Page 1 Welcome Congratulations on your purchase of this Sony VAIO This User Guide provides detailed information on all aspects of using your new VAIO computer, from keyboard functions to preinstalled software applications. In the left navigation window, click the topics you want to learn more about, and that information will be displayed in this main window.
Page 2: Using Your Vaio Computer
Using Your VAIO Computer This section describes the following aspects of your new computer:  Using the Keyboard  Using the Touchpad  Using the Center Jog Dial Control  Using the Optical Disc Drive  Using PC Cards  Using Memory Stick Media ...
Page 3: Using The Keyboard
Using the Keyboard Your computer's keyboard is very similar to that of a typewriter, but the keyboard has additional keys that perform specific computer-related tasks. Keyboard Description Numeric keypad Contains the keys found on a typical calculator. Use the numeric keypad area to type numbers or to perform mathematical calculations such as addition and subtraction.
Page 4 of clicking the right mouse button. Page 4...
Page 5 Combinations and functions with the Windows key Combination Function + F1 Displays the VAIO Help and Support Center window. + Tab Switches the selected button on the taskbar. Displays the desktop. Displays the My Computer window. Displays the Search window to find a file or folder. This is the equivalent of selecting Search from the Start menu.
Page 6 Indicators Indicator Function Power Light is green when the power to the computer is turned on, flashes amber in Standby mode, and turns off when the computer is in Hibernate mode or powered off. Battery Indicates the status of the battery inserted in the battery bay. Memory Stick Indicates that the Memory Stick Hard disk...
Page 7 Indicator lights Light Num Lock The number keys in the numeric keypad are active. active. Caps Lock The letters appear in uppercase as you type. The Shift key lowers the case of typed letters when Caps Lock is on. Letters appear in lower case as you type (unless you hold down the Shift key). Scroll Lock The screen scrolls differently.
Page 8 Combinations and functions with the Fn key If you switch user identities during a computing session, the Fn+F7 and Fn+F8 key functionality (if available on your computer) will be interrupted. To switch to an external display or monitor, see information. Combinations/ Feature Function...
Page 9 Standby Puts the system into Standby mode, a power management state. To return the system to the active state, press any key. You can also carry out these functions using the center Jog Dial Control. Some functions are not available until Windows launches.
Page 10: Using The Touchpad
Using the Touchpad The keyboard contains a cursor-pointing device called a touchpad. You can point to, select, drag, and scroll objects on the screen using the built-in touchpad. Touchpad Action Description Point Slide one finger on the touchpad to place the pointer on an item or object. Click Press the left button once.
Page 11: Vaio Action Setup
N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 12: Using The Center Jog Dial Control
Using the Center Jog Dial Control Your computer is equipped with a center Jog Dial Control located below the left and right buttons. The center Jog Dial Control enables you to open an application, folder, or document from a predefined list by rotating and pressing the center Jog Dial Control.
Page 13 Using the center Jog Dial Control This section explains how to use the center Jog Dial Control. For information on how to change the settings of the center Jog Dial Control, right-click the Jog Dial Utility icon in the taskbar and click Help Topics. Page 13...
Page 14 Launcher mode The center Jog Dial Control window is in launcher mode until a software application is launched or the Jog Dial Control window becomes active. When you select an item in the Jog Dial Control window and it is displayed between orange bars, you can press the center Jog Dial Control to view a submenu of that item.
Page 15 Guide mode The Jog Dial Control window is in the guide mode when software is in use and the software window is active. Depending on the software you are using, you can select items from the displayed list using the center Jog Dial Control. You can switch between guide mode and launcher mode by pressing the Ctrl key and the center Jog Dial Control.
Page 16 Center Jog Dial back button The center Jog Dial Control includes a back button located to the right of the control. Pressing this button brings you back to the previous screen. Page 16...
Page 17 Using the center Jog Dial Control with Sony software If Sony software that supports the center Jog Dial Control is active, you can use the functions of the center Jog Dial Control that are allocated to that software. For more information on functions allocated to software, see the software application's Help.
Page 18 Using the center Jog Dial Control with other software If the software you are using supports the center Jog Dial Control, you can still use the center Jog Dial Control to scroll the window or adjust the window size. Using a Dialog box When a window such as Screen Properties is active, the Dialog box is displayed in the Jog Dial window.
Page 19: Using The Optical Disc Drive
Using the Optical Disc Drive Your computer comes with an optical disc drive, which is located on the right panel of the computer. See the Specifications sheet for the particular drive installed on your computer. Page 19...
Page 20 To insert a disc Turn on the computer. When the computer is in Standby or Hibernate mode, you cannot insert a disc. See Management for more information on Standby and Hibernate modes. Press the Eject button to open the optical disc drive. The tray slides out. Ejecting the Tray Avoid using adhesive labels to identify your discs.
Page 21 To eject a disc When you finish using a disc, wait until the LED indicator turns off, and then press the Eject button to remove the disc. When the computer is in a power saving mode, you cannot remove an optical disc. See Controlling Power Management more information about power saving modes.
Page 22 To play a DVD To play a DVD, you may use the optical disc drive and the preinstalled WinDVD Help menu in the WinDVD application. Before you use the optical disc drive to play a DVD, quit any open applications. Your optical disc drive can read most DVD-R media.
Page 23 To play an audio CD To play an audio CD, make sure the audio function is turned on. To do this, complete the following procedure. Click Start, and click Control Panel, and Performance and Maintenance, and System. The System Properties window appears.
Page 24 Notes on CD and DVD discs  Do not drop or bend the disc.  Do not touch the surface of the disc. Fingerprints and dust on the surface of a disc may cause reading errors. Proper care of the disc is essential to maintain its reliability. Do not use solvents such as benzine, thinner, commercially available cleaners or anti-static spray, as they may cause damage to the disc.
