Ground fault action
40D
Ground fault CT ratio
40E

6. Operation

The device has been designed for use in a system complying with the Profinet
standard. For successful operation, the controller must also support all functions
and interfaces described in this document.
6.1 Device classification
The Profinet Card is a Profinet IO-Device and must be managed by an IO-Controller
over Ethernet.
6.2 Ensuring safe and successful control
Data written to the device will remain in its registers until the data is overwritten or
the device is reinitialised.
If the soft starter may be controlled via Command Override (parameter 7A) or may be
disabled via the reset input (terminals 10, 11) fieldbus commands should be cleared
from the registers. If a command is not cleared, it will be re-sent to the starter once
fieldbus control resumes.
6.3 Feedback LEDs
LED name LED state
Power Off
On
Error Off
Flashing
On
Status Off
Flashing
Link x Off
On
TX/RX x Flashing
12
Description
Selects the soft starter's response to the
protection event.
Set to match the ratio of the ground current
measuring CT.
TX/RX2
Port 1 Port 2
Description
Device is not powered up.
Device is receiving power.
No error.
Connection not established.
No physical link or slow physical link.
No configuration.
No error.
DCP signal service initiated via the bus.
No network connection.
Connected to a network.
Transmitting or receiving data.
TX/RX1 STATUS
Keypad
LINK 2 LINK 1 ERROR
Profinet Card (710-16502-00C)
