  • Page 1 FET PHONO PREAMPLIFIER 06x OPERATION MANUAL 06x FET PHONO PREAMPLIFIER 06x FET PHONO PREAMPLIFIER SAFETy PREcAUTIONS INTROdUcTION INSTALLATION dESIgN TEcHNIcAL dATA cARE & HANdLINg WARRANTy WARRANTy REgISTRATION...
  • Page 2 WARNINg CAUTION CAUTION WARNING WARNING CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. THIS SYMBOL IS TO ALERT YOU OF THE PRESENCE OF UNINSULATED DANGER- OUS VOLTAGE WITHIN THE UNIT'S ENCLOSURE THAT MAY BE OF SUFFI- CIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK.
  • Page 3 INTROdUcTION Thank you for selecting Coda Technologies and our precison line of of high definition, high value audio components. The Phono Preamplifier 06x is a precision device, designed in an effort to provide the listener with unmatched sound quality, design, and construction which will provide you with many years of listening enjoyment.

  • Page 4: Installation

    INSTALLATION The first section of the installation instructions for the 06x covers basic configuration of the preamplifier. These brief steps will bring the 06x into operation. Make sure during installa- tion that the preamplifier and all other components of your audio system are unpowered.
  • Page 5 INSTALLATION I. chassis WARNINg: Never oPeraTe ThIs uNIT wITh The ToP Cover reMoved. Never Make aNy INTerNal adjusTMeNTs whIle ThIs uNIT Is CoNNeCTed To aN aC Power sourCe. 1. Prior to installing the unit some configuration can be made internally, including input selection and per-channel gain and loading.
  • Page 6 If any of your other audio components do not have power switches, make sure they are unplugged from their aC power source. NOTE: The lINe volTage oF The PreaMPlIFIer 06x Is swITChaBle To PerMIT use IN dIF- FereNT CouNTrIes. CoNTaCT Coda TeChNologIes For INsTruCTIoNs oN ChaNgINg...

  • Page 7: Design Philosophy

    dESIgN PHILOSOPHy II. Source, Output and Power connections The input and output connections are marked on the rear lip of the top cover of the preamplifier. remember when connecting input and output cables to avoid inadvertently swapping left / right channel connections. The connections are as follows: 1.
  • Page 8 The requirements of a power supply for flawless audio reproduction are straightforward but important. The supplies in the 06x take a very direct approach to high performance. First, a top quality shielded toroid transformer with plenty of reserve current capability is used.
  • Page 9 Most companies in the upper end of the audio industry use either sheet metal or formed aluminum chassis. By contrast, the 06x has all structural parts made of machined extruded aluminum. The advantage of this over an all-stamped chassis is that the machined metal can be worked more precisely, allowing us to work on tighter tolerances and use PC-mounted parts more easily.

  • Page 10: Technical Data

    TEcHNIcAL dATA cIRcUIT SPEcIFIcATIONS Frequency response: +/- .2dB of rIaa with subsonic roll off @ 14hz distortion: < .01% from 20hz to 20khz @ 3v peak into 600Ω or higher shunted by 100pf or less. gain: unbalanced output - 37dB @ 1khz balanced output - 46dB @ 1khz Maximum output: 12v peak...

  • Page 11: Care And Handling

    cARE ANd HANdLINg The interior of the preamplifier requires no special care. If exterior cleaning beyond simple dusting is required, any dilute ammonia-based product is recommended. do not use any abrasive rags, cleaners or chemical solvents on the amplifier. when handling the preamplifier, take care not to mar the faceplate. aluminum is a medium hardness metal and can be scratched by harder tool steels, and the grained surface can be easily marred if the amplifier is set face-down on a hard surface.

  • Page 12: Warranty

    WARRANTy warranty - any failure of the Phono Preamplifier 06x, hereafter known as the product or original product, to operate or to meet specifications, applicable at time of manufacture, due to a manufacturing defect or component failure, will be corrected by Coda Tech- nologies without charge for parts or labor, for a period of ten years from date of original purchase.

  • Page 13: Warranty Registration

    WARRANTy REgISTRATION Fill in this registration sheet and fax or mail it to Coda Technologies to ensure you are in our warranty system. This will facilitate warranty service should it become necessary. It is recommended that you retain a copy of this form for your own records.
  • Page 14 7850 CUCAMONGA AVENUE #31 SACRAMENTO, CA 95826 USA +01 916.383.3653 +01 916.455.3653 phone CODA.CC on the web at info@coda.cc email us at...