Page 25 To write data to a CD-RW or CD-R disc You can use Sony SonicStage and Microsoft that is readable in a CD-ROM drive, make sure that you finish the writing process before ejecting the disc. For more information, see the instructions included with Windows Do not strike or shake the computer while writing data to a disc.
Page 26: Using Pc Cards
Using PC Cards Do not strike or shake the computer while writing data to a disc. Always use the AC adapter as the power source for your computer if you are writing data to a CD-RW or CD-R disc. Using battery power may result in data transfer failure. Your computer includes two PC Card slots.
Page 27 To insert a PC Card Insert the PC Card into the PC Card slot. Make sure the front label of the PC Card is facing up. Inserting a PC Card Push the PC Card gently into the slot. The PC Card is automatically detected by your system. The Eject Hardware icon appears in the taskbar.
Page 28 Restart your system to correct the problem.  Some PC Cards may require that you disable idle devices when using the PC Card. You can use Sony Notebook Setup to disable devices. See ...
Page 29: Using Memory Stick Media
Using Memory Stick Media This compact, portable, and versatile recording medium has a data capacity exceeding that of a floppy disk. The medium is specially designed for exchanging and sharing digital data with compatible products. Because it is removable, the media can be used for external data storage.
Page 30 To view the contents of Memory Stick media Click Start in the Windows taskbar and then click My Computer Double-click Sony Memory Stick under the Devices with Removable Storage box. The Sony Memory Stick window opens. To remove Memory Stick media Make sure the Memory Stick media indicator is off.
Page 31 Be careful when removing the Memory Stick media, as it may eject completely from the slot. M agic Gate M emory Stic k and are trademarks of Sony C orporation. M emory Stic k and are trademarks of Sony C orporation.
Page 32 Write-protecting Memory Stick media Memory Stick media is designed with a write-protect tab to protect valuable data from accidental erasure or overwriting. Move the tab to the right or left to set or release write-protection. Write-protect off Data can be saved on the Memory Stick media. Write-protect on Data can be read from but not saved on the Memory Stick media.
Page 33 Insert the Memory Stick media into the computer. See Click Start in the Windows taskbar, and click My Computer. Under Devices with Removable Storage, right-click Sony Memory Stick - MG, and select Format. The Format Sony Memory Stick - MG dialog box appears.
Page 34  Sony is not responsible for music files that cannot be recorded from a CD or downloaded from other sources.  Formatting Memory Stick media erases all data (including music data) previously saved to it. Before you format Memory Stick media, confirm that the media does not contain files you want to keep.
Page 35: Using The Multipurpose Bay
Using the Multipurpose Bay You may install a variety of devices into the multipurpose bay to expand your computer's functionality. The multipurpose bay supports the removable weight saver, floppy disk drive, compact woofer, or the internal numeric keypad (Ten-Key Bay unit). You may install only one device at a time.
Page 36 To install a device while the computer is on or off Before you install a compact woofer, prop up the rear tilt stands on the bottom of the computer to maximize woofer performance. Remove any device that is already installed in the bay. See remove a device while the computer is on Slide the device, such as the weight saver, into the multipurpose bay until it clicks into place.
Page 37 To remove a device while the computer is off Slide and hold the multipurpose bay Release switch in the release position while you gently pull the device from the bay. Multipurpose Bay Release Switch If you do not plan to install another device into the multipurpose bay, insert the supplied weigh saver to protect the bay.
Page 38 To remove a device while the computer is on Before disconnecting the device, close any active applications to help prevent data loss. Double-click the Safely Remove Hardware appears. In the Hardware devices box, click the device you want to remove, and click Stop. The Stop a Hardware device window appears.
Page 39 Notes on using a device in the multipurpose bay Do not place the compact woofer near any magnetic recording media, such as a hard disk, floppy disk, or mini disk. The woofer's magnetic field may damage the data stored on this type of media. ...
Page 40: Using The Floppy Disk Drive
Using the Floppy Disk Drive Whether you installed the supplied floppy disk drive into the multipurpose bay or connected an external floppy disk drive to the computer, you will find that both floppy disk drives are similar and easy to use. Page 40...
Page 41 To insert a floppy disk into the floppy disk drive Hold the floppy disk with the label facing up. Gently push the floppy disk into the drive until it clicks into place. Inserting a Floppy Disk Page 41...
Page 42 To remove a floppy disk from the floppy disk drive Close all applications that were opened from the disk and wait for the LED indicator to turn off. Rem ov ing a Floppy Disk Push the Eject button, and remove the disk. Do not push the Eject button when the LED indicator is turned on;...
Page 43 Notes on handling floppy disks  Do not open the shutter manually and touch the surface of the floppy disk.  Keep floppy disks away from magnets.  Keep floppy disk away from direct sunlight and other heat sources. Page 43...
Page 44: Using Power Saving Modes
Using Power Saving Modes When you use a battery as the source of power for your computer, you can take advantage of power management settings to conserve battery life. In addition to the normal operating mode, which allows you to turn off specific devices, your computer has two distinct power saving modes: Standby and Hibernate.
Page 45 Normal mode Normal mode is the normal state of your computer when it is in use. The power indicator displays green when your computer is in this mode. To save power, you can turn off a specific device such as the LCD or the hard disk drive. Page 45...
Page 46 Standby mode In Standby Mode the computer saves the current state of the system in RAM and switches off power to the CPU. The amber power indicator flashes in this mode. To activate Standby mode Press the key combination Fn + Esc. To return to Normal mode Press any key to return to Normal mode.
Page 47 Hibernate mode In the Hibernate mode, the state of the system is saved on the hard disk drive and power is turned off. The power indicator is off in this mode. To activate Hibernate mode Press the key combination Fn + F12, or press the power button and release it immediately. The computer enters Hibernate mode.
