- Page 1 LINUS System Quickstart LINUS Live v.1.2.0 Beta 2017_01_20...
- Page 2 Hadware Setup 1. Verify Master - Slave configuration in LINUS Rack 20/40 Start the Rack configuration before any frontpanel connected cables! Master Slave Master Slave Master Slave SENSOR 1+2 ±1 AMP 1-A ±1 AMP 2-A SENSOR 3+4 INPUT A LINK A INPUT B LINK B ±2 AMP 1-B...
- Page 3 Hadware Setup 2. Module Number assignment 1# Master 1# Slave (follows) 2# Master 2# Slave (follows) 3# Master 3# Slave (follows) SENSOR 1+2 ±1 AMP 1-A ±1 AMP 2-A SENSOR 3+4 INPUT A LINK A INPUT B LINK B ±2 AMP 1-B ±2 AMP 2-B PUSH PUSH...
-
Page 4: Network Setup
Network Setup 1. Configure Network Structure Wire your racks with ethernet cables (PRIM/ SEC) Example shows Daisy Chain Topology (other Network topologies possible) Set Static IP: IP:192.168.1.20 SN: 255.255.0.0 LINUS Rack 20 LINUS Rack 40 INPUT B INPUT A LINK A LINK B PUSH PUSH... - Page 5 Network Setup 2. Scan Network Start LINUS Live and Press Device Scan process will start: You will find a clear indication of available units in the network. If the Scan result do not match with your hardware, check the setup of devices and network mentioned previously. Master Module Number (#1) IP:xxx.xx.xx.01...
-
Page 6: Software Setup
Software Setup 1. Scan Network/ Update Start LINUS Live and Press The Device Scan process window informs you about a new (in Linus Live implemented) FirmWare for the scanned devices You now need to upload the FirmWare of the connected devices! Press „Add“... - Page 7 Software Setup 2. Firmware Update -Select all modules (from the same type) -Press „Firmware“ and „Upload Firmware“ Wait until the Firmware Upload is completed! LINUS Live will close and LINUS 10 will reboot automatically after the Firmware update has been completed. Note! Do not update more than 8x LINUS10 Units at any one time!
- Page 8 Software Setup 3. Scan Network/ Update Start LINUS Live and Press The Device Scan process window informs you about a new (in Linus Live implemented) Preset Library for the scanned devices You now need to upload the Preset Library of the connected Devices! Press „Add“...
- Page 9 Software Setup 4. Library Update -Select all modules (from the same type) -Press „Library“ and „Upload Library“ Wait until the Library Upload is completed! LINUS Live will close automatically after the Library Update has been completed.
- Page 10 Software Setup 5. Updated Environment Start LINUS Live and Press The Device Scan process window informs you about an updated Device environment You can start now with LINUS Live operation. Please refer to the „LINUS Startup“ manual for further information...
- Page 11 Preset Builder 1. Scan Network/ Update Start LINUS Live and Press Once you have designed a new Custom Preset with the Preset Builder Application, which is available in LINUS Live, you will need to upload the Preset Library on all the devices in your system setup! The Device Scan process window informs you that the detected devices in the network have got a Mixed User Library You now need to upload the Preset Library of the connected Devices!
- Page 12 Preset Builder 2. Preset Builder Library export/ import The Preset Builder application is automatically generates a new „Key“ file after saving the User Default Library and closing LINUS Live! If any change is applied, you will generate a new „Key“ file. The „Key“...
-
Page 13: Restore System
Restore System 1. Restore a preconfigured System on one Computer If you have designed a System online and have not changed any parameters or system configuration, you can restore the system at anytime on the same computer (e.g. if network has failed or in the case of power shut down) Start LINUS Live and Press If the preconfigured configuration hasn‘t been changed you can restore the System setup! - Page 14 Restore System 2. Restore a preconfigured System on a different Computer You need to import the used preset Lib Key from the original computer where the system setup has been created. Please refer to Page 12, Import function !!! IMPORTANT !!! Restart LINUS Live Software after Key File import Start LINUS Live and Press Now you will be able to restore the system setup on a different...
- Page 15 Restore System 3. Conclusion Sync function is only possible if same key files are used on both Computer and LINUS hardware INPUT A LINK A INPUT B LINK B SENSOR 1+2 ±1 AMP 1-A ±1 AMP 2-A SENSOR 3+4 ±2 AMP 1-B ±2 AMP 2-B PUSH PUSH...
