Welcome...7 Powering Your Computer ...9 Using AC Power...10 Connecting the AC adapter...10 Turning on the computer...11 Using the Battery...13 Inserting a battery ...13 Removing a battery ...14 Displaying battery information...15 Charging a battery...17 Notes on batteries...19 Frequently asked questions ...19 Conserving Battery Power ...20 Using power saving modes ...20 Using PowerPanel utility ...21...
Page 2
VAIO Computer Quick Start Connecting Another VAIO Computer ... 46 Connecting VAIO computers... 46 Disconnecting VAIO computers... 48 Frequently asked questions ... 48 CDs and DVDs ...51 Inserting and Ejecting CDs or DVDs ... 52 Copying and Playing CDs... 54 Playing CDs ...
Page 3
Installing a device ...102 Removing a device...103 Notes on using a device in the multipurpose bay ...104 Using the Multilingual User Interface Language Option...105 Changing Numbers, Currency, Time, and Date Formats 106 Changing the Window Design of Sony Programs ..107...
Page 4
VAIO Computer Quick Start Connecting Mice and Keyboards ...109 Using External Mice and Keyboards ... 110 Connecting a mouse or keyboard... 110 Disconnecting a mouse or keyboard ... 111 Frequently asked questions ... 111 Floppy Disk Drives and PC Cards ...113 Using Floppy Disk Drives ...
Page 5
Recording images to a digital video device ...152 Adjusting image resolution ...152 Saving to your hard disk drive ...152 Program Support Information ...154 Sony Service Center...156 Memory Upgrades ...157 Upgrading Your Computer’s Memory ...158 Precautions and procedures ...158 Typical expansion memory configuration ...159 Removing and installing memory modules ...159...
Page 6
VAIO Computer Quick Start Using the Recovery CDs ...163 Application and System Recovery CDs... 164 Using Your Recovery CDs ... 164 Using the Application Recovery CD(s) ... 164 Using the System Recovery CD(s) ... 166 Troubleshooting and Support...169 Troubleshooting Your Computer... 170 Troubleshooting Batteries...
Welcome Congratulations on your purchase of this Sony VAIO® computer, and welcome to the online VAIO® Computer User Guide. This user guide provides detailed information on all aspects of using your new VAIO computer, from keyboard functions to preinstalled software programs.
Powering Your Computer Your VAIO® computer comes with a battery and an AC adapter. This chapter explains how to install and use these supplied accessories to power your computer. It also describes ways you can efficiently utilize the battery as a power source. ❑...
VAIO Computer Quick Start Using AC Power The supplied battery is not charged when you receive your computer. To use your computer immediately, use the supplied AC adapter as the power source. While the computer uses AC power, it automatically charges the battery if it is inserted. See “Using the Battery”...
Turning on the computer To turn on the computer Slide the release lever to the right, and lift the cover while holding the bottom of the computer firmly. Opening the Computer R e l e a s e l e v e r Press the power button until the power indicator turns on.
Page 12
VAIO Computer Quick Start ❑ To increase light intensity, press the Fn+F5 keys. Press the Up Arrow or the Right Arrow key ❑ To decrease light intensity, press the Fn+F5 keys. Press the Down Arrow key or the Left Arrow key...
Using the Battery A battery is an auxiliary power source you can use when your computer is not plugged into an AC outlet. Your computer may come equipped with one or two battery bays, depending on the model you purchased. If your computer comes with two battery bays, you can purchase a second rechargeable battery to extend your computing time.
VAIO Computer Quick Start Slide the battery into the battery bay. If the computer is on, it automatically detects the battery. Inserting a Battery V A I O l o g o f a c i n g u p Push the battery bay cover up until it clicks into place.
Removing a Battery Push in and lift up the battery bay cover until it clicks into place. Displaying battery information You can display the remaining battery charge on the Battery Information toolbar and/or the Battery Information window. To display the Battery Information toolbar Right-click the center of the Windows®...
Page 16
VAIO Computer Quick Start ❑ Time indicator — Displays estimated time (hours : minutes) remaining before the battery fully discharges, also known as the time-to-empty. To close the Battery Information toolbar Right-click the Battery Information toolbar. Select Toolbars from the shortcut menu, and click to cancel Battery Information.
❑ Alarms tab — Displays the alarm settings, which notify you when the battery is fully charged or too low. You can change your computer’s alarm settings on this window. ✍ Click Help in the lower right corner of the window for more information. The battery icons that appear on the Battery Information toolbar and the Battery Information window indicate the current status of the installed battery.
Page 18
VAIO Computer Quick Start To charge a battery You can charge the battery when the computer is on or off. However, the battery will charge faster when the computer is off. Charging the battery takes several hours. See your VAIO® Computer Specifications on the “Welcome” page for the approximate time needed to charge your battery.
Battery indicator status Description Single blink The battery is running out of power. Double blink The battery is charging. The computer is using AC power. Notes on batteries ❑ Never leave the battery in temperatures above 140°F (60°C), such as under direct sunlight or in a car parked in the sun.
VAIO Computer Quick Start Conserving Battery Power You may use the power saving modes and PowerPanel™ utility to conserve battery power. Conserving battery power may significantly extend your computing time, depending on how you use your computer. ❑ Using power saving modes ❑...
✍ If the computer does not activate Hibernate mode, see “Frequently asked questions” for more information. Using PowerPanel utility The PowerPanel utility enables you to select and customize a predefined power management profile to conserve battery life. The following table describes all the predefined power management profiles in PowerPanel.
Page 22
VAIO Computer Quick Start Profile Icon Description Presentation Keeps the display on at all times while it conserves power. This option is ideal for slide show presentations. You can establish settings for LCD (Video) Standby, Hard Disk Standby, and Standby mode to optimize power management for your system.
Page 23
To select a profile Right-click the CPU icon Select Profiles, and click the profile on the shortcut menu. The profile settings are implemented instantly. See “Using PowerPanel utility” for descriptions of available profiles. When you use the battery to power your computer, your system automatically selects the Maximum Battery Life power management profile by default.
