Trip code Description
31 L3-T3 shorted
33 Time-overcurrent (Bypass overload)
34 SCR overtemperature
35 Battery/clock
36 Thermistor circuit
47 Overpower
48 Underpower
56 Keypad disconnected
57 Zero Speed Detect
58 SCR Itsm
59 Instantaneous overcurrent
60 Rating Capacity
70 Current Read Err L1
71 Current Read Err L2
72 Current Read Err L3
74 Motor Connection T1
75 Motor Connection T2
76 Motor Connection T3
77 Firing Fail P1
78 Firing Fail P2
79 Firing Fail P3
80 VZC Fail P1
81 VZC Fail P2
82 VZC Fail P3
83 Low Control Volts
84~96 Internal fault x. Contact your local supplier with the fault code (X).
7.5 Examples
Control commands (controller to device)
Start the motor using parameter set 1
Byte 0 Byte 1
4 1
Start the motor, select via remote input
Byte 0 Byte 1
0 1
Stop the motor using the programmed soft stop for motor set 2
Byte 0 Byte 1
8 0
Profinet Card (710-16502-00C)
Byte 2 Byte 3
Byte 2 Byte 3
Byte 2 Byte 3
Byte 4 Byte 5
Byte 4 Byte 5
Byte 4 Byte 5
INSTRUCTIONS
Byte 6 Byte 7
Byte 6 Byte 7
Byte 6 Byte 7