Page 48 Notes on power saving modes  When returning from Hibernate mode, the system status stored on the hard disk is erased and the computer starts normally if you press the power button and hold it for more than four (4) seconds. ...
Page 49 You need to connect a telephone cable to take advantage of online services and the Internet. In order to register your Sony VAIO computer, register your software online, and use Sony Customer Support, you must connect to a telephone cable.
Page 50: Connecting To A Local Area Network
Connecting to a Local Area Network You can connect your computer to 10BASE-T and 100BASE-TX-type Local Area Networks (LANs). For the detailed settings and devices needed to connect to the network, ask your network administrator. Connecting to LAN Warning: Only connect 10BASE-T and 100BASE-TX cables to the Ethernet port.
Page 51 Setting up your Ethernet connection To connect to the network Click Start on the Windows ® In the Other Places box on the left, click My Network Places. In the Network Tasks box, click Add a network place or click Set up a home or small office network, depending on your configuration.
Page 52: Connecting To A Wireless Lan
Connecting to a Wireless LAN Your computer may come with a built-in mini PCI card that allows for wireless connections. With Sony's Wireless Local Area Network (LAN) functionality, all compatible digital devices can communicate freely without cable connections. A Wireless LAN is a network in which a mobile user can connect to a LAN through a wireless (radio) connection.
Page 53 Turning On Wireless LAN To enable Wireless LAN functionality, first locate the Wireless LAN switch on the top right corner of the computer. Move the switch to the ON position. The Wireless LAN indicator lights up. Connecting to a Wireless LAN Page 53...
Page 54 You can also connect an access point to a telephone line, Integrated Services Digital Network (ISDN) router, cable modem, or Digital Subscriber Line (xDSL) modem to share access to the Internet among multiple computers. Com m unicating v ia Wireless LAN Access Point For information on available Sony products, go to: http://www.sonystyle.com/vaio. Page 54...
Page 55 Communicating with an Access Point (infrastructure) An extended network infrastructure is one that extends an existing wired local network to wireless devices by providing an access point. The access point bridges the wireless and wired LAN and acts as a central controller for the Wireless LAN. The access point coordinates transmission and reception from multiple wireless devices within a specific range.
Page 56 Communicating without an access point (ad-hoc) An ad-hoc network is one in which a local network is created only by the wireless devices themselves, with no other central controller or access point. Each device communicates directly with other devices in the network. You can set up an ad-hoc network easily at home, either with a network key for added security or without a key.
Page 57 Click OK. Click Advanced. The Advanced dialog box appears. Select "Computer-to-computer (ad hoc) networks only.", and click Close. Select a network from the Preferred networks list, and click OK. To connect to an existing network Locate the Wireless LAN switch, and move the switch to the ON position. Click the Wireless Network Connection window appears.
Page 58 Checking your connection status To confirm your connection status with an access point Right-click the Wireless Network Connection icon on the Windows taskbar. Click Status in the pop-up menu. The Wireless Network Connection Status window appears. Page 58...
Page 59 Turning Off Wireless LAN To turn off Wireless LAN functionality Turning off Wireless LAN functionality while accessing remote documents, files, or resources may result in data loss. Close all files that you are accessing through the network connection. Locate the Wireless LAN switch, and move the switch to the OFF position. The Wireless LAN indicator switches off.
Page 60 Notes on using Wireless LAN  Sony Wireless LAN devices support the IEEE 802.11b standard. Devices connecting to a Wireless LAN using the IEEE 802.11a standard cannot connect to devices using the IEEE 802.11b standard.  Wireless LAN communication occurs on divided frequency bands known as channels. Third-party Wireless LAN Access Point channels may be preset to different channels from Sony devices.
Page 61: Connecting Peripheral Devices
Connecting Peripheral Devices You can add functionality to your notebook by connecting a variety of peripherals, as discussed in the following sections:  Connecting a USB Device  Connecting a USB Printer  Connecting a Parallel Port Printer  Connecting an Audio Device ...
Page 62: Connecting A Usb Device
Connecting a USB Device You can connect a universal serial bus (USB) device, such as a external mouse, keyboard, speaker, and microphone to your computer. However, make sure the USB device you want to connect is compatible with the Windows operating system ®...
Page 63 USB device, if it is not already connected. You can use a Sony USB mouse (not supplied) with this computer. The USB mouse software driver is preinstalled, however, the first time you connect a mouse, on-screen installation instructions may appear. Press Enter to complete the on-screen instructions.
Page 64: Connecting A Usb Printer
Connecting a USB Printer You can connect a universal serial bus (USB) printer to your computer. However, make sure the USB device you want to connect is compatible with the Windows operating system installed on your computer. ® Page 64...
Page 65 To use a printer, you may need to install the driver software that came with your printer. Connecting a USB Printer See the manual that came with your printer for more information on its installation and use. Displaying the Sony Notebook Setup Screen Page 65...
Page 66: Connecting A Parallel Port Printer
Connecting a Parallel Port Printer You can connect a parallel port printer to your computer. However, make sure the parallel port printer you want to connect is compatible with the Windows operating system installed on your computer. ® Page 66...
Page 67 See the manual that came with your printer for more information on its installation and use. If your printer stops functioning after resuming from a power saving mode, see information. Displaying the Sony Notebook Setup Screen Troubleshooting the Printer for more...
Page 68: Connecting An Audio Device
Connecting an Audio Device You can connect an audio device to your computer using mini-plug cables shorter than 2 meters with no resistance. Page 68...
Page 69 To connect an audio device Plug one end of an audio cable (not supplied) into the Headphone jack on the computer. Plug the opposite end of the audio cable into an audio output device, such as a CD player, active speaker, or amplifier.
Page 70: Connecting An Audio-Video Device
Connecting an Audio-Video Device You can connect an audio-video (AV) device, such as a TV or a VCR, to your computer. Page 70...