Page 24
VAIO Computer Quick Start Power profile Description CPU Control Controls the processor speed. You can select either Performance, Adaptive, Battery Life, or More Battery Life. These selections are listed in order from the greatest to least amount of power consumed. System Standby Controls the time it takes the system to activate the Standby Timer...
Power profile Description LCD Standby Controls the time it takes the system to switch the computer Timer screen (LCD) to Standby mode when the system is idle. This setting only turns off power to the computer screen. The system itself still functions on full power. HDD Standby Controls the time it takes the system to switch the hard disk Timer...
Internet and choosing an Internet service provider (ISP) or setting up an existing account. When you connect to the Internet, you can register your VAIO® computer, use online services, and gain access to Sony Computing Support.
Page 29
Connecting a Telephone Cable M o d e m j a c k ✍ Your computer does not work with party lines, cannot be connected to a coin-operated telephone, and may not work with multiple telephone lines or a private branch exchange (PBX).
VAIO Computer Quick Start New Connection Wizard Click Next. If the Location Information dialog box appears, follow the on- screen instructions. If it is not already selected, click to select Connect to the Internet, and click Next. Follow the on-screen instructions. Setting up an Ethernet Internet connection Your computer accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps, depending...
Page 31
To connect an Ethernet cable Locate the Ethernet port on your computer. For location information, see Locating Ports and Controls in the Setting Up chapter of your printed VAIO® Computer Quick Start. Connecting an Ethernet Cable E t h e r n e t p o r t Plug one end of the Ethernet cable into your computer’s Ethernet port and the other into the network connection.
VAIO Computer Quick Start New Connection Wizard Click Next. If the Location Information dialog box appears, follow the on- screen instructions. If it is not already selected, click to select Connect to the Internet, and click Next. Follow the on-screen instructions. Customizing your Internet connection The Internet Properties dialog box enables you to change the way you view the Internet.
Make sure the telephone number the program is dialing is correct. ❑ Make sure the software you are using is compatible with the computer’s modem. (All preinstalled Sony programs are compatible.) ❑ If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem driver software.
VAIO Computer Quick Start Network Connections With a Sony computer, you can easily set up or connect to a variety of networks. The New Connection Wizard and Network Setup Wizard make it easy to gain access to remote and local area networks (LANs) using wireless, Ethernet, or dial-up connections.
Page 35
accommodates both 10BASE-T and 100BASE-TX Ethernet connections, with data transfer speeds of between 10 and 100 Mbps, depending on the Ethernet cable. To set up an Ethernet LAN Plug one end of the Ethernet cable into your computer’s Ethernet port and the other into the network connection.
Page 36
VAIO Computer Quick Start The Network Setup Wizard Click Next. Follow the on-screen instructions. Only connect 10BASE-T and 100BASE-TX cables to the Ethernet port not connect any other type of network cable or any telephone cable. Connecting cables other than those listed above may result in an electric current overload and could cause a malfunction, excessive heat, or fire in the port.
Using wireless LAN connections A wireless local area network (LAN) is a network in which you can connect to a LAN through a wireless (radio) connection. You can opt to purchase a Sony Wireless LAN Access Point to set up a LAN.
Page 38
VAIO Computer Quick Start wireless LAN. The access point coordinates transmission and reception from multiple wireless devices within a specific range. ❑ A computer-to-computer (ad-hoc) network is one in which a local network is created only by the wireless devices themselves, with no other central controller or access point.
Page 39
Connecting to a Wireless LAN Select a network from the Available networks list box. Type the network key of the available network in the Network key box. See your network administrator for this information. Click Connect. To set up a wireless network Move the Wireless LAN switch to ON or insert a Wireless LAN PC Card into the PC Card slot.
Page 40
VAIO Computer Quick Start Setting Wireless Network Connection Properties Type up to 32 ASCII characters in the Network name (SSID) box. Click to select the Data encryption (WEP enabled) check box. Click to select the Network Authentication (Shared mode) check box. Click to cancel the The key is provided for me automatically check box.
Page 41
To set up a computer-to-computer (ad-hoc) network Move the Wireless LAN switch to ON or insert a Wireless LAN PC Card into the PC Card slot. See “Inserting PC Cards” for more information. The Wireless LAN indicator turns on. From the Start menu, click Control Panel, Network and Internet Connections, and then click Network Connections.
Page 42
VAIO Computer Quick Start Click to select the Network Authentication (Shared mode) check box. Click to cancel the The key is provided for me automatically check box. Type between 5 to 13 ASCII characters or 10 to 26 hexadecimal characters in the Network key box.
Checking your network connection status Whether you have a wireless, Ethernet, or dial-up connection, you can check the status of that connection by double-clicking the Wireless Network Connection icon on your taskbar. The Wireless Network Connection Status window appears. Wireless Network Connection Status Window Frequently asked questions Why can’t my computer connect to a wireless LAN access point? ❑...
Page 44
VAIO Computer Quick Start Right-click Wireless Network Connection, and select Properties. The Wireless Network Connection Properties dialog box appears. Select the Wireless Networks tab, and make sure the access point is displayed in the Available networks box. If it is not displayed, see “To connect to an existing wireless network”...
Page 45
Wireless LAN communication occurs on divided frequency bands known as channels. Third-party wireless LAN access point channels may be preset to different channels from Sony devices. If you are using a wireless LAN access point, refer to connectivity information contained in your access point instructions.
Click Network and Internet Connections, and click Set up or change your home or small office network. The Network Setup Wizard appears. * i.LINK is a trademark of Sony used to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software programs, operating system, and compatible i.LINK devices.
Page 47
The Network Setup Wizard window Follow the on-screen Network Setup Wizard instructions. When you are prompted, type in a unique computer name for each computer. You will use this unique name to differentiate the two computers once they are networked together. ✍...
Disconnect the i.LINK cable * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software applications, operating system, and compatible i.LINK devices.
Page 49
Connecting Another VAIO Computer and securely reconnect it to both computers. If neither computer responds after a few moments, restart both computers. ❑ If the computers do not recognize the i.LINK connection after resuming from a power saving mode (Standby or Hibernate), restart both computers. For more information, see “Connecting VAIO computers.”...
