Solimotion FTR20
24 Adjustment of limit signal function
A Rest position (supply voltage missing)
B Minimum safety
C Maximum safety (default setting)
The limit signal function is configured as follows:
Move the encoding switch to position 6
→ Display of the function number
→ After 2 seconds: Display of the configured limit signal function, example:
Press the or
signal functions
→ Display of the changed limit signal function, example:
Move the encoding switch to the initial position 0
→ Display of the current signal strength
Output
Relay
(Contact 3-4-5)
or
Solid-state
relay
(Contact 3-4)
Endress+Hauser
key on the device in order to change between the two possible limit
Rest Setting
position
3 4 5
A
A
Exceeding of
switch point
(LED 5)
3 4
3 4
Commissioning
B
C
Undershooting
hysteresis
(function 5)
5 3 4
5 3 4
5
5