Page 71 To connect an AV device Locate the AV Out jack on the left panel of the computer. Plug one end of an audio-video cable (not supplied) into this jack, and plug the opposite end of the cable into the audio-video device. Make sure you switch the TV input channel to external input and set up the TV configuration system.
Page 72 To change the display If you insert a DVD in your optical disc drive to watch on your TV, the Fn+F8 key combination might not activate the function to toggle between your LCD and TV. Follow these steps. Connect the TV to the computer. Restart the computer and wait until it finishes rebooting.
Page 73: Connecting An I.link Audio-Video Device
N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tor. T he i.LI...
Page 74 To connect a digital video camera recorder Plug one end of the i.LINK cable (not supplied) into the i.LINK ® Plug the opposite end of the i.LINK cable into the DV IN/OUT port on the digital video camera recorder. Connecting Digital Video Cam era Recorder to i.LINK Port port on the left panel of the computer.
Page 75 Notes on connecting an i.LINK device  Only the Sony digital video camera port labeled DV IN/OUT or i.LINK are i.LINK-compatible.  Do not connect more than one digital video camera at a time. The software supplied with your computer will not recognize multiple cameras.
Page 76: Connecting An External Display
Connecting an External Display You can connect any of the following external displays to your computer.  Computer display (monitor)  Multimedia computer display  Projector Page 76...
Page 77 To connect a computer display Turn off the computer before you connect the computer display. Locate the VGA (Monitor) Plug the display cable (not supplied) into the VGA (Monitor) port. Verify that the power cord is plugged into the computer display and an AC outlet. Turn on all external devices before turning on the computer.
Page 78 To connect a multimedia computer display Turn off the computer before you connect the multimedia computer display. Locate the AV Out jack on the left panel of the computer. Plug one end of the display cable (not supplied) into the AV Out jack, and plug the opposite end of the display cable into the multimedia computer display.
Page 79 To connect a projector Turn off the computer before you connect the projector. Locate the VGA (Monitor) Plug one end of the display cable (not supplied) into the VGA port, and plug the opposite end into the appropriate port on the projector. Plug one end of the audio cable (not supplied) into the Headphone jack, and plug the opposite end into the appropriate port on the projector.
Page 80 Changing the display when connecting an external computer display or projector When you connect an external display to the VGA (Monitor) port, you can toggle the output between the Liquid Crystal Display (LCD), the external monitor, or both devices. Press the Fn+F7 key combination to select a display. See Selecting the Display Mode for more information.
Page 81: Connecting With Another Vaio Computer
N K is a trademark of Sony us ed to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 82 Connect one end of the i.LINK cable to the i.LINK port on each computer. To connect VAIO computers that do not have the latest Windows necessary. Consult the Sony Web site for support options (http://www.sony.com/pcsupport). operating system, Smart Connect software may be ®...
Page 83: Connecting External Speakers
Connecting External Speakers You can enhance the sound quality of your computer by connecting external speakers (not supplied). Do not place floppy disks on the speakers. The speakers' magnetic field may damage the data on the floppy disks. Page 83...
Page 84 To connect external speakers Make sure that your speakers are designed for computer use. Turn down the volume of the speakers. Locate the Headphone jack on the left panel of the computer. Plug one end of the speaker cable (not supplied) into the Headphone Connecting External Speakers to the Headphone Jack See the manual that came with your speakers for more information on its installation and use.
Page 85 Notes on connecting external speakers  Do not connect external speakers to the AV Out jack. Connecting speakers to this jack will not damage the speakers, but only one speaker will function.  Do not use the external speakers and the compact woofer at the same time. Using both devices at the same time does not enhance sound quality.
Page 86: Connecting An External Microphone
Connecting an External Microphone You can enhance the quality of sound input by using an external microphone (not supplied). Page 86...
Page 87 To connect an external microphone Make sure that your microphone is designed for computer use. Locate the Microphone jack on the left panel of the computer. A protruding dot above the Microphone jack distinguishes this jack from the Headphone Plug one end of the microphone cable (not supplied) into the Microphone Connecting External Microphone to the Microphone Jack See the manual that came with your microphone for more information on its installation and use.
Page 88 To record from a microphone or audio device You can record messages, memos, or other recordings in analog by connecting a microphone or other audio device to the Microphone jack of your computer and switching the jack's functionality. The Microphone jack is for MIC IN (monaural). Double-click the Volume icon on the taskbar.
Page 89 Adjusting the volume You can adjust the volume for playing or recording, but you can only adjust the recording volume in the Recording Control window. If you adjust the volume, the adjustment is only effective for playing sound. It does not adjust the volume for recording sound.
Page 90: Expanding Your Computer Capabilities
Expanding Your Computer Capabilities You can connect the following peripheral devices to your computer to expand its capabilities and enhance its versatility to meet your needs:  A Personal Digital Assistant (PDA)  A Wireless LAN Access Point  A Wireless LAN PC Card Page 90...
Page 91 Personal Digital Assistant A handheld PDA is the quintessential personal planner and entertainment center that fits in your pocket. With a PDA, you can easily perform the following functions:  Enter your schedule details in the calendar and view them by the day, week, or month, and even set an alarm to remind you of important events.
Page 92 Wireless LAN Access Point The Wireless LAN Access Point is designed for building a wireless Local Area Network (LAN) environment. You can easily build a wireless LAN environment by plugging the access point into an AC power outlet and using a card that allows for wireless connections with the provided software.
Page 93 LAN between computers that are equipped with the Wireless LAN PC Card and gain access to the Internet. Without the access point, you can achieve direct communication (Peer-to-Peer mode) between computers. For more information on Sony Wireless LAN, go to http://www.sonystyle.com/vaio. Page 93...
Page 94: Customizing Your Vaio Computer
Customizing Your VAIO Computer The following sections briefly describe how to change your notebook's default settings.  Displaying the Sony Notebook Setup Screen  Controlling Power Management  Displaying Battery Information  Selecting the Display Mode  Using the Multilingual User Interface Language Option...