CDs and DVDs Your computer may come with an optical drive, depending on the model you purchased. If you purchased your VAIO® computer with an optical drive, you can use the drive to play or copy ❑ Inserting and Ejecting CDs or DVDs ❑...
VAIO Computer Quick Start Inserting and Ejecting CDs or DVDs ✍ Avoid using adhesive labels to identify your CDs or DVDs. Adhesive labels may damage the optical drive if they come off while the disc is in the drive. To insert a CD or DVD Turn on the computer or exit a power saving mode (Standby or Hibernate) if one is active.
Page 53
Inserting a Disc Press the disc onto the hub until the disc clicks securely into place. If you do not seat the disc firmly over the hub, the disc may come loose while it is in the drive. A loose disc may damage the optical drive and make opening the drive tray difficult.
VAIO Computer Quick Start Copying and Playing CDs You can use the optical drive installed in your computer to play CDs and copy files to CD-Rs and CD-RWs. ❑ Playing CDs ❑ Copying files to a CD-RW or CD-R ❑ Frequently asked questions Do not remove the optical drive when the computer is in a power saving mode (Standby or Hibernate).
❑ To increase volume, press the Fn+F4 keys. Press the Up Arrow key or the Right Arrow key ❑ To decrease volume, press the Fn+F4 keys. Press the Down Arrow key or the Left Arrow key ❑ Using the Volume icon. Double click the Volume icon Volume Control dialog box appears.
VAIO Computer Quick Start Connect the AC adapter to the computer. See “Connecting the AC adapter” for more information. Insert the disc into the optical drive. See “Inserting and Ejecting CDs or DVDs” for more information. Click Start, All Programs, and select the program you want to use from the submenu.
Page 57
Why can’t I view the entire DVD video display on a TV screen? The display resolution may not be properly set. To adjust the display resolution, see “Selecting a display mode” for more information. It is recommended that you adjust the display resolution to 1024 x 768 or smaller, depending on the size of the external display screen.
Page 58
VAIO Computer Quick Start ❑ If you are playing a CD or DVD and cannot hear sound, follow these steps: ❑ Double-click the Volume icon cancel the Volume Control and CD Audio Mute check boxes. ❑ Check the volume setting in the audio mixer. ❑...
Page 59
Why did the computer screen (LCD) go blank? ❑ Your computer screen may go blank if the computer has lost power or has entered a power saving mode (Standby or Hibernate). If the computer is in LCD (Video) Standby mode, press any key to activate the computer screen. See “Using power saving modes”...
Page 60
VAIO Computer Quick Start How do I switch the computer screen (LCD) from LCD to TV? Press Fn+F8 to select either the computer or TV display. See “Selecting a display mode” for more information. The Fn+F8 key combination will not work once a DVD is inserted into the optical drive.
Copying and Playing DVDs The type of optical drive installed in your computer may vary, depending on the model you purchased. Computers equipped with a CD-RW/DVD drive can play DVDs and can read most DVD-R media. Computers equipped with a DVD-RW drive can play and copy files to DVD-R and CD-R media.
Page 62
VAIO Computer Quick Start To play a DVD on the computer using battery power Set the power management profile to DVD. Close all open programs. Right-click the CPU icon Select Profiles from the shortcut menu, and then select DVD from the submenu.
Page 63
Connecting a TV A / V O U T j a c k Switch the TV input channel to external input. ✍ See the guide that came with your peripheral device for more information on its installation and use. Restart the computer by pressing Ctrl+Alt+Delete, and then selecting Restart from the Shut Down menu of the Windows Task Manager dialog box.
VAIO Computer Quick Start The Fn+F8 key combination will not work once a DVD is inserted into the optical drive. Switching the display while a DVD is playing may cause the computer to malfunction, and you may need to restart the DVD software. Set the power management profile to DVD, if you are using battery power.
You can copy files to a DVD-R or DVD-RW if your computer is equipped with a DVD-RW drive. Use the DVD-RW drive and the preinstalled Click to DVD or Drag’n Drop CD/DVD program to create your own DVDs. The Sony Click to DVD program is ideal for creating full-featured video DVDs, and the Drag’n Drop CD/DVD program is ideal for creating data DVDs.
Page 66
VAIO Computer Quick Start with water, wring it out well, and use it to wipe the surface of the disc from the center out. Wipe off any remaining moisture with a dry, soft cloth. ❑ Do not clean the disc with solvents (such as benzine, thinner, commercially available cleaners, or anti-static spray), which may damage the disc.
Page 67
Restart the computer by pressing Ctrl+Alt+Delete, and selecting Restart from the Shut Down menu of the Windows Task Manger dialog box. Remove the CD or DVD from the optical drive. Check the disc for dirt or damage. If you need to clean the disc, see “How do I maintain CDs and DVDs?”...
Page 68
VAIO Computer Quick Start ❑ If a region code warning appears, the disc may be incompatible with the optical drive. Check the DVD package to make sure the region code is compatible with the optical drive. ❑ If you notice condensation on the computer, do not use the computer for at least one hour.
Page 69
Right-click the desktop, and select Properties from the shortcut menu. The Display Properties dialog box appears. Select the Settings tab. Move the screen resolution slider to the left to reduce the size and to the right to increase the size of the video resolution. How do I switch the computer screen (LCD) from LCD to TV? Press Fn+F8 to select either the computer or TV display.
VAIO Computer Quick Start Printing With Your Computer You can connect a universal serial bus (USB) printer or a parallel port printer to your computer. To print properly, the printer you connect must be compatible with the Microsoft® Windows® operating system installed on your computer. ❑...
Page 73
Connecting a USB Printer Cable P o w e r c o r d ✍ See the guide that came with the USB printer for more information on its installation and use. To connect a parallel port printer Locate the Printer port Plug the printer cable into the Printer port Plug the other end of the printer cable into the port on the printer.
VAIO Computer Quick Start Connecting a Parallel Port Printer P r i n t e r p a r a l l e l p o r t ✍ See the guide that came with the parallel port printer for more information on its installation and use.
