4.6
4.6

User panel SPACE 4000

Functions: Buttons 1-7
• Button ①.
To switch the safety system on and off.
• Button ②
Not active in this configuration.
• Button ③.
For OLP release if the crane is in an OLP
situation and for disconnecting the automatic
dump function.
• Stop button ④
When the button is pressed, all crane func-
tions are stopped.
To release, turn the button clockwise.
• Button ⑤
Sounds the horn.
• Button ⑥
Activates OLP for manual extensions.
• Button ⑦
Activates the remote controller.
44
The Safety system
Operator's Manual GB
①