Page 95: Displaying The Sony Notebook Setup Screen
To display the Sony Notebook Setup screen: Click Start on the Windows ® Click Performance and Maintenance, and then Sony Notebook Setup. Sony Notebook Setup Screen Select the tab for the item you want to change. See After you finish making your changes, click OK.
Page 96 To display the Sony Notebook Setup screen: Click Start on the Windows ® Click Performance and Maintenance, and then Sony Notebook Setup. Sony Notebook Setup Screen Select the tab for the item you want to change. See After you finish making your changes, click OK.
Page 97 Advanced on the Basic/Advanced tab. Basic/Advanced Switch between Advanced mode (additional screens with advanced settings) and Basic mode of display. For more information about each option, click Help on the Sony Notebook Setup screen to display the Help file. Page 97...
Page 98: Controlling Power Management
Controlling Power Management The PowerPanel utility allows you to control the power management of your notebook and provides key information about system activity and battery life. The following sections briefly describe how to conserve your computer's battery power. You can also refer to PowerPanel Help for more detailed information. To activate a profile or command, see Displaying Battery Information for more information.
Page 99 Viewing the Power Management status icons The Power Management status icons are displayed in the taskbar at the lower-right corner of your screen. Move the pointer over the Battery icon to see the tool tip that displays information about the active profile. Double-click the icon for additional information.
Page 100 Power Management profiles The PowerPanel utility provides several predefined power management profiles. Each profile consists of a group of power management settings that are designed to meet specific power management goals — ranging from maximum power management to no power management. You can change the settings for any of the predefined profiles (except for the Disable Power Management profile), or you can create your own profile to suit your portable computing needs.
Page 101 Page 101...
Page 102 Power Management commands PowerPanel also provides power management commands that you can use to activate specific power management functions and to control power for a specific device. You can use these commands to override a profile setting or initiate an immediate action.
Page 103 Conserving battery power When using your notebook with a battery, the LCD display and the hard drive can be set to switch off automatically to conserve battery power. Power Management profiles for more information. Page 103...
Page 104: Displaying Battery Information
Displaying Battery Information You can display information for each of the batteries in your notebook. The following sections briefly describe how to display your notebook's general battery information. Refer to PowerPanel Help for more detailed information. To activate the Battery Information toolbar Right-click on the Windows taskbar at the bottom of the screen.
Page 105 Battery icon descriptions Battery icon Battery status Charging Fully charged Discharging No battery Page 105...
Page 106 Displaying detailed battery information Double-click the battery icon on the taskbar to display the Battery Information window. The Battery tab contains information such as battery charging time and duration of the battery charge. Battery Inform ation Window Customizing the Battery Information toolbar and alarm system You can customize the Battery Information toolbar and modify the alarm settings, to suit your portable computing needs.
Page 107: Selecting The Display Mode
Selecting the Display Mode This notebook uses the ATI video controller. You can select which display is used when the notebook is connected to an external monitor. When you connect an external display, you can switch the display mode between your notebook's LCD display and the external monitor.
Page 108 Double-click UI Design Selector. Click and select the desired design. Click Apply. The "UI Design Selector" window design changes. The window design for your Sony software will match the "UI Design Selector" window. To try another selection, click This feature is available with UI Design Selector-compatible software only.
Page 109 Display Properties Notes If you change the factory display screen settings to 1600 x 1200 pixels, you can increase the display font size as well. To increase the display font size Click Start, point to Control Panel, and click Appearance and Themes. Click Display.
Page 110: Using The Multilingual User Interface Language Option
Using the Multilingual User Interface Language Option (Windows XP Pro only) After you have initially setup your new VAIO computer, you have the ability to change the language ® displayed in Microsoft Windows XP Professional operating system. The multilingual user interface (MUI) language option ®...
Page 111 To Change the Language Option Click Start in the Windows taskbar, then click Control Panel. Click "Date, Time, Language and Regional Options", then click Regional and Language Options. The Regional and Language Options dialog box appears. Select the Languages tab. From the "Language used in menus and dialogs"...
Page 112 To Change Numbers, Currency, Time, and Date Formats You can change the system's number, currency, time and date formats to coordinate with your chosen country or language settings. To change these formats, follow the steps below: Click Start in the Windows taskbar, then click Control Panel. Click "Date, Time, Language and Regional Options", then click Regional and Language Options.
Page 113: Adding Memory
Adding Memory In the future you may want to install memory modules to expand the functionality of your computer. See the Specifications sheet supplied with your computer for the amount of preinstalled memory. Expansion memory modules are available as options. For memory upgrades and information on which memory modules to use, refer to the Specifications sheet. This section provides you with information on removing and replacing a memory module.
Page 114: Precautions And Procedures
Precautions and Procedures The procedures described below assume that you are familiar with the general terminology associated with personal notebooks and with common safety practices required for using and modifying electronic equipment. Personal injury or equipment damage may result from failure to take these precautions. Make sure you observe the proper safety precautions when you install memory modules in your notebook.
Page 115: Typical Expansion Memory Configuration
Typical Expansion Memory Configuration Models with 256 MB Memory Total System Memory (MB) Slot 1 (MB) Slot 2 (MB) Page 115...
Page 116 Typical Expansion Memory Configuration Models with 256 MB Memory Total System Memory (MB) Slot 1 (MB) Slot 2 (MB) Page 116...
Page 117: Removing A Memory Module
Removing a Memory Module Your computer may come with two memory modules already installed in the memory bay. To upgrade your memory, you may need to remove a module before you can install an upgrade memory module(s). To install an upgrade memory module into an empty slot, see Turn off the computer and disconnect all peripheral devices, such as your printer.