Page 75
Select the Port Settings tab, and select a different LPT Port Number. ❑ You may need to enable the computer’s printer settings. Click Start, and point to All Programs, Sony Notebook Setup, and click Sony Notebook Setup again. Click the Device tab.
Using the Keyboard ❑ Using the Touch Pad ❑ Using the Jog Dial Control ❑ Using Memory Stick Media ❑ Using the Multipurpose Bay ❑ Using the Multilingual User Interface Language Option ❑ Changing the Window Design of Sony Programs...
VAIO Computer Quick Start Using the Keyboard Your keyboard is very similar to a typewriter’s, but your computer keyboard has additional keys that perform specific computer-related tasks. ❑ Key locations and descriptions ❑ Combinations and functions with the Windows key ❑...
Page 79
Description Numeric keypad Contains the keys found on a typical calculator. Use the numeric keypad area to type numbers or to perform mathematical calculations such as addition and subtraction. Numbers appear on the front beveled edge of the numeric keys. Press the Num Lock key to activate the numeric keypad.
VAIO Computer Quick Start Description Windows key The key with the Microsoft® Windows® operating system logo displays the Start menu; it is the equivalent of clicking Start on the taskbar. See “Combinations and functions with the Windows key” for more information. Fn key The Fn key is used in combination with other keys to issue commands.
Combination Function Shift + Returns all minimized windows to their previous size. Displays the Run window. This is the equivalent of selecting Run from the Start menu. Fn + + Insert Displays the System Properties window. This is the equivalent of selecting Control Panel, and then System from the Start menu.
VAIO Computer Quick Start Indicator Function Caps Lock Turns on when the letters appear in uppercase as you type. The Shift key lowers the case of typed letters when Caps Lock is on. When the indicator is off, the letters appear in lower case as you type (unless you hold down the Shift key).
Page 83
Combinations/ Feature Function Fn + Toggles between the computer screen (LCD), a connected L C D (F7) external display, and both the LCD and external display. Switch to the external monitor/LCD Select one display at a time to playback DVDs. Connect the cable before you turn on the computer, otherwise Fn+F7 will not work.
VAIO Computer Quick Start Using the Touch Pad The keyboard contains a pointing device called a touch pad. You can point to, select, drag, and scroll objects on the screen using the built-in touch pad. ❑ Describing the touch pad ❑...
Customizing the touch pad Sony Notebook Setup lets you customize your touch pad, such as enable or disable the touch pad. You can also open the Mouse Properties dialog box, which enables you to set your touch pad and mouse preferences, such as changing pointers, enabling or disabling the tapping feature, clicking both buttons simultaneously, and adjusting the touch pad speed.
VAIO Computer Quick Start Press the Right Arrow key Press the Tab key to select the Default button, and press Enter. A pop-up window appears. Press the Left Arrow key Touchpad option is automatically selected. Press the Tab key to select the Apply button, and press Enter. Click OK.
Page 87
Why doesn’t the pointer move when I use the touch pad? ❑ Try restarting your computer. Follow these steps: Press the Windows key Press U. The Turn off computer window opens. Press R to restart the computer. ❑ If the computer does not restart, Press Ctrl+Alt+Delete simultaneously.
VAIO Computer Quick Start Using the Jog Dial Control Your computer is equipped with a Jog Dial™ Control and Jog Dial Navigator software, which enables you to scroll through programs, folders, and documents from a predefined list. The Jog Dial control and Jog Dial Navigator are compatible with preinstalled software programs that support Jog Dial Navigator functions.
To use the Jog Dial control ❑ Rotate the Jog Dial™ Control to scroll up and down a menu. ❑ Press the Jog Dial control to select a menu item. ❑ Press the Back button (on selected models) to return to the previous menu. ✍...
VAIO Computer Quick Start Features Jog Dial icon VAIO Settings button Jog Dial Settings button Close button Launcher button Mode button Help button To move, hide, or close the Jog Dial bar ❑ Click and drag the Jog Dial Bar to another location on the desktop. ❑...
Page 91
❑ Press and hold Ctrl, and then press the Jog Dial control. To open a program Open Jog Dial Launcher. See “To open Jog Dial Launcher” for more information. Rotate the Jog Dial control until the program you want to select appears highlighted in the center window.
Jog Dial Navigator operates in one of two modes: Scroll or Application. Once a program is open, you can easily switch modes. Mode Description Application Enables you to carry out commands for specific Sony programs. Scroll Enables you to scroll through an active window and the Start menu of specific Sony programs.
Page 93
Jog Dial Navigator windows Descriptions Guide Display Appears when a program that supports Jog Dial Navigator has audio features, such as volume control. This shows the operation guide for the Jog Dial control. List Display Appears when a program that supports Jog Dial Navigator is active.
VAIO Computer Quick Start Selecting Scroll Mode from Application Mode Changing Jog Dial Navigator settings You can change the Jog Dial Navigator settings to modify the Jog Dial Navigator functionality and appearance. To change settings Click the Jog Dial Setting button dialog box appears.
Page 95
Click the tabs near the top of the dialog box to view options, and then make your changes. Click Apply, and then click OK. For information about Jog Dial settings, right-click the Jog Dial Navigator icon on the taskbar, and click Help. Using the Jog Dial Control...
VAIO Computer Quick Start Using Memory Stick Media This compact, portable, and versatile recording medium has a data capacity exceeding that of a floppy disk. The medium is specially designed for exchanging and sharing digital data with compatible products. Because it is removable, the media can be used for external data storage.
✍ MG Memory Stick media has the MG mark. Inserting Memory Stick media Before using Memory Stick media, back up important data. The media slot accommodates only one Memory Stick media at a time. To insert Memory Stick media Insert the Memory Stick® media with the arrow facing up and toward the Memory Stick media slot.
Memory Stick media. From this window, you can choose to view, print, copy or organize your Memory Stick images or data. If the Sony Memory Stick window does not appear when you insert your Memory Stick media, then follow these steps: To view the contents From the Start menu, click My Computer.
From the Start menu, click My Computer. The My Computer window appears. Right-click Sony MemoryStick, and click Format from the menu. The Format Sony MemoryStick dialog box appears. Select Quick Format in the Format options box, and then click Start.
