Features and Controls

Compare the illustrations with your generator to familiarize yourself with the locations of various controls and product warnings.
120 Volt AC, 20 Amp, Duplex Receptacle — Used
to supply 120 Volt AC, single phase, 60 Hz power for
electrical lighting, appliance, tool and motor loads.
120 Volt AC, 30 Amp Travel Trailer Receptacle (see
page 5) — May be used to supply electrical power for the
operation of 120 Volt AC, 30 Amp, single phase, 60 Hz
electrical, travel trailer loads.
Circuit Breakers (AC) — Push-to-reset circuit breakers are
provided to protect the generator against electrical overload.
4
Carbon Monoxide (CO) Shutdown Indicator Light —
Indicates the engine shutdown due to carbon monoxide
accumulation around the generator or a CO system fault
occurred.
Main Reset — Push to reset generator if overloaded.
USB Ports — Use ports to recharge most USB powered
devices.
Carbon Monoxide
(CO) Shutdown
Indicator Light
USB Ports
120 Volt AC, 20 Amp
Duplex Receptacles
Circuit Breakers
Main Reset
