Item# 258362
MFR#SRFP11716
Assembly Instructions
& User's Manual
35" Deep Bowl Fire Pit
Please keep this instruction manual for future reference
Warning:
READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR
OPERATE THIS PRODUCT.
Adult assembly required.
Keep screws and parts out of reach of children.
Customer Service: 1-866-814-0585, 8:00am to 8:00pm,
Monday thru Friday Eastern Standard Time
(Made in China)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Four Seasons Courtyard SRFP11716
Summary of Contents for Four Seasons Courtyard SRFP11716
- Page 1 Item# 258362 MFR#SRFP11716 Assembly Instructions & User's Manual 35" Deep Bowl Fire Pit Please keep this instruction manual for future reference Warning: READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT. Adult assembly required. Keep screws and parts out of reach of children.
-
Page 2: Table Of Contents
Table of Contents Warnings..................2 Exploded View..................4 Tools,Parts and Hardware............... 4 Assembly Instructions ..............Care and Maintenance............... Warranty Information................Note: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. If any part is missing or damaged do not attempt to assemble the unit. Contact customer service for replacement parts. -
Page 3: Warnings
Warnings WARNING For Outdoor Use Only (outside any enclosure) WARNING 1. Improper installation, adjustment, alteration, service, or maintenance may result in property damage, injury or death. 2. Read the installation, operation, maintenance instructions thoroughly before installing or servicing this equipment. 3. - Page 4 Warnings DO NOT store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance. DO NOT store or use an LP gas cylinder within 10 feet (3.05 m) of this fire pit while it is in operation. DO NOT use this fire pit near automobiles, trucks, vans or recreational vehicles.
-
Page 5: Exploded View
Exploded View TOOLS REQUIRED (Not included): Phillips screwdriver Page 4 of 9... - Page 6 Parts List Part # Description Picture Screen Safety Ring Fire Bowl Screen Hook Hardware Hardware # Description Picture M5 x 12 Screw M5 x 15 Tapping Screw M6 Flange Nut M6 Ring Screw Page 5 of 9...
-
Page 7: Assembly Instructions
Assembly Instructions NOTE: Assemble the fire pit on a non-abrasive, level surface. If missing parts, please contact customer service. Step 1 Attached the legs (E) to the fire bowl (C) with (12) M5 x 10 screws (AA) as illustrated. Hardware Used M5 x 10 Screw Step 2 Attach the safety rings (B) to the fire bowl... - Page 8 Assembly Instructions Step 3 Connect the safety rings (B) with (4) M5 x13 tapping screws (BB) as illustrated. Hardware Used M5 x 13 Tapping Screw Step 4 Attach M6 ring screw (DD) to the top of the screen (A) with M6 flange nut (CC), then place the screen (A) on the top of the fire bowl (C) followed by the screen hook (D) as illustrated.
-
Page 9: Care And Maintenance
Care and Maintenance Lighting 1. Make sure there is only a small amount of ash in the bottom of the bowl. 2. Place a layer of dry kindling or a natural fire-starter onto the center of the grid. 3. Place above that a layer of dry seasoned hardwood that is no more than 3/4 the diameter of the bowl. -
Page 10: Warranty Information
Warranty Information 2019 2019 Need help? call our toll free number at: 1 (866)-814-0585 e-mail us at: Shinerichgroup Page 9 of 9...