❑ Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources. Can I copy images from a digital video camera using Memory Stick media? Yes, and you can view video clips that you have recorded with Memory Stick media-compatible video camera recorders.
Page 101
❑ Do not bend, drop, or apply strong shock to the media. ❑ Do not disassemble or modify the media. ❑ Do not allow the media to get wet. How do I extend the life of the Memory Stick media? ❑...
VAIO Computer Quick Start Using the Multipurpose Bay You may install a variety of devices into the multipurpose bay to expand your computer’s functionality. The multipurpose bay supports the removable weight saver, floppy disk drive, compact woofer, or the internal numeric keypad (Ten- Key Bay unit) supplied with your computer.
Inserting a Device T e n - K e y B a y u n i t Removing a device To remove a device while the computer is off Slide and hold the multipurpose bay release switch in the release position while you gently pull the device from the bay.
VAIO Computer Quick Start ✍ If you do not plan to install another device into the multipurpose bay, insert the supplied weight saver to protect the bay. Do not store anything inside the weight saver. Items stored in the weight saver may break or make it difficult to remove the weight saver from the multipurpose bay.
Using the Multilingual User Interface Language Option (Microsoft® Windows® XP Professional only) After you have initially setup your new VAIO® computer, you can change the language displayed in Microsoft® Windows® XP Professional operating system. The multilingual user interface (MUI) language option changes the text controlled by Windows XP Professional operating system.
VAIO Computer Quick Start ✍ Additional users can also change to their desired language(s) without affecting your existing language settings. Changing Numbers, Currency, Time, and Date Formats You can change your operating system’s number, currency, time, and date formats to coordinate with your chosen country or language settings. To change these formats Click Start on the Windows taskbar, and then click Control Panel.
Click << or >> to view the designs. Click Apply to select a design that appears in the center window. The UI Design Selector window design changes. The window design for your Sony software will match the UI Design Selector window.
VAIO Computer Quick Start Using External Mice and Keyboards You can connect a universal serial bus (USB) mouse or keyboard to your computer. To function properly, the device you connect must be compatible with the Microsoft® Windows® operating system installed on your computer. For information about your computer’s built-in keyboard and key functions, see “Using the Keyboard”...
Connecting a USB Mouse or Keyboard U S B p o r t ✍ See the guide that came with your mouse or keyboard for more information on its installation and use. Disconnecting a mouse or keyboard You can disconnect a USB mouse or keyboard when the computer is on or off. Disconnecting the USB mouse or keyboard when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction.
Page 112
VAIO Computer Quick Start ❑ You may need to install or reinstall the mouse driver software. Use the supplied Application Recovery CD(s). See “Using the Application Recovery CD(s)” for more information. ❑ If you are playing a disc, press the Ctrl+Alt+Delete keys simultaneously to stop playback and restart the computer.
VAIO Computer Quick Start Using Floppy Disk Drives You can install a floppy disk drive into the multipurpose bay in your computer. The floppy disk drive enables you to read data stored on a floppy disk. ❑ Inserting and removing floppy disks ❑...
✍ To avoid losing data, do not push the Eject button when the LED indicator is on. Removing a Floppy Disk Notes on handling floppy disks ❑ Do not open the shutter manually and touch the surface of the floppy disk. ❑...
You can use Sony Notebook Setup to disable devices. To open Sony Notebook Setup Click Start on the Windows taskbar, and then click All Programs. Point to Sony Notebook Setup, and click Sony Notebook Setup. The Sony Notebook Setup dialog box appears. To insert a PC Card Make sure the front label of the PC Card is facing up.
Do not force a PC Card into the slot. It may damage the connector pins. When a PC Card is inserted, do not place your computer in a bag or case. Pressure or shock to a PC Card may damage your computer. Touching the head of the PC Card will not damage the connector pins, but damage may occur if the head of the PC Card is sticking out of the PC Card slot while the computer is being transported.
The PC Card drive enables you to read data stored on a DVD or CD. Your computer may come with an external PC Card drive, depending on the model you purchased. If you wish to purchase an optional PC Card drive, shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
Page 119
Remove the PC Card from the bottom of the optical drive. Removing a PC Card Insert the PC Card into the PC Card slot with the arrow facing the slot. See “To insert a PC Card” for more information. ✍ Remove the protective cover that is attached to the lens of the optical drive before you use the drive.
Make sure the PC Card is compatible with the Microsoft® Windows® operating system installed on your computer. ❑ Use the Sony Notebook Setup utility to disable devices you are not currently using. See “To open Sony Notebook Setup” for more information. ❑...
The Found New Hardware window appears on the lower right corner of your screen. * i.LINK is a trademark of Sony used to designate that a product contains an IEEE 1394 connector. The i.LINK connection may vary, depending on the software application, operating system, and compatible i.LINK devices.
Using a digital video camera recorder Your computer comes with preinstalled driver software that is compatible with most Sony digital video camera recorders. If you purchased a camera that comes with its own driver software, install these drivers before you use the camera.
See “Connecting an i.LINK digital video recorder” for more information. * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software applications, operating system, and compatible i.LINK devices.
Using Computer Monitors and Projectors You can connect an external display (such as a computer monitor or a projector) to your computer. ❑ Connecting a computer monitor ❑ Connecting a multimedia computer monitor ❑ Connecting a projector ❑ Selecting a display mode ❑...
VAIO Computer Quick Start Connecting a Computer Monitor M o n i t o r ( V G A ) p o r t Connecting a multimedia computer monitor A multimedia computer monitor has built-in speakers and/or a microphone device. Before you can connect your computer to a multimedia computer monitor, it must have an A/V OUT jack.
Connecting a Multimedia Computer Monitor A / V O U T j a c k ✍ See the guide that came with your multimedia computer monitor for more information on its installation and use. Connecting a projector You can use a projector to display the actions and images on the computer screen (LCD).
VAIO Computer Quick Start Press the Fn+F7 key combination to toggle the display between your computer and the projector. See “Selecting a display mode” for more information. Connecting a Projector V G A p o r t D i s p l a y c a b l e ( n o t s u p p l i e d ) ✍...