Page 118: Installing A Memory Module
Installing a Memory Module Your computer may come with one memory module installed. To upgrade your computer's overall memory capacity, you can install a second memory module into the empty slot. If two memory modules are already installed in the memory bay and you want to install an upgrade memory module(s), see Removing a Memory Module Follow steps 1 to 5 of...
Page 119: Confirming Added Memory Capacity
The amount of memory displayed in the Sony Notebook Setup window is not always correct. The video adapter may use some system memory, and that amount of memory does not appear as part of the total memory shown in the Sony Notebook Setup window.
Page 120: About The Software On Your Notebook
About the Software on Your Notebook Your VAIO computer is ready to help you work, play, learn, and communicate as soon as you turn it on. This section ® provides you with information on the wide variety of software applications installed on your computer: ...
Page 121: Software Overview
DigitalPrint Sony Electronics Inc. This image management software makes it fun and easy to edit, import, and organize your digital pictures in a photo album for rich digital printing to any standard color laser or ink-jet printer. DigitalPrint can also be used to make custom CD labels for your audio CDs.
Page 122 Sony Electronics Inc. Sony's original MovieShaker software creates personal movies that have transitions, background music, and text. Just import your video clips and "shake" with a click of the mouse. Your personal movies are easy to create and fun to share with family and friends.
Page 123 Sony Pictures Digital Entertainment Sony ScreenBlast Sound Forge allows you to record, edit, and process mono or stereo audio files for your multimedia or Internet projects. Whether you want to use a number of professional effects, convert video into streaming media, or synchronize audio to video —...
Page 124: Software Support Information
Systems Inc.) Web site http://www.adobe.com e-mail techdocs@adobe.com telephone 206-675-6126 (fee-based support) 206-628-5737 hours M-F, 6 A.M.-5 P.M. (Pacific time) EverQuest (Sony Online Entertainment Inc.) ® Web site(s) http://www.everquest.com e-mail eqtech@soe.sony.com telephone 858-831-9143 hours M-F, 8:30 A.M.-5:30 P.M. (Pacific time) Microsoft Windows Operating System, Office XP, Word (Microsoft Corp.)
Page 125 (RealNetworks, Inc.) ® Web site http://service.real.com/rjoptions.html e-mail http://service.real.com/help/call.html Sony Applications (Sony Electronics Inc.) Web site http://www.sony.com/pcsupport telephone 888-4-SONY-PC (888-476-6972) hours 7 days a week, 24 hours a day Support from 1 -8 8 8 -4 -SO N Y -P C is free of c harge for 9 0 days after the original date of purc has e.
Page 126 Sony Service Center For the Sony Service Center nearest you, call 1-888-4-SONY-PC (1-888-476-6972) or find Sony Customer Service on the Web at http://www.sony.com/pcsupport. Page 126...
Page 127: Using The Recovery Cds
Using the Recovery CDs This section provides you with details on your Sony Application Recovery and System Recovery CDs.  Application and System Recovery CDs  Using Your Recovery CDs Page 127...
Page 128: Application And System Recovery Cds
(supplied with selected models) to use these recovery CDs. If your computer does not come with an optical disc drive, use an external optical disc drive. Application Recovery CD(s) Sony Electronics Inc. This CD enables you to reinstall individual applications and device drivers if they become corrupted or are erased. System Recovery CD(s) Sony Electronics Inc.
Page 129: Using Your Recovery Cds
Using Your Recovery CDs The following sections describe how to use the Application Recovery and System Recovery utilities. Page 129...
Page 130 Reinstalling software applications with the Application Recovery CD(s) Turn on your computer. If your computer is already on, close all open applications. When the Windows desktop appears, insert Sony Application Recovery CD No. 1 into your computer's optical disc drive. The Application Recovery utility loads automatically.
Page 131 Your system may take a few minutes to load necessary files. A blue screen appears during the downloading process. Insert the Sony System Recovery CD in the optical disc drive. The System Recovery utility starts from the optical disc drive. The first CD must be in the drive when your turn on the computer.
Page 132 Your system may include one or more System Recovery CDs. If you have more than one System Recovery CDs, insert the first CD to run the System Recovery program. You are prompted to insert the second CD once the information from the first CD has been installed.
Page 133: Troubleshooting
Troubleshooting This section describes how to solve common problems you may encounter when using your computer. Many problems have simple solutions, so try these suggestions before you contact Sony Computing Support (http://www.sony.com/pcsupport). Consult the following sections:  Troubleshooting Your Computer ...
Page 134: Troubleshooting Your Computer
Troubleshooting Your Computer My computer does not start.  Make sure the computer is plugged into a power source and is turned on.  Make sure the power indicator shows the power is on.  Make sure the battery packs are inserted properly and are charged. ...
Page 135 Troubleshooting Your Computer My computer does not start.  Make sure the computer is plugged into a power source and is turned on.  Make sure the power indicator shows the power is on.  Make sure the battery packs are inserted properly and are charged. ...
Page 136 Make sure Exit (Save Changes) is selected, and press Enter. The Setup Confirmation window appears. Make sure Yes is selected, and press Enter. The computer restarts. If this occurs on a regular basis, contact Sony Computing Support (http://www.sony.com/pcsupport). key to select Get Default...
Page 137 Turn off the computer. Remove any peripheral devices connected to the computer. Restart the computer. Press F2 when the Sony logo appears. The BIOS setup menu window appears. Press the Right Arrow Press the Down Arrow default values for all SETUP items" appears.
Page 138 My computer stops responding or does not shut down. It is best to turn off your computer using the Turn Off Computer command on the Windows Start menu. Using other methods, including those listed below, may result in loss of unsaved data. ...
Page 139 The power management does not respond. Your computer's operating system may become unstable if a lower power state, such as Hibernate, is initiated and changed before the computer completely enters the lower power state. To restore the computer to its normal operating stability Close all open applications.
