This appliance shall be installed in accordance with:
• Manufacturer's Installation Instructions
• Current AS/NZS 3000
• Local Regulations and Municipal Building Codes including local OH&S requirements
This appliance must be installed, maintained and removed by an Authorised Person.
For continued safety of this appliance it must be installed and maintained in
accordance with the manufacturer's instructions.
Split Type Wall Mounted Air Conditioner
Rinnai System Models
System
HSNRA26
HSNRA35
HSNRA50
HSNRA70
HSNRA80
Reference Only
Owner's Manual
Indoor
HINRA26M
HINRA35M
HINRA50M
HINRA70M
HINRA80
HINRA20M
Matching Multi System Only
Outdoor
HONRA26
HONRA35
HONRA50
HONRA70
HONRA80
Advertisement
Table of Contents
Related Manuals for Rinnai HSNRA35
Summary of Contents for Rinnai HSNRA35
- Page 1 Owner’s Manual Split Type Wall Mounted Air Conditioner Rinnai System Models System Indoor Outdoor HSNRA26 HINRA26M HONRA26 HSNRA35 HINRA35M HONRA35 HSNRA50 HINRA50M HONRA50 HSNRA70 HINRA70M HONRA70 HSNRA80 HINRA80 HONRA80 Reference Only HINRA20M Matching Multi System Only This appliance shall be installed in accordance with: •...
-
Page 2: Table Of Contents
Installation Record - System Details ���������������������������������������������������������������������������������������������������������������� 12 Customer care Program ����������������������������������������������������������������������������������������������������������������������������������� 12 Service Maintenance Schedule - Non Ducted Air Conditioning Systems ��������������������������������������������������������� 13 Save A Service Call ������������������������������������������������������������������������������������������������������������������������������������������ 14 When to Call for Service ����������������������������������������������������������������������������������������������������������������������������������� 16 Disposal Guidelines ������������������������������������������������������������������������������������������������������������������������������������������ 16 Warranty Contacts Rinnai Split AC OM... -
Page 3: Warnings And Important Information
0°C ~ 50°C WARRANTY EXCLUSIONS Rinnai product warranty excludes faults and failures caused by improper use and abuse; fair wear and tear; or failure to follow instructions regarding service and maintenance� It is very important that you maintain your appliance and have it serviced regularly� It is a condition of warranty that you adhere to the maintenance and service requirements as set out in this manual�... - Page 4 A NOTE ON ILLUSTRATIONS The illustrations used in this manual are for explanatory purposes only and the shape of your indoor unit NOTE may vary slightly from that which is shown in this manual� Rinnai Split AC OM...
-
Page 5: Air Conditioner Basics
Refrigerant Leakage Detection (where fitted) The indoor unit will automatically display ‘EC’ when it detects refrigerant leakage� For a more detailed explanation of your air conditioners advanced functionality, please refer to the Remote Control Manual. NOTE Rinnai Split AC OM... -
Page 6: Remote Control Batteries
Limit energy usage by using TIMER ON and TIMER OFF functions� • Do not block air inlets or outlets� • Regularly inspect and clean air filters. For a more detailed explanation of your air conditioner's advanced functionality, please refer to the Remote Control Manual. NOTE Rinnai Split AC OM... -
Page 7: Basic Operation
Do not keep louvre set to a vertical an angle for long periods of time, as this may cause water condensation to drip on your furnishings. DO NOT put your fingers in or near the blower and suction sides of the unit. The high-speed fan inside the unit may cause injury. Rinnai Split AC OM... -
Page 8: Sleep Operation
After power restoration, the automatic restart cycle will take approximately 5 minutes. DO NOT adjust setting during the restart cycle period. NOTE Rinnai Split AC OM... -
Page 9: Manual Operation
When operated in this manner the appliance is set to FORCED Cooling mode, the temperature will be set to the lowest setting and the fan will run on the highest setting. NOTE 4� Press the Manual Control button a third time to return the unit to standby� Rinnai Split AC OM... -
Page 10: Care & Maintenance
Filter Tab cooling mode during humid conditions. For replacement filters, please contact Rinnai. Turn off the power before you perform any maintenance; otherwise it may cause electric shock. -
Page 11: Cleaning The Outdoor Unit
After long periods of non-use, or before periods of frequent use, do the following: • Check for damaged wires • Clean all filters • Check for leaks • Replace batteries • Make sure nothing is blocking all air inlets and outlets of both the indoor or outdoor units Rinnai Split AC OM... -
Page 12: Installation Record - Installer Details
Please ensure you register your product warranty on line at rinnai�com�au� The Rinnai Customer Care Program is designed to help you get the most out of your new system� Service and maintenance in accordance with the Service Maintenance Schedule on page 13 is essential in ensuring the prolonged useful life of your system, and help ensure it operates at optimum efficiency. -
Page 13: Service Maintenance Schedule - Non Ducted Air Conditioning Systems
Batteries (If applic) * Installation and other field-supplied components are not covered by Rinnai product warranty. These include, but are not limited to, control wiring, refrigerant gas and electrical connections to the appliance. These should be inspected as they can affect the performance, reliability and safety of the system. -
Page 14: Save A Service Call
Possible flat batteries, replace the batteries with two fresh 1.5V (AAA) batteries� If after changing batteries the remote control still does not work contact Rinnai� Remote control does not operate the Check for interference or obstructions that may be blocking the indoor unit�... - Page 15 Too many sources of heat in the room (people, computers, electronics, etc)� Where possible reduce the amount of heat sources� Low refrigerant due to a leak or after long-term use, contact Rinnai� SILENCE function (where fitted) is activated. SILENCE Function can lower product performance by reducing operating frequency�...
-
Page 16: When To Call For Service
• If the unit has been exposed to flooding DO NOT ATTEMPT TO FIX THESE YOURSELF! TURN OFF THE AIR CONDITIONER, AND CONTACT RINNAI. DISPOSAL GUIDELINES This appliance contains refrigerant and other potentially hazardous materials� When disposing of this appliance, the law requires special collection and treatment�... -
Page 17: Warranty
Spare Parts 1 Year 2�2 Rinnai will determine in its sole discretion, which classification the Product fits into and the corresponding Warranty that shall apply� 2�3 An Authorised Service Representative will repair or replace, at its option, the Product or any part of the Product that its examination shows to be defective�... - Page 18 Service or Owner’s Manual; b) complies with clause 7 below (titled “Purchaser’s Responsibilities”); b) notifies Rinnai within 30 days of a defect developing, that a claim is being made under this Warranty; and c) provides, in support of the claim made under this Warranty, a Proof of Purchase�...
- Page 19 Rinnai considers appropriate, it will authorise the Purchaser in writing to pay for the relevant freight charges, in-transit insurance expenses or travelling costs and then, upon provision by the Purchaser to Rinnai of a tax invoice showing those costs have been incurred, reimburse the Purchaser for such costs which are within the terms of the authorisation�...
-
Page 20: Contacts
Braeside, Victoria 3195 For further information visit: www.rinnai.com.au Part Number: B063804 Rinnai has a Service and Spare Parts network with personnel who are fully trained December 2016 and equipped to give the best service on your Rinnai appliance. If your appliance EQPL38586755 requires service, please call our National Help Line.
