The serial number contains of ten values. The location of the serial number shows as the figure. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 11: Unpacking & Assembly

    8mm x 25mm 8mm Flat washer (4 each) (8 each) (8each) #3-8 3mm x 12mm Screw (1 each) 6mm T-Handle #3-7 5mm x 114mm 6mm x80mm www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 12 Remove the motor cover screws #1 - #4, and put the motor cover aside. 2). Reinstall motor cover screws #1 - #4 to frame until Step 5. Lift hood off Screw #3 Screw #4 Screw #2 Screw #1 www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 13 3). Do not untie wires till end of Step 3 Pull wire thru top *Do not untie at this time Lower tube hole Lower frame hole www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 14 Bolt#2 8mm x 15mm Allen Bolt Bolt#5 Bolt#3 (2 each) #3, #7 Bolt#4 Bolt#5 8mm Flat Washer (8 each) Bolt#8 8mm Lock Washer (8 each) www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 15 8mm Lock Washer (4) bolts 20 (4 each) ft/lbs Attention: Confirm both Handlebars are aligned and flush with no gap before moving on to Step 5. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 16 Upper console wire 8mm Flat Washer (8 each) *Inside Only Lower console wire 8mm Lock Washer (4 each) *Front & Back Only (4) bolts 20 ft/lbs www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 17 50 to 100 pounds of force several times. If needed, re-torque to the specifications outlined. (2) bolts 20 ft/lbs (2) bolts 20 ft/lbs (1) bolt 20 ft/lbs (2) bolts 20 ft/lbs (1) bolt 20 ft/lbs www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 18 2) Angle hood at 45 degrees left to right to slide hood between front mass tubes, then down to position over motor housing. Install all four (4) screws finger tight, then once all in, tighten with Phillips screw driver. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 19 3) Fasten power cord and “sure connect” by Philips screw driver with new 3mm x 12mm screw. #1-32 Power Cord #4-7 Power Cord Sure Connect 3mm x 12mm Close-up view of Power Phillips head screw Cord w/ Sure Connect www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 20: Warm Up & Cool Down

    Keep your right leg straight and the left foot on the floor; try to stretch your right hand toward the toe, hold this posture for 15 seconds. Relax, and then repeat the action for left leg. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 21: Panel Control & Program

    PANEL CONTROL Safety Key Pad The treadmill will not function if the safety key is not present. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 22 To select program. Quick Start or program start. Quick Start / Pause Press to start the treadmill while in the pause, stop or idle condition. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 23 * If time setting is not zero (count down mode), the time of each segment is “time/16”, else every 2 minute will change the program profile segment. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 24 * If time setting is not zero (count down mode), the time of each segment is “time/16”, else every 2 minute will change the program profile segment. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 25 You can use any speed or incline key or device to change present speed or incline. 7.4. It will process the cool down program before end of workout if time counts down to 0. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 26 PROGRAMS Course program profile www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 27 9. You can also adjust the speed and incline during the workout. 10. It will process the cool down program after 16 segments have been executed. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 28 6.2. The program will be end if time count down to 0 and process the cool down program. After finish the cool down program and get into end mode, the dot matrix shows the test result. 6.3. Test result：【VERY GOOD】,【GOOD】,【AVERAGE】,【BAD】,【VERY BAD】. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 29 11. You can use any speed or incline key or device to change the speed or incline. 12. It will process the cool down program if time count down to 0. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 30 4. The treadmill is now ready to be used. Ensure the emergency stop key clip is secured to your clothing at all times during use. 5. After use, clip the emergency stop key around handrail one and clip to its own cord. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 31: Operation

    High speaker volume may interfere with the heart rate accuracy. Please decrease the speaker volume when you are using the heart rate function. *Warning: After removing the safety key, wait for 5 seconds to re-insert in. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 32 If the heart beat is too high or irregular, please have your hands out of the hand grip until the pulse display returns to " 0 ", then redoing the test. Don't do this test while running. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 33: Belt Adjustment

    Using wrench, turn the right adjustment bolt clockwise 1/4 turn and the left adjustment bolt counterclockwise 1/4. c. If the belt is still not centered, repeats the above steps until the running belt is on center. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 34 The running belt can be worn and damaged if the running belt travels beyond this scope. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 35: Care & Maintenance

    It can cause the running belt to slip when in use if there is too much lubrication SPRAY AREA Silicone bottle www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 36 Front Roller & Groove Wipe Checking Rear Roller Checking Safety Key Wipe Drive Belt Wipe Checking Running belt tension Checking Motor Control Clean(dust) Motor Pulley & Groove Checking www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 37 Support recommends that the following preventive maintenance schedule be followed. DAILY • Unplug the treadmill. Clean entire machine using water and a mild soap or other Green Series Fitness approved solution (cleaning agents should be alcohol and ammonia free). MONTHLY or QUARTERLY (depending on usage or dirty environments) •...
  • Page 38 This treadmill has been designed and equipped with wheels for easy mobility. Before moving, ensure the master power switch is in the off position and the power cord is unplugged from the electrical outlet. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 39 MAINTAIN LABELS AND NAMEPLATES Do not remove labels for any reason. They contain important information. If unreadable or missing, contact Green Series Fitness for a replacement or an authorized service provider. MAINTAIN ALL EQUIPMENT Preventative maintenance is the key to smooth operating equipment, as well as keeping the user’s liability to a minimum.

  • Page 40: Trouble Shooting

    If the supply cord is damaged, it must be replaced by the manufacturer or its service provider or a similarly qualified person in order to avoid a hazard. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 41 Type of Lubricant: Use only approved lubricant on the walking belt and deck. Green Series Fitness requires the use of Silicon lubricant. Using wax or spray type lubricant, or others, will result in a buildup of a sticky substance on the walking belt and deck.

  • Page 42: Engineering Mode

    Series Customer Service before performing this change. Roller Size is displayed. (Do not modify) Press ENTER to continue. Press SPEED +/- to change min speed. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 43 Recommended for AC treadmill This screen shows the Total Distance exercised in MILES or KILOMETERS. Press ENTER to continue. This screen shows Total Hours of use. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 44 Press ENTER to continue and exit the Engineering Mode. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 45: Parts List

    H020803-001 Bolt M4x10mm 1-75 H021206-000 S Washer M4 1-76 F916215-001 Non-slip sticker 1-77 F300037-000 Incline motor Bushing 1-78 H021120-004 Washer M8 1-79 F377007-001 Wave filter www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 46: Exploded Drawings

    EXPLODED DRAWING www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 47 EXPLODED DRAWING (CONSOLE SET) www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 48 EXPLODED DRAWING (CONSOLE MAST SET) www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...

  • Page 49: Warranty

    The warranty and remedies set forth below are exclusive and in lieu of all others, oral or written, expressed or implied. No reseller, agent or employee is authorized to make any modification, extension or addition to this warranty. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 50 13. GREEN SERIES™ makes no warranty either expressed or implied regarding third-party (non-GREEN SERIES™) installed parts, accessories or modifications. 14. All GREEN SERIES™ equipment shall be properly cleaned and cared for in accordance to the procedures outlined the in the owner’s manual. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
  • Page 51  By using this product, I indicate that I understand and agree to the terms of this warranty. www.GreenSeriesFitness.com ©April 2017 Call Toll free at (800) 269-7130 CIR-TM6000AC-G1 Revision 1.2 John C. Jensen...