Page 140 The sound of my computer's fan is too loud. Use the PowerPanel utility to change the Thermal Control Strategy setting to Quiet. This setting slows down the CPU speed. See PowerPanel Help for more information. To reduce fan noise Right-click the CPU: Performance Profile Profile Editor window appears.
Page 141 Why does the System Properties dialog box display a slower CPU speed than advertised? This is normal. Because your computer's CPU uses a type of CPU speed controlling technology, System Properties may display the CPU's current speed instead of the maximum advertised speed. Page 141...
Page 142: Troubleshooting The Lcd Screen
Troubleshooting the LCD Screen My LCD screen is blank.  Verify the computer is plugged into a power source and is turned on.  Verify the power indicator on the computer is on.  Verify the battery packs are inserted properly and are charged. ...
Page 143 Troubleshooting the LCD Screen My LCD screen is blank.  Verify the computer is plugged into a power source and is turned on.  Verify the power indicator on the computer is on.  Verify the battery packs are inserted properly and are charged. ...
Page 144 My LCD screen continues to show the previous screen. Press the Windows key and D twice to refresh the screen. Page 144...
Page 145 The image on my connected external display is not centered or sized properly. Use the controls on your external display to adjust the image. See the manual that came with your display for more information. Page 145...
Page 146 I want to change the video resolution of my display. Click Start on the taskbar, and then Control Panel. Click Appearance and Themes, and then click the Display icon. The Display Properties dialog box appears. Click the Settings tab. Move the Screen resolution slider to change your video resolution, and click Apply and OK. Page 146...
Page 147 I want to change the display resolution for AV Out. Make sure your computer was started with the AV Out jack plugged in. Click Start on the taskbar, and then Control Panel. Click Appearance and Themes, and then click the Display icon. The Display Properties dialog box appears. Click the Settings tab.
Page 148 I cannot switch the LCD display to TV and vice versa. Ensure that the TV was connected, configured, and powered on correctly prior to starting the computer. See Connecting an Audio-Video Device Remove the DVD video disc if it is inserted in the optical drive. Press Fn+F8 to change the display.
Page 149: Troubleshooting The Mouse And Touchpad
Troubleshooting the Mouse and Touchpad My mouse does not work.  Make sure the mouse is securely plugged into the USB port. See  If you are still experiencing problems, use your supplied Application Recovery CD to reinstall the mouse drivers. See To use the Application Recovery CD(s) Connecting a USB Device for more information.
Page 150 Troubleshooting the Mouse and Touchpad My mouse does not work.  Make sure the mouse is securely plugged into the USB port. See  If you are still experiencing problems, use your supplied Application Recovery CD to reinstall the mouse drivers. See To use the Application Recovery CD(s) Connecting a USB Device for more information.
Page 151 You may have disabled the touchpad without connecting a mouse to the computer. To enable the touchpad: Press the Windows key, and then press the Up Arrow Press the Down Arrow Make sure Sony Notebook Setup is selected, and press Enter. Press the Right Arrow Press the Tab key to select Enable Touchpad, and press Enter.
Page 152 The pointer does not move when I use the Touchpad or Mouse.  You should restart your computer. Follow these steps: Press the Windows key. Press U. The Turn off computer window opens. Press R to restart the computer.  If the computer does not restart, Press Ctrl+Alt+Delete simultaneously.
Page 153: Troubleshooting Drives, Pc Cards, And Peripheral Devices
Troubleshooting Drives, PC Cards, and Peripheral Devices My floppy disk drive icon doesn't appear even though it is connected.  Make sure the floppy disk drive is properly connected. Wait a few moments for the computer to recognize the drive. ...
Page 154 Troubleshooting Drives, PC Cards, and Peripheral Devices My floppy disk drive icon doesn't appear even though it is connected.  Make sure the floppy disk drive is properly connected. Wait a few moments for the computer to recognize the drive. ...
Page 155 My floppy disk drive cannot write to a floppy disk.  If the floppy disk is write-protected, disable the write-protect feature or use a floppy disk that is not write-protected.  Make sure a formatted floppy disk is properly inserted into the floppy disk drive. Page 155...
Page 156 My optical drive is not playing my CD or DVD properly.  Make sure the disc label is facing up.  If the disc requires software, make sure the software is installed according to the manufacturer's instructions.  A dirty or damaged disc may cause the computer to stop responding while it tries to read the disc. If necessary, restart the computer, remove the disc, and check the disc for dirt or damage.
Page 157 Why does it take longer for the optical disc drive to read some types of CDs? The reading speed for a CD-RW is slower than the reading speed for a CD-ROM or CD-R because these discs are formatted differently. Page 157...
Page 158 My optical drive tray does not open.  Make sure the computer is turned on.  Press the Eject button on the optical drive.  If the Eject button does not work, open the tray by inserting a thin, straight object (such as a paper clip) in the hole to the right of the Eject button.
Page 159 N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 160 Make sure the PC Card is installed properly.  Make sure the PC Card is compatible with the Microsoft  Use the Sony Notebook Setup utility to disable devices you are not currently using.  Make sure any necessary drivers were installed properly. See information.
Page 161: Troubleshooting The Software
Troubleshooting the Software My software program stops responding or crashes. Contact the software publisher or designated provider for technical support. See Software Support Information for contact information. Page 161...
Page 162 Troubleshooting the Software My software program stops responding or crashes. Contact the software publisher or designated provider for technical support. See Software Support Information for contact information. Page 162...
Page 163 When I click an application icon, the message "You must insert the Application CD into your optical drive" appears, and the software does not start.  Some titles require specific files that are located on the Application Recovery CD. Insert the disc, and try starting the program again.
Page 164 The application cannot find a file while a PC Card is inserted. When inserted into a computer that is connected to the docking station, some PC Cards may change the drive letters of the disk drives in the docking station. If this occurs, an application you are using may not be able to find files. To correct this condition, do one of the following: ...
