Installer: Leave these instructions with consumer.
Consumer: Keep these instructions for future reference
DANGER

If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from
the appliance and immediately call
your gas supplier or fire department.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill
you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
Jul-1-2017
ASSEMBLY INSTRUCTIONS
CSA Model 99000
ARV05900
.
WARNING:
Improper installation, adjustment alteration,
service or maintenance can cause injury or
property damage. Read the installation,
operating and maintenance instructions
thoroughly before installing or servicing this
equipment.
WARNING: For Outdoor Use Only
FOR USE WITH 20LB (9KG) PROPANE
CYLINDER (NOT SUPPLIED) WITH TYPE 1
CONNECTION. ALSO THE LP REGULATOR
MUST BE SUPPLIED BY THE MANUFACTURER.
CANNOT BE CONVERTED FOR USE WITH
NATURAL GAS-FOR USE WITH PROPANE ONLY.
WARNING:
USE FACTORY APPROVED
REPLACEMENT PARTS AND
ACCESSORIES ONLY. USE
OF UNAPPROVED PART OR
ACCESSORIES CAN VOID
THE WARRANTY ON THIS
PRODUCT AND RESULT IN
AHAZARDOUS CONDITION.
PLEASE CONTACT US FOR
INFORMATION REGARDING
REPLACEMENT HOSES,
THERMOCOUPLES,
ELECTRODES, IGNITION
MODULES, LAVAROCKS,
LOGS, FIRE ICE, ETC.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 99000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Four Seasons Courtyard 99000

  • Page 1 ASSEMBLY INSTRUCTIONS CSA Model 99000 ARV05900 Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference DANGER   WARNING:  If you smell gas: Improper installation, adjustment alteration, 1. Shut off gas to the appliance. service or maintenance can cause injury or 2.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Information Important About Propane Specification Parts Identification List Installation Batteries Lighting Instructions Maintenance Troubleshooting Guide Warranty...
  • Page 3: Important Safety Information

    IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54; International Fuel Gas Code. ; Natural Gas and Propane Installation Code, CSA B149.1; or Propane Storage and Handling Code, B149.2, as applicable. The appliance must be isolated from the gas supply piping system by closing its equipment shutoff valve during any pressure testing of the gas supply system at test pressure equal to or less than 1/2 psi (3.5kPa).
  • Page 4: Important About Propane

    IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A self contained LP-gas cylinder for use with this appliance must have a capacity of 20 lbs. and must be equipped with a Type 1 connector and an OPD (overfill protection device). See Figure 1. The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S.
  • Page 5: Parts Identification List

    PARTS IDENTIFICATION LIST PART DESCRIPTION PART# CONTROL KNOB FP0245 GAS VALVE FP0307 LP REGULATOR HOSE FP1369 ELECTRODE FP1330 ORIFICE ELBOW FP1385 IGNITION MODULE FP1666 PROPANE ORIFICE FP1283 FIRE ICE SET FP1471 “AAA” BATTERY(1.5V) HW0705 FOOTCAP FC0660 1/4" X 15 MM BOLT HW0034 1/4"...
  • Page 6 BACK PANEL FP1998 LEFT SIDE PANEL FP1999 RIGHT SIDE PANEL FP2000 DOOR PANEL FP2001 MIDDLE SUPPORT FP2002 FIRE PAN/BURNER FP2003 ASSEMBLY BURNER COVER FP2004...
  • Page 7: Installation

    INSTALLATION 1. Identify all parts packed in the carton against the parts list. Remove all protective materials and set parts on a flat, non-abrasive surface. 2. Attach the back panel to side panels by using four 1/4"x40 mm bolts and Ø6.5X1.0 mm washers as shown in Figure 3.Guide bolts through holes in back panel, into pre-drilled holes in the side panels.
  • Page 8 4.With the help of another person, carefully place the table top onto the firepit base. After making any necessary adjustments to the alignment of the table top and the assembled base, use four 1/4"x20 mm bolts and Ø18xØ6.5x1.5 mm washers as shown in Figure 5.Guide the bolts through the holes in the base brackets, into the pre-drilled holes in the table top.
  • Page 9 6. Place gas tank onto the LP support as shown in Figure 7. Connect the regulator as shown in figure.8a. Turn the black handle clock-wise to tighten. Turn the handle counter clock-wise to remove. The hose must point down. Check that the valve is turned all the way clockwise to the "OFF"...
  • Page 10: Batteries

    BATTERIES Make sure the control knob is in the "OFF" position. Figure 15 Unscrew the push button cap on the ignition module located on the control panel to access the battery compartment. The ignition module requires one Alkaline AAA size battery (1.5V). The negative (-) end goes in first. See Figure 11.
  • Page 11: Maintenance

    MAINTENANCE The flames should look like those in Figure 13. To clean the burner, use a soft brush after the burner has cooled completely. Never use a vacuum cleaner on the burner. It is recommended that the fire pit be stored indoors during the winter if it will be subjected to freezing temperatures.
  • Page 12: Warranty

    ONE-YEAR LIMITED WARRANTY What is Covered Under This Warranty? The item you have purchased is warranted against defects in material and workmanship for the following parts from the date of purchase for the period of warranty as outlined below, but only when the unit is installed and operated in accordance with the instructions in this Owner’s Manual and in compliance with local building and fire codes: Limited 1 Year...
