Cirris 4200 Series Testers combine powerful testing with reliable software. This
guide will help you set up your tester, create a test program, and test a cable.
The instructions explained in this guide are an example of one way to set up a
simple testing process.
For complete instructions, see the 4200 Series User Manual found on the USB
flash drive included with the tester.
In the Box
You should have recieved:
☐
Tester Unit
☐
Power Cable
☐
Power Supply
You may have also received:
■
Cirris Adapters
■
Tilt Stand
■
Expansion Boxes
Cirris 4200 Series
Quick Start Guide
4250 Getting Started Guide
☐
USB Flash Drive containing
manual and software
☐
USB Cable
☐
Probe
☐
Wi-Fi Antenna
■
Header Strips
■
Printed User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cirris 4200 Series

Summary of Contents for Cirris 4200 Series

  • Page 1 The instructions explained in this guide are an example of one way to set up a simple testing process. For complete instructions, see the 4200 Series User Manual found on the USB flash drive included with the tester. In the Box You should have recieved: ☐...

  • Page 2: Hardware Setup

    Note: Depending on your environment, network, and other conditions, you may occasionally notice the tester pause to reestablish network communication. To avoid this, Cirris recommends using a wired connection. For more information on networking, see Network Settings in the 4200 Series User Manual. Fixturing...

  • Page 3: Installing Adapters

    Installing Adapters The Cirris Adapter System connects the DUT to the tester. Cirris sells a variety of adapters that mate to standard connectors. See cirris.com/products/adapters. To attach an adapter to the tester: Push the slidelocks to the outward positions. Set an adapter in one or more of the J1-J4 slots. Push the adapter to the left (toward the tester’s screen).
  • Page 4 Manage Files Edit Test System Settings View Create Load Cirris 4250 Tester | SN: XXXXXXXX Cirris OS v 0.0.0.0 | Hardware v XXXXX.1.A Press Edit Learn Settings to adjust settings per the cable Create New Test specifications. Learn Settings Preferences Learn...

  • Page 5: Perform A Learn

    Learn Settings Preferences: • Set start conditions along with Lot ID and intermittents testing. Low Voltage: • Set low voltage conditions such as connection resistance and insulation resistance. High Voltage (Hipot): • Set high voltage conditions for voltage, insulation resistance and dielectric withstand testing, dwell time, and other settings.
  • Page 6 By pressing Save As, you will be able to select a storage location and name for the test program. Navigate to a location within Manage Files the directory to save the test program. If you are using Cirris NewTest.wir Hub Software, saving files to New Folder the network location F: will...

  • Page 7: Common Errors

    Open Errors: A gap in the intended electrical path. Short: Unintended contact between two or more points. Miswire: The wire is terminated to an incorrect contact. For more informatin on errors, refer to the 4200 Series User Manual or cirris.com. 4250 Getting Started Guide...

  • Page 8: Finishing A Test

    Cirris Hub Software allows you to share files and print to network printers from your 4200 Series tester. A free version of the software is found on the USB flash drive that came with your tester. For more information see cirris.com or the Cirris Hub Getting Installation Guide.
