1.2 Board Overview

1.2.1

Board-Specific Information

Based around the Chips&Technologies 69000 or 69030 multi-media graphic controller
chips, the CP331 is a CompactPCI enhanced speed, resolution, connectivity (ESRC)
flat-panel USXGA graphics board built for use with all industrial standard displays. All
variants of the CP331 are equipped with a CRT standard VGA interface. As an option,
either an additional standard integrated LVDS interface or an additional PanelLink inter-
face can be provided. The LVDS and PanelLink variants provide the user with the possi-
bility of connecting all types of flatpanel displays with up to 24-bit resolution (16.7 million
colors.)
Simultaneous display on a CRT monitor and a flatpanel display
Possible flatpanel types: displays: EL monochrome, 24-bit TFT, 24-bit plasma, sin-
gle-scan (SSTN) or dual-scan (DSTN) STN color
Up to sixteen flatpanel types directly selectable by jumper setting
Configuration utilities for adapting the BIOS of the graphic chip to almost any panel
Up to 16.7 million colors
VGA, SVGA, XGA, SXGA and USXGA resolutions
Separation between external flatpanels and the graphics interface:
LVDS:
PanelLink:
TTL:
Low EMI emission
Video memory:
C&T 69000: 2 MByte
C&T 69030: 4 MByte
Hardware Windows accelerator with 64-bit graphics engine
Various power-down and sleep modes
Display centering/stretching for larger displays
1.2.2

Board Variants

Three different variants of the CP331 are available:
CP331 (standard variant)
CP331-PL
CP331-LVDS
All board variants have in common a standard 15-pin VGA connector on the frontpanel.
In addition, the various board variants are equipped with one or more of the following
connectors:
LVDS connector (26-pin miniature Delta Ribbon connector)
PanelLink connector (20-pin miniature Delta Ribbon connector)
Flatpanel adapter connector CON8 (64-pin on-board pin-row connector)
Internal TTL flatpanel connector CON9 (on-board 40-pin on-board pin-row connector)
General-purpose connector CON10 (8-pin on-board pin-row connector)
Page 1 - 4
10m
5m
0.6m
© 2000 PEP Modular Computers GmbH
Introduction
ID 19947, Rev. 0200
