Programmable Side Key - Intek ET Series Instruction Manual

You can program the Side key (8), by using the dedicated PC software.
The programmable fuctions are as follow :
No. Function
1 DTMF ON / OFF (*)
2 Monitor
3 Monitor Momentary
4 Squelch OFF
5 Squelch OFF Momentary
6 Check Squelch level
7 Adjust Squelch level
8 SCAN
9 Priority Channel Scan
10 Nuissance Channel
Temporary Delete
11 Nuissance Channel Delete
12 Talk Around (*)
13 Reverse Frequency (*)
14 Check TX Power (*)
15 VOX ON / OFF
16 Check battery capacity
17 Voice Announcement
18 1750 Hz Tone (*)
19 Channel Lock
20 Whisper (*)
21 Select Call (*)
22 Emergency Alarm (*)
Note: Your dealer may assign different functions for Side Key (long press or short press the key).
(*) These funcions are available only on models MT-174ET and MT-460ET

Programmable Side Key

Description
Enable / disable DTMF Function
The radio will un-mute only when it receives a carrier signal.
The radio will un-mute no matter there is a carrier signal or not.
Check the current Squelch Level.
Adjust the current Squelch Level quickly.
Automatic channel scanning.
Scan the Priority Channel before other channels.
Delete the noise channel from the current scan group
temporarily.
Delete the noise channel from the current scan group.
The Rx frequency will be used in place of the Tx frequency
during transmission.
Reverse the transmitting frequency and receiving frequency for
Repeater function.
Check the transmitting power level on the current channel.
Enable / disable VOX function.
To know the current battery capacity.
When you turn the Channel Selector Knob, the radio will report
the current channel position.
For access to Repeaters
To lock the current channel position, and the Channel Knob is
invalid.
You can speak quietly into the Microphone, and other users
still can hear clearly.
Single Call and Group Call.
The alarm mode can be programmed via Software.
- 11-
