INSTRUCTIONS
Input
Parameter data from the starter is reported in input bytes 60-63.
Device > controller input bytes are structured as follows.
Byte Bits
60 0 to 7
61 0
1
2 to 7
62 0 to 7
63 0 to 7
7.4 Trip codes
Trip code Description
255 No trip
1 Excess start time
2 Motor overload
3 Motor thermistor
4 Current imbalance
5 Frequency
6 Phase sequence
7 Overcurrent
8 Power loss
9 Undercurrent
10 Heatsink overtemperature
11 Motor connection
12 Input A trip
13 FLC too high
14 Unsupported option (function not available in inside delta)
15 Communications card fault
16 Network communication
18 Overvoltage
19 Undervoltage
23 Parameter out of range
24 Input B trip
26 L1 phase loss
27 L2 phase loss
28 L3 phase loss
29 L1-T1 shorted
30 L2-T2 shorted
18
Details
Echo parameter number
1 = Invalid parameter number
1 = Invalid parameter value
Reserved
Low byte parameter value read from soft starter
High byte parameter value read from soft starter
