AuCom PROFINET CARD Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTRUCTIONS
PROFINET CARD
RIGHT FROM
THE START
Contents
1. Introduction ......................................................................................... 3
2. Installation ........................................................................................... 5
3. Device configuration ............................................................................ 6
4. Master configuration ......................................................................... 11
5. Ground fault protection ..................................................................... 11
6. Operation ........................................................................................... 12
7. Packet structures .............................................................................. 13
8. Network design ................................................................................. 21
9. Specifications .................................................................................... 23
Compatibility
This manual is suitable for:
• Profinet Card
• Profinet Card with Ground Fault
These cards are suitable for use with EMX4e and EMX4i soft starters.
The available features may vary according to the model and version of the starter.
This user manual is intended for use with version 3.x of the Profinet Card. Version 2.x
of the Profinet Card does not support custom users or IoT operation.
© 2021 AuCom Electronics Ltd. All Rights Reserved.
Profinet Card
|
Rev C 5/2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROFINET CARD and is the answer not in the manual?

Questions and answers

Related Manuals for AuCom PROFINET CARD

Summary of Contents for AuCom PROFINET CARD

  • Page 1: Table Of Contents

    The available features may vary according to the model and version of the starter. This user manual is intended for use with version 3.x of the Profinet Card. Version 2.x of the Profinet Card does not support custom users or IoT operation.
  • Page 2 For your safety, isolate the soft starter completely from mains voltage before attaching or removing accessories. WARNING Inserting foreign objects or touching the inside of the starter while the expansion port cover is open may endanger personnel, and can damage the starter. Profinet Card (710-16502-00C)

  • Page 3: Introduction

    1. Introduction 1.1 Product design The Profinet Card allows the soft starter to connect to an Ethernet network and be controlled or monitored using an Ethernet communication model. Familiarity with Ethernet protocols and networks is required to operate the device successfully.
  • Page 4 INSTRUCTIONS Soft starter Network switch IoT connection (MQTT/OPC UA) Industrial ethernet connection to programmable logic controller Profinet Card (710-16502-00C)

  • Page 5: Installation

    2.4 Addressing Each device in a network is addressed using a MAC address and a device name. The MAC address is fixed within the device and is printed on a label on the front of the device. Profinet Card (710-16502-00C)

  • Page 6: Device Configuration

    I/O data, the Error LED will flash. The Error LED will be active during the configuration process. NOTE If your PC has a firewall enabled, you must add the tool to the list of authorised programs. Profinet Card (710-16502-00C)
  • Page 7 INSTRUCTIONS 3.2 Enabling network control The soft starter will only accept commands from the Profinet Card if parameter 1A Command Source is set to 'Network'. NOTE If the reset input is active, the starter will not operate. If a reset switch is not required, use parameter 7I to set the reset input to normally open or fit a link across terminals 10, 11 on the soft starter.
  • Page 8 1978 NOTE Version 2.x of the Profinet Card does not support custom users. The Profinet Card supports multiple users and levels of privilege. • Users can view the home screen and IP address settings • Supervisors can view the home screen and IP settings and can change configuration settings •...
  • Page 9 2. Click the required entry in the user list then click Delete user. Click Delete again to confirm the action. Configure IoT settings The Profinet Card supports soft starter status monitoring over IoT. The card cannot control or program the soft starter. NOTE Version 2.x of the Profinet Card does not support IoT operation.
  • Page 10 2. Tick the Enable checkbox to enable OPC UA client operation. The OPC UA client is enabled by default. 3. Click Server Configuration then configure the settings as required. 4. Use Actions to select the actions for different object instances. 5. Click Submit to save all settings in the card. Profinet Card (710-16502-00C)

  • Page 11: Master Configuration

    5.1 Overview Ground fault protection The Profinet Card can detect ground current and trip before the equipment is damaged. Ground fault protection requires a 1000:1 or 2000:1 5 VA current transformer (not supplied). The soft starter can be configured to trip at 1 A~50 A. If ground fault current rises above 50 A, the soft starter will trip immediately.

  • Page 12: Operation

    For successful operation, the controller must also support all functions and interfaces described in this document. 6.1 Device classification The Profinet Card is a Profinet IO-Device and must be managed by an IO-Controller over Ethernet. 6.2 Ensuring safe and successful control Data written to the device will remain in its registers until the data is overwritten or the device is reinitialised.

  • Page 13: Packet Structures

    Command source 0 = Network, Timer 1 = Remote Keypad, Digital Input, Clock 1 = Ramping (starting or stopping) 1 = Ready 1 = Starting, running or stopping 1 = Tripped 1 = Warning Reserved 12 to 15 Profinet Card (710-16502-00C)
  • Page 14 0 to 15 Refer to Trip codes on page 18 Bytes 6-7: Motor current Bits Details 0 to 15 Average rms current across all three phases Bytes 8-9: Motor temperature Bits Details 0 to 15 Motor thermal model (%) Profinet Card (710-16502-00C)
  • Page 15 Average rms current across all three phases Reserved 14 to 15 22-23 Current 0 to 9 Current (% motor FLC) Reserved 10 to 15 24-25 Motor temperature 0 to 7 Motor thermal model (%) Reserved 8 to 15 Profinet Card (710-16502-00C)
  • Page 16 48-49 Trip code 0 to 15 Refer to Trip codes on page 18 Reserved 50-51 52-53 Frequency Frequency (Hz) 54-55 Ground current Ground current (A) Reserved 56-59 60-63 Parameter Refer to Parameter management on page 17 management Profinet Card (710-16502-00C)
  • Page 17 Frequency reported via communications is 10 times greater than the actual value. 7.3 Parameter management The Profinet Card can read parameter values from and write parameter values to the soft starter. The card handles one parameter at a time. The device references parameters according to their position in the starter's parameter list.
  • Page 18 FLC too high Unsupported option (function not available in inside delta) Communications card fault Network communication Overvoltage Undervoltage Parameter out of range Input B trip L1 phase loss L2 phase loss L3 phase loss L1-T1 shorted L2-T2 shorted Profinet Card (710-16502-00C)
  • Page 19 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Stop the motor using the programmed soft stop for motor set 2 Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Profinet Card (710-16502-00C)
  • Page 20 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Stop Mode Parameter read response: parameter 2I = 1 (TVR Soft Stop) Byte 56 Byte 57 Byte 58 Byte 59 Byte 60 Byte 61 Byte 62 Byte 63 Profinet Card (710-16502-00C)

  • Page 21: Network Design

    NOTE Each connection adds a delay to communication with the next device. The maximum number of devices in a line network is 32. Exceeding this number may reduce the reliability of the network. Profinet Card (710-16502-00C)
  • Page 22 The device supports beacon based ring node configuration with MRP (media redundancy protocol). NOTE The network switch must support loss of line detection. 8.4 Combined topologies A single network can include both star and line components. Profinet Card (710-16502-00C)

  • Page 23: Specifications

    Link speed ............10 Mbps, 100 Mbps (auto-detect) Full duplex Auto crossover • Power Consumption (steady state, maximum) ........35 mA @ 24 VDC Reverse polarity protected Galvanically isolated • Certification CE ...................... EN 60947-4-2 ..................IEC 60947-4-2 Profibus & Profinet International ........... Profinet Card (710-16502-00C)
  • Page 24 INSTRUCTIONS Profinet Card (710-16502-00C)
