Internal Flatpanel Interfaces

Flatpanel Adapter Interface
The on-board 64-pin row flatpanel adapter connector CON8 is placed on the standard
version of the CP331 and on the board variant CP331-PL to provide connectivity for any
type of flatpanel via a suitable adapter.
Note...
On the CP331-PL a PanelLink Adapter Module provided with a
PanelLink connector to the frontpanel is connected to the flatpanel
adapter connector CON8. Therefore, no other internal connection
to this connector is possible on the CP331-PL.
Table 2-4: CON 8 Pinouts
Pin
1 GND
4 VDDSAFE
7 12VSAFE
10 P1
13 P4
16 +3.3V
19 P8
22 P11
25 P12
28 P15
31 VCC
34 P19
37 P22
40 GND
43 P26
46 P29
49 P30
52 P33
55 VCC
58 FLM
61 DDCLK0
64 GND
Page 2 - 8
Signal Pin
2
5
8
11
14
17
20
23
26
29
32
35
38
41
44
47
50
53
56
59
62
© 2000 PEP Modular Computers GmbH
Functional Description
Signal
GND 3
VEESAFE 6
12VSAFE 9
P2 12
P5 15
P6 18
P9 21
GND 24
P13 27
P16 30
VCC 33
P20 36
P23 39
P24 42
P27 45
+3.3V 48
P31 51
P34 54
VCC 57
M 60
DDDAT0 63
Pin Signal
VDDSAFE
VEESAFE
P0
P3
+3.3V
P7
P10
GND
P14
P17
P18
P21
GND
P25
P28
+3.3V
P32
P35
LP
SHFCLK
GND
