This user's guide describes the characteristics, operation, and use of the
TPS65023EVM-205 evaluation module (EVM). This EVM is designed to help the user
evaluate and test the various operating modes of the TPS65023. This user's guide
includes setup instructions for the hardware and software, a schematic diagram, a bill
of materials, and PCB layout drawings for the evaluation module.
Related Documentation From Texas Instruments
TPS65023, Power Management IC For Li-Ion Powered Systems data sheet
(SLVS670)
1
2
3
4
1
2
3
4
5
6
Figure 6. TPS65023EVM-205 Schematic
1
1
Introduction
The Texas Instruments TPS65023EVM is an integrated power management IC for applications that are
powered with one Li-ion or Li-polymer cell and require multiple power rails. The TPS65023 contains three
highly efficient switching step-down converters, two LDOs, and additional status and I/O pins. The device
is controlled via an I
1.1
Requirements
In order for this EVM to operate properly, the following components must be connected and properly
configured.
1.1.1
Personal Computer
A computer with a USB port is required to operate this EVM. The TPS65023 interface software, which is
run on the personal computer (PC), communicates with the EVM via the PC USB port. The user sends
commands to the EVM as well as reads the contents of the TPS65023 internal registers through the USB
port.
SLVU193 - December 2006
Submit Documentation Feedback
..........................................................................................
.................................................................................................
........................................................................................
...................................................................
.....................................................................................
..................................................................................
......................................................................
........................................................................
..............................................................................
2
C interface (HPA172).
List of Figures
......................................................
List of Tables
...........................................................
User's Guide
SLVU193 - December 2006
TPS65023EVM
1
2
4
9
5
6
7
8
9
10
10
TPS65023EVM
1
Advertisement
Table of Contents
Related Manuals for Texas Instruments TPS65023EVM
Summary of Contents for Texas Instruments TPS65023EVM
-
Page 1: Table Of Contents
TPS65023EVM-205 Bill of Materials Introduction The Texas Instruments TPS65023EVM is an integrated power management IC for applications that are powered with one Li-ion or Li-polymer cell and require multiple power rails. The TPS65023 contains three highly efficient switching step-down converters, two LDOs, and additional status and I/O pins. The device is controlled via an I C interface (HPA172). -
Page 2: Setup
1.1.4 Software Texas Instruments provides software to assist the user in evaluating this EVM. To install the software, insert the enclosed CD into your computer. The software should start automatically. If it does not, go to <Start>, <Run>, and type D:\setup.exe, and click <OK> (assuming that D: is your CD drive). Check the TPS65023 product folder on the TI Web site for the latest version of the software. - Page 3 Sets default voltage for DCDC1, 1.2 V or 1.6 V. JP2 – DEF2 Sets default voltage for DCDC2, 3.3 V or 1.8 V. JP3 – DEF3 Sets default voltage for DCDC3, 3.3 V or 1.8 V. SLVU193 – December 2006 TPS65023EVM Submit Documentation Feedback...
-
Page 4: Board Layout
Figure 5show the board layout for the TPS65023EVM-205 PWB. The nodes with high switching frequencies and currents are short and are isolated from the noise-sensitive feedback circuitry. Careful attention has been given to the routing of high-frequency current loops. See the data sheet for specific layout guidelines. -
Page 5: Assembly Layer
Board Layout Figure 1. Assembly Layer SLVU193 – December 2006 TPS65023EVM Submit Documentation Feedback... -
Page 6: Top Layer Routing
Board Layout Figure 2. Top Layer Routing TPS65023EVM SLVU193 – December 2006 Submit Documentation Feedback... -
Page 7: Layer 2 Routing, Gnd Plane
Board Layout Figure 3. Layer 2 Routing, GND Plane SLVU193 – December 2006 TPS65023EVM Submit Documentation Feedback... -
Page 8: Layer 3 Routing, Vin Plane
Board Layout Figure 4. Layer 3 Routing, Vin Plane TPS65023EVM SLVU193 – December 2006 Submit Documentation Feedback... -
Page 9: Schematic And Bill Of Materials
Schematic and Bill of Materials Figure 5. Bottom Layer Routing Schematic and Bill of Materials This section provides the TPS65023EVM-205 schematic and bill of materials. SLVU193 – December 2006 TPS65023EVM Submit Documentation Feedback... -
Page 10: Tps65023Evm-205 Bill Of Materials
Schematic and Bill of Materials Schematic Figure 6. Figure 6. TPS65023EVM-205 Schematic Bill of Materials Table 1. TPS65023EVM-205 Bill of Materials Count RefDes Value Description Size Part Number 10 µF C1, C2, C4, Capacitor, ceramic, 6.3 V, X5R, 10%... - Page 11 Schematic and Bill of Materials Table 1. TPS65023EVM-205 Bill of Materials (continued) Count RefDes Value Description Size Part Number 2.2 µF C8, C18 Capacitor, ceramic, 6.3 V, X5R, 10% 0603 C1608X5R0J225K 0.100 × 2 J1–J6, J9–J18 Header, 2 pin, 100 mil spacing, (36-pin...