Page 165 What software do I use for CD-R/CD-RW software functions? Using the preinstalled SonicStage software's Record function to create CDs on your VAIO computer, if the specific model ® you purchased is preconfigured with all of the necessary components for CD-R and CD-RW capability. Page 165...
Page 166 I cannot use the DVgate software. If your computer is using the Ultimate Battery Life profile for its power saving mode, you cannot use DVgate or Smart Connect software. Please select another profile. Preferably, connect your computer to AC power when using these features.
Page 167: Troubleshooting I.link Devices
N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 168 N K is a trademark of Sony us ed only to des ignate that a produc t c ontains an I E E E 1 3 9 4 c onnec tion. T he i.LI...
Page 169: Troubleshooting The Modem
 Make sure the telephone number the program is dialing is correct.  Make sure the software you are using is compatible with the computer's modem. (All preinstalled Sony programs are compatible.)  If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem drivers.
Page 170  Make sure the telephone number the program is dialing is correct.  Make sure the software you are using is compatible with the computer's modem. (All preinstalled Sony programs are compatible.)  If you are still experiencing problems, use the supplied Application Recovery CD(s) to reinstall the modem drivers.
Page 171 My modem connection is slow. Your computer is equipped with a V.90 compatible modem. Many factors may influence modem connection speed, including telephone line noise or compatibility with telephone equipment (such as fax machines or other modems). If you think your modem is not connecting properly to other PC-based modems, fax machines, or your Internet service provider (ISP), do the following: ...
Page 172: Troubleshooting Audio
Troubleshooting Audio My speakers have no sound.  If the built-in speakers are turned off, press Fn+F3 or use the center Jog Dial  If the speaker volume is turned to the minimum, press Fn+F4, and then press Up Arrow increase the volume.
Page 173 Troubleshooting Audio My speakers have no sound.  If the built-in speakers are turned off, press Fn+F3 or use the center Jog Dial  If the speaker volume is turned to the minimum, press Fn+F4, and then press Up Arrow increase the volume.
Page 174 There is noise distortion while listening to music with USB speakers or USB headphones. Use the preinstalled PowerPanel Right-click the CPU: Performance Profile The Profile Editor dialog box appears. In the left portion of the window, click the power management profile you want to set. Maximum Battery Life is the default selection when your computer runs on battery power.
Page 175 My microphone does not work. If you are using an external microphone, make sure the microphone is plugged into the Microphone jack. See Connecting an External Microphone for more information. Page 175...
Page 176: Troubleshooting Memory Stick Media
I cannot open image files.  If the Sony MemoryStick dialog box does not appear when you first insert a Memory Stick media, you can: Click Start, and then My Computer. The My Computer window appears. Click the Sony MemoryStick icon. If your images are not stored in a folder, your images should appear in the Sony MemoryStick window.
Page 177 I cannot open image files.  If the Sony MemoryStick dialog box does not appear when you first insert a Memory Stick media, you can: Click Start, and then My Computer. The My Computer window appears. Click the Sony MemoryStick icon. If your images are not stored in a folder, your images should appear in the Sony MemoryStick window.
Page 178 Memory Stick media does not work. I cannot access the removable drive. To locate the Memory Stick media icon in your My Computer folder Click the View menu, and select Refresh. Wait a few moments for the computer to recognize the Memory Stick media. Click the Sony MemoryStick icon. Page 178...
Page 179: Troubleshooting Wireless Lan Functions
Troubleshooting Wireless LAN Functions The computer cannot connect to a Wireless LAN Access Point. Connection availability is affected by distance and obstructions. You may need to move your computer away from obstructions or closer to any access point you may be using. ...
Page 180 Troubleshooting Wireless LAN Functions The computer cannot connect to a Wireless LAN Access Point. Connection availability is affected by distance and obstructions. You may need to move your computer away from obstructions or closer to any access point you may be using. ...
Page 181 I cannot access the Internet.  Make sure the Wireless LAN switch on the computer is in the ON position or the Wireless LAN PC Card is properly inserted.  Check the access point settings. Refer to the instructions supplied with the access point. ...
Page 182 The data transfer speed is slow.  The Wireless LAN data transfer speed is affected by distance and obstructions between devices and access points. Other factors include device configurations, radio conditions, and software compatibility. To maximize the data transfer speed, move your computer away from obstructions or closer to any access point you may be using. ...
Page 183 The communication speed is interrupted or slowed down when MPEG2 data is transferred. The typical effective data transfer speed via an access point is 4-5 Mbps when adhering to the IEEE 802.11b standard. High-rate stream transfers with MPEG2 data may lower this rate. Page 183...
Page 184 Data transfers are interrupted. Data transfer interruptions may occur with large files or use of microwaves and cordless telephones when connected to an access point. To avoid data transfer interruptions  Move the computer closer to the access point.  Make sure the access point connection is intact.
Page 185: Troubleshooting The Printer
Troubleshooting the Printer I cannot print.  Make sure the printer is on, and the printer cable is securely connected to both the printer and your computer.  Make sure the printer is compatible with the Windows the correct printer drivers. ...
Page 186 Troubleshooting the Printer I cannot print.  Make sure the printer is on, and the printer cable is securely connected to both the printer and your computer.  Make sure the printer is compatible with the Windows the correct printer drivers. ...
Page 187: Getting Help
Getting Help Sony provides you with several support resources to answer questions about your VAIO computer or the preinstalled ® software. Refer to these resources in the order they are listed. Page 187...
Page 188: Support Options
Sony Computing Support This service provides instant access to information on commonly encountered problems. Enter a description of your problem and the Knowledge Database searches for the corresponding solutions online. You can access Sony Computing Support at: http://www.sony.com/pcsupport. Sony Fax-on-Demand This service, which requires a fax machine or your fax software, provides answers to commonly asked questions.