Page 129
Shortcut keys Result Toggles between the computer screen (LCD), a connected (F7) external display (projector or computer monitor), and both the LCD and external display. Select one display at a time. Connect the cable before you turn on the computer, otherwise Fn+F7 will not work. only/ Toggles between the computer screen (LCD-only), TV-only, (F8)
Page 130
VAIO Computer Quick Start Mobility Radeon Properties window Click the selection tab located just above the display graphic to activate the display panel. Click the Primary icon display choice to change the display settings. Click Apply. For more information, click Help. ✍...
Using Computer Monitors and Projectors Disconnecting a computer monitor or projector You can disconnect the external computer monitor or projector by unplugging the display or Monitor (VGA) cable from your computer’s port. Disconnecting the external display when the computer is in a power saving mode (Standby or Hibernate) may cause the computer to malfunction.
If you want to purchase speakers, make sure the speakers are designed for computer use. You can shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer. ❑...
Connecting External Speakers ✍ See the guide that came with your speakers for more information on its installation and use. Disconnecting external speakers You can disconnect external speakers when the computer is on or off. Simply unplug the speaker cable from the Headphone jack Notes on using the speakers ❑...
Page 134
VAIO Computer Quick Start To adjust the volume using the Volume icon Right-click the Volume icon Volume Control. The Volume Control window appears. Click and drag the Volume Control slider up to increase volume and down to decrease volume. Click to cancel any Mute check boxes that are selected. Sound device Volume Control Wave...
To adjust the volume using the volume dial control ❑ Rotate the volume dial control clockwise to increase the volume. ❑ Rotate the volume dial control counterclockwise to decrease the volume. When you use the Volume icon volume dial control volume. Unlike the Volume icon, the volume dial control adjusts only the sound level from the speakers or headphones.
Page 136
VAIO Computer Quick Start ❑ If you have connected an audio cable to the Headphone jack, disconnect the cable and use the speaker cable that was supplied with the speakers. ❑ You may need to install or reinstall speaker driver software. Use the Application Recovery CD(s) to reinstall the drivers.
Page 137
Why do I hear noise distortion while listening to music with speakers or headphones? You may experience noise distortion while listening to music with speakers or headphones if the CPU control is set to Automatic Profile Selection. Use the preinstalled PowerPanel™ program to set the CPU control to Performance or Battery Life.
Page 138
VAIO Computer Quick Start ❑ You can also press Fn+F4 to increase the volume. If you double-click the Volume icon on the Windows® taskbar, you can view your changes on the Volume Control window. ✍ The Volume icon and Fn+F4 and Fn+F3 key combinations will work only when the volume dial control is set to an audible level.
You can connect an external microphone to your computer to enhance the sound input to your computer. Make sure your microphone is designed for computer use. If you wish to purchase a microphone, shop Sony online at http://www.sonystyle.com/vaio or contact your local retailer.
VAIO Computer Quick Start Using a microphone or other device to record You can record messages, memos, or other recordings in analog by connecting a microphone or other audio device to the Microphone jack and switching the jack functionality. The Microphone jack (monaural).
Using Microphones Frequently asked questions Why doesn’t my microphone work? If you are using an external microphone, make sure the microphone is properly plugged into the Microphone jack on the computer. See “Connecting a microphone” for more information.
VAIO Computer Quick Start Software Programs On Your Computer Your computer may not be supplied with all of the programs listed in “Program overview”, depending on the configuration you purchased. Preinstalled software may not be identical to retail versions or include supporting documentation. ❑...
Page 145
Click to DVD™ Sony Electronics Inc. At the touch of a button, Click to DVD software enables you to automatically burn DVDs from videos or still pictures. Create DVDs by capturing video content straight from a digital video (DV) device or stored video files —...
Page 146
VAIO Computer Quick Start DVgate™ Sony Electronics Inc. Connect a compatible digital video camera to your computer’s i.LINK® port and capture video clips and still images. You can edit clips from your video, add new clips, and combine clips into new movie segments. You can also save your images in a variety of popular file formats.
Page 147
Network Smart Capture Sony Electronics Inc. .Network Smart Capture captures images and video from any Sony Digital Camcorder that supports a standard i.LINK connection. Send your video or still images through e-mail or upload them to the ImageStationSM service. You can use the Web camera function to automatically upload your captured images.
Page 148
Sony Electronics Inc. PictureGear Studio image management software displays images from your hard drive or a Sony digital still camera. The images appear in a convenient light-table format, so that you can easily view the contents of an entire folder and create your own photo albums and make prints.
Page 149
Internet content. Sony on Yahoo! Yahoo! Inc. Personalize your own Web portal with Sony on Yahoo! Get a free Web mail account, customized news and local weather reports, comics, instant messaging, and more.
VAIO Computer Quick Start VAIO Support Agent Sony Electronics Inc. VAIO Support Agent provides immediate, interactive, online support with information about your preinstalled software and answers to frequently asked questions. WinDVD® InterVideo, Inc. WinDVD 2000 software is a simple-to-use DVD player that offers all the features...
Page 151
Software Programs On Your Computer Which program do I use for CD-R/CD-RW functions? Use the preinstalled Sony SonicStage program and Windows® software to create CDs on your VAIO® computer, if the specific model you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability.
VAIO Computer Quick Start DVgate Program Notes ❑ Recording images to a digital video device ❑ Adjusting image resolution ❑ Saving to your hard disk drive Recording images to a digital video device If your system displays the message, “Failed to record to DV deck, please check deck’s power status, cable connection…,”...
Page 153
To defragment a partition Back up all files you want to save. From the Start menu on the Windows® taskbar, point to All Programs, Accessories, System Tools, and then click Disk Defragmenter. The Disk Defragmenter dialog box appears. Select the drive you want to defragment from the list, and click Defragment. See the Microsoft®...
VAIO Computer Quick Start Program Support Information ❑ Sony Service Center Adobe® Acrobat® Reader®, Photoshop® Elements, Premiere® LE (Adobe Systems Inc.) Web site http://www.adobe.com/ e-mail techdocs@adobe.com telephone 206-675-6126 (fee-based support) 206-628-5737 hours M-F, 6 A.M.-5 P.M. (Pacific time) America Online® (America Online, Inc.) Web site http://www.aol.com/...
