550W
Electric
Hedge Trimmer
HTEG48C-510
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your trimmer, ensuring it is assembled correctly
and safely. If you need help or have damaged or missing parts,
call the Customer Helpline on 0345 605 2067
ORIGINAL
INSTRUCTION
MANUAL
AFTER SALES SUPPORT
0345 605 2067
Advertisement
Table of Contents
Related Manuals for Spear & Jackson HTEG48C-510
Summary of Contents for Spear & Jackson HTEG48C-510
- Page 1 ORIGINAL INSTRUCTION MANUAL 550W Electric Hedge Trimmer HTEG48C-510 Important - Please read these instructions fully before starting assembly AFTER SALES SUPPORT 0345 605 2067 These instructions contain important information that will help you get the best from your trimmer, ensuring it is assembled correctly and safely.
- Page 2 SPEAR & JACKSON SINCE 1760 For more than 250 years gardeners have enjoyed high quality performance and great results using Spear & Jackson tools. Our garden power tools combine continuous innovation and the latest in manufacturing technologies with a proud heritage. Each product is carefully designed with performance, comfort and durability firmly in mind, which has earned Spear &...
-
Page 3: Table Of Contents
CONTENTS Safety Information Description of symbols General safety Personal safety Operational safety Maintenance and storage safety Intended use In The Box Assemble Unpacking Blade sheath Connection to the power supply Operate General operate Remove the blade sheath Switching on/off Trimming times Trimming Maintenance General cleaning... -
Page 4: Safety Information
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine DESCRIPTION OF SYMBOLS The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the hedge trimmer. IMPORTANT! Warning! Switch the product off Please read all of the safety and... -
Page 5: General Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine GENERAL SAFETY physical, sensory or IMPORTANT! mental capabilities, or lack of experience ■ Keep this instruction and knowledge, unless manual in a safe they have been given place for future reference. - Page 6 SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine ■ Keep children and ■ Do not abuse the cord. bystanders away while Never use the cord operating a power tool. for carrying, pulling or Distractions can cause you unplugging the power tool.
-
Page 7: Personal Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine PERSONAL SAFETY The correct power tool will do the job better and more safely when operated at ■ Stay alert, watch what the rate for which it was you are doing and use designed. -
Page 8: Operational Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine power tools with your finger collection can reduce dust- related hazards. on the switch or energising power tools that have the switch on invites accidents. OPERATIONAL SAFETY ■... - Page 9 SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine shields in place. cutting attachment. ■ Keep hands and feet away ■ Always ensure that the from the cutting attachment air vents are kept clear of at all times and especially debris.
-
Page 10: Maintenance And Storage Safety
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine NOT TOUCH THE CORD considered unauthorized BEFORE DISCONNECTING use and relieves the THE SUPPLY. manufacturer from his or her legal liability. ■ Do not use the product if the cord is damaged or worn. -
Page 11: Intended Use
SAFETY INFORMATION Please read these instructions fully before operating or maintaining your machine product out of the reach of Service children. ■ Have your power tools ■ Maintain power tools. serviced by a qualified Check for misalignment or repair person using only binding of moving parts, identical replacement parts. -
Page 12: In The Box
IN THE BOX PARTS Power cord with plug Cutting blades Front guard Cord strain relief Front handle Blade sheath Safety switch Air vent Rear handle On/off switch If there are any parts missing, please call the customer helpline on 0345 605 2067 AFTER SALES SUPPORT 0345 605 2067... -
Page 13: Assemble
ASSEMBLE Unpacking i. Unpack all parts and lay them on a flat, stable surface. ii. Make sure all parts and accessories are included and undamaged. If you find that parts are missing or show damage please contact the after sales service at 0345 605 2067. -
Page 14: Connection To The Power Supply
ASSEMBLE Connection to the power supply i. Double the cord, about a foot from the end. Lead the loop through the hole on the rear safe guard and hook the loop over the cord strain relief (9). Gently pull on the cord to ensure that it is firmly attached. -
Page 15: Operate
OPERATE GENERAL OPERATE Check the product, its power cord and plug as well as ■ accessories for damage before each use. Do not use the product if it is damaged or shows wear. Double check that accessories or cutting device are properly ■... -
Page 16: Switching On/Off
OPERATE Switching on/off i. Hold the product with one hand at the rear handle (6) and with the other at the front handle (3). ii. Press the on/off switch (7) and the safety switch (4) at the same time to switch the product on. iii. - Page 17 OPERATE v. First cut both sides from the bottom cutting upwards to the top. This will prevent any of the trimmings falling into the path of the area still to be cut. vi. After cutting the sides proceed to the top. Try to keep the cutting device angled at approximately 15°...
-
Page 18: Maintenance
MAINTENANCE WARNING! Always switch the product off, disconnect it from the power supply and let the product cool down before performing inspection, maintenance and cleaning work! Regular and proper cleaning will help ensure safe use and ■ prolong the life of the product. Inspect the product before each use for worn and damaged ■... -
Page 19: Cleaning The Blades
MAINTENANCE Cleaning the blades WARNING! Wear safety gloves when working on blades and close to it! Use appropriate tools to remove debris, e.g. a brush or wooden stick! Never use your bare hands! Always use original spare parts for replacement. i. -
Page 20: Storage
MAINTENANCE Storage i. Clean the product as described above. ii. Attach the blade sheath. iii. Store the product and its accessories in a dry, frost-free place. iv. Always store the product in a place that is inaccessible to children. The ideal storage temperature is between 10 - 30°C. v. -
Page 21: Technical Data
TECHNICAL DATA Model HTEG48C-510 Input voltage rating 230-240V ~,50Hz Input power 550W Max. cutting length 450mm Max. cutting capacity 20mm Safety class class II Weight 3.35kg Part number Accessories HT550-01 Blade sheath Measured sound pressure level: LpA:89dB(A), K=3dB(A) Measured sound power level: LwA:102 dB(A), K=3dB(A) -
Page 22: Troubleshooting
TROUBLESHOOTING Suspected malfunctions are often due to issues that the user can fix themselves. Therefore, check the product using this section. In most cases the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself! -
Page 23: Warranty
WARRANTY If your device develops a fault, please don’t hesitate to contact our customer service department on 0345 605 2067, we can solve 80% of problems via the phone. 1. These warranty terms cover additional warranty rights and do not affect your statutory warranty rights. - Page 24 AFTER SALES SUPPORT 0345 605 2067...
