- Page 1 Easy-Touch Pro Getting Started Guide Software & Documentation To download software, the Easy-Touch Pro User Manual, and other supporting documentation scan the QR code here or on the tester to visit downloads.cirris.com. downloads.cirris.com...
-
Page 2: Getting Started
Getting Started The Cirris Easy-Touch Pro combines superior flexibility with the simplicity of a touchscreen user interface. The tester is controlled by the Easy-Wire software running on an integrated PC under the Windows operating system. Test programs and test results are stored in a database. By default, the database is located on the unit’s hard drive. -
Page 3: Intended Use
NOT perform high voltage testing. Intended Use Cirris Easy-Touch Pro testers are designed for electrical testing and are intended to be used indoors, in a dry environment, at a temperature of 50-104 degrees Fahrenheit (10-40 degrees Celsius). High voltage Insulation Resistance measurements degrade at over 70% relative humidity. -
Page 4: Hardware Setup
The tester includes 128 test points in the base enclosure. It can be expanded to a maximum of 1024 test points using 128-point Expansion Scanners. See the Easy-Touch Pro User Manual for Expansion Scanner installation instructions. After installing any included expansion scanners: 1. - Page 5 When the self-test passes, the Main Menu will open with a Ready status indicator. The software license purchased with a new Easy-Touch Pro tester includes software upgrades for a period of one year. The Main Menu shows a Licensed status.
-
Page 6: Changing The Interface Language
Click OK on the Setup System Options window to return to the Main Menu. The Easy-Wire Help The Easy-Wire software includes a contextual Help system accessed by clicking/ tapping the Help button available on most Easy-Wire windows. The Help can be browsed using its Table of Contents or searched by keywords. Cirris... - Page 7 (a complete list can be found on the Cirris web site). However, if the DUT includes connectors that have no direct adapter mates, test cables can be used to connect the connector on a standard Cirris adapter to the DUT connector.
- Page 8 (high voltage is not used during the learn process). Click Set High Voltage Parameters to edit the test criteria. ● Check any components included in the product. ● Click/tap Learn Attached Device to begin the learn process. Cirris...
- Page 9 The location of the adapters (J1, J2, J3 etc.) and the positions within their connectors (001, 002, 003 etc.) are used to identify test points, for example J1- 001. Product-specific nomenclature can be used instead by adding point Labels. Easy-Touch Pro Getting Started Guide...
- Page 10 Hipot. 3. If an intermittents test was programmed, it will begin after the initial test cycle passes. Flex the cable to check for intermittent errors. The test will end depending on the Test Method settings. Cirris...
- Page 11 New Cirris testers ship with a Certificate of Calibration valid for one year. Cirris recommends that the calibration be validated annually at a minimum thereafter. The validation can be performed by Cirris or by the end user or a calibration service provider using an Easy-Touch Performance Verification Kit. Contact your Cirris sales representative for more information.
-
Page 12: Help & Support
● In the United States, contact our technical support team at techsupport@ cirris.com or by phone at 801-973-4600, ext. 666 (or ask for Tech Support). ● Outside the United States, visit the contact page of the Cirris web site at cirris.com to find your local representative.
