- Page 1 Models REFRIGERANT System | HSNRJ25B | HSNRJ35B | HSNRJ50B | HSNRJ70B | HSNRJ80B Indoor | HINRJ25B | HINRJ35B | HINRJ50B | HINRJ70B | HINRJ80B Outdoor | HONRJ25B | HONRJ35B | HONRJ50B | HONRJ70B | HONRJ80B J Series Split Type Wall Mounted Air Conditioner...
- Page 2 OH&S requirements This appliance must be installed, maintained and removed only by an Authorised Person. For continued safety of this appliance it must be installed and maintained in accordance with the manufacturer’s instructions. REFRIGERANT Rinnai Split AC IM...
-
Page 3: Table Of Contents
Connecting Vapour / Liquid Pipes To Indoor & Outdoor Units ���������������������������������������������������������������������� 13 Air Purging & Leakage Test �������������������������������������������������������������������������������������������������������������������������� 14 Evacuation Vacuum Method / Leak Test ������������������������������������������������������������������������������������������������������ 14 Adding Refrigerant for Longer Line Length �������������������������������������������������������������������������������������������������� 14 Final Checklist �������������������������������������������������������������������������������������������������������������������������������������������������� 15 Contacts Rinnai Split AC IM... -
Page 4: Warnings And Important Information
For safety and warranty purposes, appliances that may be damaged or incorrect MUST NOT be installed or operated under any circumstances. Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances. - Page 5 Improper earthing may cause electric shock. The circuit breaker must have the functions of magnetic tripping and heat tripping to prevent short circuit and overload. Use a standard circuit breaker and fuse conforming with the rating of the appliances. Model HSNRJ25B HSNRJ35B HSNRJ50B HSNRJ70B HSNRJ80B Circuit Breaker (Amps) The unit must be earthed in accordance with local regulations.
- Page 6 The table below indicates the temperature ranges the air conditioner can be operated within. MODE Cool Mode Heat Mode Dry Mode Room Temperature > 17°C < 27°C > 17°C Outdoor Temperature -15°C ~ 52°C -15°C ~ 24°C -15°C ~ 52°C Rinnai Split AC IM...
-
Page 7: Installation General
Refrigerant entry (for service and installer use only) 10. Outdoor unit air inlet (on rear & left side of unit) 11. Outdoor unit air discharge and protective grille (on front of unit) WEIGHTS & DIMENSIONS Model HSNRJ25B HSNRJ35B HSNRJ50B HSNRJ70B HSNRJ80B Indoor 12.0 13.5 14.0... -
Page 8: Location
Chargeless Minimum Maximum Maximum Additional Pipe Size Gas Pipe Size Liquid Length Length - X Length - X Height - Y Refrigerant Models inch inch HSNRJ25B Ø9.52 Ø6.35 HSNRJ35B Ø12.7 Ø6.35 HSNRJ50B Ø12.2 Ø6.35 HSNRJ70B Ø15.88 Ø6.35 HSNRJ80B Ø15.88 Ø6.35 The outdoor unit is charged for interconnecting pipe lengths of up to 10m. -
Page 9: Installation
Drill a Ø70mm wall penetration through the wall with a 2° to 4° fall to the outside wall. INSIDE 2° to 4° fall OUTSIDE Drain Pipe Connect the drain pipe to the drain hose outlet of the indoor unit, Bind the joint with PVC insulation tape (not supplied). Rinnai Split AC IM... -
Page 10: Electrical Connections
NOTE 2. Unscrew the rubber plug from the alternate drainage discharge connection point. 3. Clip the drainage hose into the alternate discharge connection point. 4. Screw the rubber plug into the unused drainage discharge connection point. Rinnai Split AC IM... -
Page 11: Outdoor Unit
Secure the electrical cable(s) and power cable onto the control board with the cable clip. Connect the cables as shown on the drawing below. Wiring HONRJ80B ONLY All Other Outdoor Models cover Re-install the wiring cover. Rinnai Split AC IM... -
Page 12: Dred Connection (Optional)
Insert the barbed elbow into the drainage point of the outdoor unit as shown. A drainage hose (installer to supply) will need to be fitted. Drainage of the condensate must conform with all local regulations and municipal building codes including local OH&S requirements. IMPORTANT Rinnai Split AC IM... -
Page 13: Refrigerant Pipes
Ø 5/8" 75 Nm Indoor Unit Outdoor Unit Vapour pipe Liquid pipe Ensure the joint nut is tightened firmly to avoid leakage. Ensure that both the connections and the refrigerant pipes are wrapped with insulation material. CAUTION Rinnai Split AC IM... -
Page 14: Air Purging & Leakage Test
It is very easy to overcharge, take caution in charging Vacuum refrigerant liquid and keep your eye on the scales to avoid Pump CAUTION overcharging the unit. Take care not to discharge refrigerant into the atmosphere during installation, re-installation, repair or service. Rinnai Split AC IM... -
Page 15: Final Checklist
No cooling or heating Is the end user fully aware of the operating procedure? Incorrect operation If you have answered no to any of the above, you must check and correct before appliance hand-over to customer. Rinnai Split AC IM... - Page 16 Tel: 1300 555 545* Fax: 1300 555 655 Monday to Friday, 8.00 am to 5.00 pm EST. *Cost of a local call higher from mobile or public phones. For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai New Zealand Ltd...