Page 155
888-4-SONY-PC (888-476-6972) hours 7 days a week, 24 hours a day * Support from 1-888-4-SONY-PC is free of charge for 90 days after the original date of purchase. Windows® Operating System, Word, XP Professional, XP Small Business (Microsoft Corp.) Web site http://www.sony.com/pcsupport...
VAIO Computer Quick Start WinDVD® (InterVideo, Inc.) Web site http://www.intervideo.com telephone 510-651-0888 Yahoo! (Yahoo! Inc.) Web site http://help.yahoo.com/ Sony Service Center For the Sony Service Center nearest you, call 1-888-4-SONY-PC (1-888-476-6972) or find Sony Customer Service on the Web at http://www.ita.sel.sony.com/support.
Sony recommends that memory upgrades be performed by an authorized Sony Service Center. To find the nearest center or agent, go to: http://www.sony.com/pcsupport.
❑ Do not open the memory module package until you are ready to install the module. The package protects the module from ESD. ❑ Use the special protective package to store a memory module and prevent ESD or use anti-static wrap. Typical expansion memory configuration Total System Memory (MB) Removing and installing memory modules...
Page 160
VAIO Computer Quick Start Removing the Bottom Screws Touch a metal object (such as the connector panel on the back of your computer) to discharge static electricity. Remove the memory module by pulling out the tabs (see arrows No. 1), and pulling out the module in the direction of arrow No.
Do not touch any part of the motherboard or the other components inside the computer. Installing a New Memory Module Snap the connectors into place when the board is correctly seated, and close the computer cover. Replace the fastening screws on the bottom of the computer. Make sure the system memory matches the amount of installed memory.
Page 162
Click Start on the Windows® taskbar, point to All Programs, and then point to Sony Notebook Setup. Select Sony Notebook Setup from the submenu. The Sony Notebook Setup dialog box appears. On the About This Computer tab, make sure the System Memory displayed in the System Information box matches the amount of memory installed.
Recovery CDs. You will need an optical drive to use these recovery CDs. If your computer does not come with an optical drive, use an external optical drive. Application Recovery CD(s) Sony Electronics Inc. This CD enables you to reinstall individual software programs and device drivers if they become corrupted or are erased.
Page 165
When the Windows® desktop appears, insert Sony Application Recovery CD No. 1 into your computer’s optical drive. The Application Recovery utility loads automatically. Click OK in the VAIO welcome window. The Sony Application Recovery Program window appears. Double-click the Software folder icon.
16 Turn off your computer by clicking Start, and then Turn off computer. 17 Wait 30 seconds, and turn on your computer. If you have any questions about using the Application Recovery CD(s), visit http://www.sony.com/pcsupport, or contact Sony Customer Support at 1-888-4- SONY-PC. Using the System Recovery CD(s) The System Recovery CD(s) enables you to format your hard disk and restores all original software programs.
Page 167
Your system may take a few minutes to load necessary files. A blue screen may appear during the downloading process. Insert the Sony System Recovery CD in the optical drive. The first CD must be in the drive before you restart your computer.
Page 168
Press the power button and hold it for more than four seconds to turn off the computer. Turn on the computer. When the Sony logo is displayed, press the F2 key. The BIOS Setup Utility appears. Press the right arrow key Press the down arrow key The Setup Confirmation window appears.
Troubleshooting and Support This section describes how to solve common problems you may encounter when using your computer. Many problems have simple solutions, so try these suggestions before you contact Sony Computing Support (http://www.sony.com/pcsupport). ❑ Troubleshooting Your Computer ❑ Troubleshooting Batteries ❑...
VAIO Computer Quick Start Troubleshooting Your Computer Why doesn’t my computer start? ❑ Make sure the computer is securely plugged into a power source and is on. Make sure the power indicator shows the power is on. See “Connecting the AC adapter”...
Page 171
Select Yes, and press Enter. The computer restarts. ✍ If this occurs on a regular basis, contact Sony Computing Support (http://www.sony.com/pcsupport). Why does the message, “Operating system not found” appear when my computer starts, and why won’t Windows start? ❑...
Page 172
VAIO Computer Quick Start 10 Select Exit (Save Changes), and press Enter. The Setup Confirmation window appears again. 11 Select Yes, and press Enter. The computer restarts. If your computer continues to display the message “Operating system not found,” and Windows does not start, use your supplied System Recovery CD(s) to restore the software titles shipped with your computer.
Page 173
Close all open programs. Restart the computer by pressing Ctrl+Alt+Delete simultaneously. The Windows Task Manager dialog box appears, and you can restart the computer from the Shut Down menu. If this procedure does not work, press and hold the power button to turn off the computer.
VAIO Computer Quick Start Troubleshooting Batteries How do I know when the battery is charged? To determine the remaining battery charge, see “Displaying battery information.” When is the computer using AC power? When the computer is directly connected to the AC adapter, it uses AC power, even if a battery is installed.
Select the Port Settings tab, and select a different LPT Port Number. ❑ You may need to set or reset your computer’s printer settings. Click Start, and point to All Programs, Sony Notebook Setup, and click Sony Notebook Setup again. Click the Device tab.
Page 176
VAIO Computer Quick Start In the left panel, make sure the Printer Port check box is selected, and click Setting. In the Printer port mode box, click the ECP option. Click OK.
Troubleshooting the Mouse and Touch Pad Why doesn’t the computer recognize the USB mouse? ❑ Make sure the mouse is securely plugged into the USB port. See “Connecting a mouse or keyboard” for more information. ❑ You may need to install or reinstall the mouse driver software. Use the supplied Application Recovery CD to install the drivers.
Page 178
VAIO Computer Quick Start Press the Windows appears. Click the Tools menu, and select Folder Options. The Folder Options dialog box appears with the General tab open. In the Click items as follows box, click to select Single-click to open an item (point to select).
