Summary of Contents for Adaptec 5325301580

  • Page 1 Quick Start Guide and User CD Kurzanleitung und Benutzer-CD Guía de iniciación rápida y CD del usuario Guide de mise en route rapide et CD de l’utilisateur...
  • Page 2: About This Guide

    About This Guide This guide shows you how to quickly install and connect your Snap Server to the network. Prior to the installation, gather all the hardware components required for your system: Check the contents of your shipment package for all the items shown in Hardware Features. •...
  • Page 3: Hardware Features

    Hardware Features Quick Start Guide Power button System status lights Release latches (two) Disk drive status lights Primary Ethernet port Secondary Ethernet port Note The monitor, USB, keyboard, and mouse connectors are not needed to administer the Snap Server. These connectors are disabled Server number label Serial number label Stacking clips (four)
  • Page 4: Installing The Server In A Rack

    Installing the Server in a Rack The Snap Server ships with two L-shaped rack mount brackets. You can attach them in one of two ways: (1) to the front of the server for mounting to the front posts of a four-post rack; or, (2) to the middle or front of the server for mounting to both posts of a Telco rack.
  • Page 5: Connecting The Power Cord

    Connecting the Server to the Network The server has Dual-Gigabit Ethernet ports that can connect to 10BaseT, 100BaseTx, or 1000BaseT networks. A dual-port configuration offers added advantages, such as load balancing and failover. You may connect one or both of the ports. •...
  • Page 6 Connecting to the Snap Server for the First Time Snap Servers are preset to acquire an IP address from a DHCP server. If no DHCP server is found on the network, the Snap Server defaults to an IP address of 10.10.10.10, and you may not be able to see the server on your network.
  • Page 7 User CD For immediate response to a service inquiry, you can submit a question to our Sie finden den technischen Service oder Kundendienst für Ihren Snap Server auf unserer Website. Wenn Kunden sofortige Antworten auf eine Serviceanfrage wünschen, können sie mit Hilfe unseres Expert Knowledge Base System Para obtener servicio o asistencia técnica para su Snap Server, visite nuestro sitio Web.
