AuCom PROFINET CARD Instructions Manual page 16

INSTRUCTIONS
Byte Description
26-27 Power
28-29 % Power factor
30-31 Voltage
32-33 Current
34-35 Current
36-37 Current
38-39 Voltage
40-41 Voltage
42-43 Voltage
44-45 Parameter list
version number
46-47 Digital input state
48-49 Trip code
Reserved
50-51
52-53 Frequency
54-55 Ground current
Reserved
56-59
60-63 Parameter
management
16
Bits Details
0 to 11 Power
12 to 13 Power scale
0 = Multiply power by 10 to get W
1 = Multiply power by 100 to get W
2 = Power (kW)
3 = Multiply power by 10 to get kW
Reserved
14 to 15
0 to 7 100% = power factor of 1
Reserved
8 to 15
0 to 13 Average rms voltage across all three phases
Reserved
14 to 15
0 to 13 Phase 1 current (rms)
Reserved
14 to 15
0 to 13 Phase 2 current (rms)
Reserved
14 to 15
0 to 13 Phase 3 current (rms)
Reserved
14 to 15
0 to 13 Phase 1 voltage (rms)
Reserved
14 to 15
0 to 13 Phase 2 voltage (rms)
Reserved
14 to 15
0 to 13 Phase 3 voltage (rms)
Reserved
14 to 15
0 to 7 Parameter list minor revision
8 to 15 Parameter list major version
For all inputs, 0 = open, 1 = closed (shorted)
0 Start/Stop
Reserved
1
2 Reset (Refer to note)
3 Input A
4 Input B
Reserved
5 to 15
0 to 15 Refer to Trip codes on page 18
Frequency (Hz)
Ground current (A)
Refer to Parameter management on page 17
Profinet Card (710-16502-00C)
