Grass Trimmer
N1F-GT-280/450-D
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your trimmer, ensuring it is assembled correctly
and safely. If you need help or have damaged or missing parts,
call the Customer Helpline on 0345 605 2067
ORIGINAL
INSTRUCTION
MANUAL
AFTER SALES SUPPORT
0345 605 2067
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spear & Jackson N1F-GT-280/450-D
Summary of Contents for Spear & Jackson N1F-GT-280/450-D
- Page 1 ORIGINAL INSTRUCTION MANUAL 450W Electric Grass Trimmer N1F-GT-280/450-D Important - Please read these instructions fully before starting assembly AFTER SALES SUPPORT 0345 605 2067 These instructions contain important information that will help you get the best from your trimmer, ensuring it is assembled correctly and safely.
- Page 2 SPEAR & JACKSON SINCE 1760 For more than 250 years gardeners have enjoyed high quality performance and great results using Spear & Jackson tools. Our garden power tools combine continuous innovation and the latest in manufacturing technologies with a proud heritage. Each product is carefully designed with performance, comfort and durability firmly in mind, which has earned Spear &...
-
Page 3: Table Of Contents
CONTENTS Safety Information Description of symbols General safety Safety warnings Personal safety Operational safety Maintenance and storage safety Intended use Box Content / Parts Assemble Safety guard assemble Front handle assemble Plant protector assemble Cord strain relief Operate General operate Height adjustment Handle adjustment Tilt adjustment... -
Page 4: Safety Information
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine DESCRIPTION OF SYMBOLS The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the grass trimmer. IMPORTANT! Objects thrown by the product could hit the user or other bystanders. -
Page 5: General Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine GENERAL SAFETY appliance by a person IMPORTANT! responsible for their safety. ■ Children should be ■ Keep this instruction supervised to ensure that manual in a safe they do not play with the place for future reference. - Page 6 SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine ELECTRICAL SAFETY entangled cords increase the risk of electric shock. ■ Power tool plugs must ■ When operating a power match the outlet. Never modify the plug in any tool outdoors, use an way.
-
Page 7: Personal Safety Y
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine repaired. and clean. Properly maintained cutting tools ■ Disconnect the plug from with sharp cutting edges the power source and/ are less likely to bind and or the battery pack from are easier to control. -
Page 8: Operational Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine serious personal injury. better control of the power tool in unexpected ■ Use personal protective situations. equipment. Always wear ■ Dress properly. Do not wear eye protection. Protective equipment such as dust loose clothing or jewellery. - Page 9 SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine ■ Always ensure that the feet and hands from the cutting means. air vents are kept clear of debris. ■ Before use check the ■ After extending new controls and proper use of the product.
-
Page 10: Maintenance And Storage Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine ■ Disconnect from the power cord (code designation 60227 IEC 53). supply when the cord becomes damaged or ■ Do not expose the product tangled. to rain. ■... -
Page 11: Intended Use
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine similar qualified specialist. manufacturer from his or her legal liability. ■ When not in use, store the product out of the reach of children. ■ Have your power tools serviced by a qualified repair person using only identical replacement... -
Page 12: Box Content / Parts
BOX CONTENT PARTS 10m cable Tilt adjustment pedal Main handle Pole On/off Switch Knob Cable retainer Angle adjustment button Front handle Cable collector Locking sleeve length adjustment Support wheel Guard Spare spool Plant protector If there are any parts missing, please call the customer helpline on 0345 605 2067 AFTER SALES SUPPORT 0345 605 2067... -
Page 13: Assemble
ASSEMBLE Safety guard assemble i. Remove four mounting screws from motor housing. Note: They are pre-mounted on the motor housing by factory to help end-user find them quickly. And send a message to end-user, where these four screws should be used for. ii. -
Page 14: Cord Strain Relief
ASSEMBLE Cord strain relief i. Make sure the on/off switch is in its off position. ii. Double the cord, about 3cm from the end. Lead the loop through the hole on the rear safe guard and hook the loop over the cord strain relief. Gently pull on the cord to ensure that it is firmly attached. -
Page 15: Operate
OPERATE General operate i. Check the product, its power cord and plug as well as accessories for damage before each use. Do not use the product if it is damaged or shows wear. ii. Double check that accessories or cutting device are properly fixed. -
Page 16: Tilt Adjustment
OPERATE Tilt adjustment Adjust the vertical angle of the trimmer head to fit the trimming conditions. i. Press the tilt adjustment pedal down with your foot. ii. Adjust the angle of the pole, up or down. iii. Release the unlock pedal and keep moving the pole until it locks in place. -
Page 17: Plant Protector
OPERATE appliance. To support proper line elongation, ensure that the coil has stopped moving completely before turning on the appliance again. The lines are automatically cut to the correct length by the line cutter. Plant protector Use the plant protector to keep distance to plants like flowers, trees or other objects that could be hit by the cutting device. - Page 18 OPERATE iv. Hold the trimmer head just above the ground at an angle of approximately 30°. v. Move the product slowly from side to side in a swinging motion. vi. Ensure the cutting device remains clean and free from off-cuts that may cause it to jam.
-
Page 19: Tips
OPERATE WARNING! · Always fit the guard before using the product · When cutting longer /high grass, please make sure that you cut this down in 2 to 3 stages. · DO NOT cut long grass in one cut, as this will damage your grass trimmer, and make your warranty invalid. -
Page 20: Maintenance
MAINTENANCE This product does not contain any parts that can be repaired by the consumer. Contact an authorised service centre or a similarly qualified person to have it checked and repaired. Replacing the spool NOTE: Before replace the spool, make sure the mains plug is disconnected from the unit. -
Page 21: Storage
MAINTENANCE i. Hold the loose ends of the line together with one hand, find the center of the line with the other hand and hook this center loop into the groove on the spool. ii. Wind the line following the directional arrows on the spool housing and hook the two ends into the side grooves. -
Page 22: After Use
MAINTENANCE After use i. Switch the product off, disconnect it from the power supply and let it cool down. ii. Fold the plant protector in. iii. Check, clean and store the product as described below. Recycling and disposal i. Waste electrical products should not be disposed of with household waste. -
Page 23: Technical Data
TECHNICAL DATA Model N1F-GT-280/450-D Input voltage rating 240V~/50Hz Input power 450W No load speed 9000/min Trimming line Ø 1.4 mm, length 8m Cutting width 28cm Angle adjustment 0°~90° Weight 3.56kg Vibrations 4.61m/s , K=1.5m/s Part number Accessories GT450-57 Front handle... - Page 24 TECHNICAL DATA Measured sound pressure level LpA: 86dB(A), K=3dB(A) Measured sound power level LwA: 95.8dB(A), K=3dB(A) Guaranteed sound power level LwA: 96dB(A) The sound values have been determined according to noise test code given in EN 50636-2-91, using the basic standards EN ISO 11201 and EN ISO 3744. The sound intensity level for the operator may exceed 80dB(A) and ear protection measures are necessary.
-
Page 25: Troubleshooting
TROUBLESHOOTING Suspected malfunctions are often due to causes that the user can fix themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself! Gloves and appropriate protective clothing... -
Page 26: Warranty
WARRANTY If your device develops a fault, please don’t hesitate to contact our customer service department on 0345 605 2067, we can solve 80% of problems via the phone. 1. These warranty terms cover additional warranty rights and do not affect your statutory warranty rights.
