Specifications - Cold Jet i3 MICROCLEAN Operator's Manual

COMPONENT GUIDE
The single hose electric i
technology, providing unparalleled precision and reliability. This environmentally
responsible system enables you to safely clean delicate surfaces and complex cavities
and crevices that other machines can't reach—without surface abrasion, disassembly
or harmful secondary waste.
IN THIS SECTION

Specifications. . . . . . . . . . . . . . . 5

Unit Operation. . . . . . . . . . . 11
Maintenance. . . . . . . . . . . 15
Troubleshooting. . . . . 16
SPECIFICATIONS
Weight (empty) Weight (empty)
Dimensions Dimensions
Dry Ice Capacity Dry Ice Capacity
Variable Feed Rate Variable Feed Rate
Power Consumption Power Consumption
Feeder Drive Feeder Drive
Blast Pressure Range Blast Pressure Range
Supply Pressure Range Supply Pressure Range
Air Consumption Air Consumption
Range Range
A-Weighted Emission A-Weighted Emission
Sound Pressure Sound Pressure
Level Range Level Range
MicroClean features Cold Jet's patented shaved dry ice
3
130lb (59kg) 130lb (59kg)
22 x 16 x 21in (56 x 41 x 53cm) 22 x 16 x 21in (56 x 41 x 53cm)
6 x 6 x12in (150 x 150 x 300mm) (24.5lbs./11kg) 6 x 6 x12in (150 x 150 x 300mm) (24.5lbs./11kg)
5 x 5 x 12in (127 x 127 x 300mm) 5 x 5 x 12in (127 x 127 x 300mm)
with inserts (16.5 lbs. 7.5 kg.) with inserts (16.5 lbs. 7.5 kg.)
0 - 1.2 lbs/min (0-0.6 kg/min) 0 - 1.2 lbs/min (0-0.6 kg/min)
100 - 140 VAC 1 Ø 60 Hz 300W (watts) 100 - 140 VAC 1 Ø 60 Hz 300W (watts)
200 - 240 VAC 1 Ø 50 Hz 300W (watts) 200 - 240 VAC 1 Ø 50 Hz 300W (watts)
1/4 Hp, 1.1 A, 230 VAC, 1, 750 RPM, AC Motor 1/4 Hp, 1.1 A, 230 VAC, 1, 750 RPM, AC Motor
20 - 140 psig (1.4 - 9.7 bar) 20 - 140 psig (1.4 - 9.7 bar)
50 - 140 psig (3.4 - 9.7 bar) 50 - 140 psig (3.4 - 9.7 bar)
12 – 50 scfm @ 100 psig (0.3 – 1.4 m3/min @ 6.9 bar) 12 – 50 scfm @ 100 psig (0.3 – 1.4 m3/min @ 6.9 bar)
Dependent on nozzle selection Dependent on nozzle selection
84 (distance of 10 ft.) – 97 dbA (distance of 2 ft.)* 84 (distance of 10 ft.) – 97 dbA (distance of 2 ft.)*
* Nozzle 13865-259 @ 80 PSI blast pressure * Nozzle 13865-259 @ 80 PSI blast pressure
5