Make sure the telephone number the program is dialing is correct. ❑ Make sure the program you are using is compatible with the computer’s modem. (All preinstalled Sony programs are compatible.) ❑ If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem driver software.
VAIO Computer Quick Start Troubleshooting Networks Why can’t my computer connect to a wireless LAN access point? ❑ Connection availability is affected by distance and obstructions. You may need to move your computer away from obstructions or closer to any access point you may be using.
Page 181
the data transfer speed, move your computer away from obstructions or closer to any access point you may be using. ❑ If you are using a wireless LAN access point, the device may be temporarily overloaded depending on the number of other devices communicating via the access point.
Page 182
(Standby or Hibernate), restart both computers. For more information, see “Connecting Another VAIO Computer.” * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software programs, operating system, and compatible i.LINK devices.
Troubleshooting DVDs and CDs How do I maintain DVDs? ❑ Avoid touching the surface of the disc with your fingers. Fingerprints and dust on the surface of the disc may cause reading errors. ❑ To clean the disc, hold the edge of the disc, and use a soft cloth to wipe the surface from the center out.
Page 184
VAIO Computer Quick Start Why isn’t the optical drive playing my CD or DVD properly? ❑ Make sure the disc label is facing up. ❑ If the disc requires software, make sure the software is installed according to the manufacturer’s instructions. ❑...
Page 185
Click the Properties tab, and click to select the Enable digital CD audio for this CD-ROM device check box. Why did the computer screen (LCD) go blank? ❑ Your computer screen may go blank if the computer has lost power or is in a power saving mode (Standby or Hibernate).
Page 186
VAIO Computer Quick Start How do I switch the computer screen (LCD) from LCD to TV? Press Fn+F8 to select either the computer or TV display. See “Selecting a display mode” for more information. The Fn+F8 key combination will not work once a DVD is inserted into the optical drive.
Make sure the region code listed on the DVD package is compatible with the drive. * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software programs, operating system, and compatible i.LINK devices.
VAIO Computer Quick Start Troubleshooting Floppy Disk Drives Why doesn’t the Safety Remove Hardware icon the drive is connected? The computer does not recognize that the floppy disk drive is connected to the computer. First, make sure the USB connector is properly inserted into the USB port.
Make sure the PC Card is compatible with the Microsoft® Windows® operating system installed on your computer. ❑ Use the Sony Notebook Setup utility to disable devices you are not currently using. See “To open Sony Notebook Setup” for more information. ❑...
See that program’s help file for more information. * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software applications, operating system, and compatible i.LINK devices.
Page 191
❑ Your speakers may be set to mute, the volume setting may be too low, or the audio option may be disabled. See “Adjusting the volume” and “Enabling the audio feature” for more information. Why don’t the Fn+F3 or the Fn+F4 key combinations work? The computer may not recognize the Fn+F3 and Fn+F4 key combinations if the correct speakers are not selected.
Page 192
VAIO Computer Quick Start Close the Profile Editor window. Why doesn’t my volume control dial work? ❑ Your volume control dial will work only when the Volume icon an audible level. Use the Volume icon to increase the volume. Double-click the Volume icon window appears.
Troubleshooting the computer screen (LCD) Why did the computer screen (LCD) go blank? ❑ Your computer screen may go blank if the computer has lost power or is in a power saving mode (Standby or Hibernate). ❑ Make sure the computer is plugged into a power source and is on. The power indicator on the computer will be on if the computer is on.
Page 194
VAIO Computer Quick Start How do I switch the computer screen (LCD) from LCD to TV? See “Selecting a display mode” for instructions on how to switch the display mode to LCD and TV.
❑ Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources. Can I copy images from a digital video camera using Memory Stick media? Yes, and you can view video clips that you have recorded with Memory Stick media-compatible video camera recorders.
Page 196
VAIO Computer Quick Start ❑ Do not bend, drop, or apply strong shock to the media. ❑ Do not disassemble or modify the media. ❑ Do not allow the media to get wet. How do I extend the life of the Memory Stick media? ❑...
See “Using the Multipurpose Bay” for more information. Which program do I use for CD-R/CD-RW functions? Use the preinstalled Sony SonicStage™ software and Windows® software to create CDs on your VAIO® computer, if the specific model you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability.
VAIO Support Agent You can find VAIO Support Agent by clicking Start and selecting Help and Support. Using advanced diagnostic technology, Sony’s VAIO Support Agent runs scheduled protections of your programs, network settings, and other important program settings. When your program is protected, you can use VAIO Support Agent to repair program problems by restoring the program to any of the previously protected states.
Page 199
AC adapter connecting AC Profile power setting adding memory Application Recovery CD Applications key arrow keys audio connecting microphone connecting speakers audio-video (AV) connecting i.LINK battery power saving modes battery pack notes battery packs charge status icons charging indicator lights removing brightness 11, 82...
Page 200
VAIO Computer Quick Start computer connecting computers online support troubleshooting connecting coin-operated telephones computers dial-up digital video recorder Ethernet floppy disk drive hard drives i.LINK device Internet microphone multimedia computer display multiple phone lines network party phone lines printer projector speakers telephone line controls...
Page 202
VAIO Computer Quick Start Caps Lock hard disk Memory Stick Num Lock Scroll Lock Wireless LAN installing hard drives Internet connecting jacks modem Jog Dial Control Jog Dial Navigator Indicate window Launcher window settings key locations keyboard 80, 82 key combinations key locations using 59, 68, 185, 193...
Page 204
VAIO Computer Quick Start using ports printer power power button Power Management Off power setting power saving modes 20, 83 Hibernate Standby power setting AC Profile Maximum Battery Life Maximum Performance Power Management Off power source battery packs Print Screen key printer connecting port...
Page 205
System Recovery CD telephone connecting line jack touchpad disable enable troubleshooting using troubleshooting Memory Stick media mouse and touchpad printer printer using PC Card video camera volume speakers window design of Sony software Windows Find window help Windows key...
Page 206
VAIO Computer Quick Start combinations and functions Wireless LAN indicator light...
Need help?
Do you have a question about the PCG-NV290 VAIO and is the answer not in the manual?
Questions and answers
