READ AND SAVE THESE INSTRUCTIONS
INSTALLATION INSTRUCTIONS
Model: AC-30052
Kendal Lighting (BC) Inc.
#110, 6780 Dennett Place
Delta, BC V4G 1N4
Canada
Tel: (604) 952-5510
Fax: (604) 952-5513
CETL LISTED MODEL: BF858-52
Weight of Fan: 5.61 Kgs
