Comfee CS14EFSBK1RCM Use & Care Manual
Hide thumbs
Also See for CS14EFSBK1RCM:
- Installation instructions manual (25 pages) ,
- Use & care manual (35 pages)
Advertisement
Dishwasher Features ......................................... 4
Operating Instructions ........................................5
Dishwasher Use & Care Manual
Dishwasher
Use & Care Manual
CS14EFSBK1RCM
TA B L E O F C O N T E N T S
........................... 2-3
s..............................
Dishwasher Dispenser and Detergents ............... 11
Care and Cleaning ........................................... 12-13
-7
Solutions to Common Dishwashing Problems......14-15
8-10
Warranty.........................................................16-17
Advertisement
Related Manuals for Comfee CS14EFSBK1RCM
Summary of Contents for Comfee CS14EFSBK1RCM
-
Page 1: Table Of Contents
Dishwasher Use & Care Manual Dishwasher Use & Care Manual CS14EFSBK1RCM TA B L E O F C O N T E N T S Important Safety Instructions ......2-3 Dishwasher Dispenser and Detergents ....11 Dishwasher Features ......... 4 Care and Cleaning ........... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Do not use the dishwasher if it has a damaged power line or plug and do not plug the dishwasher into a damage power outlet failure to observe these instructions may result in electrical shock． ， Remove the door to the washing compartment when removing an old dishwasher from service or discarding it. STEAM Do not touch the on the panel during the washing... -
Page 4: Dishwasher Features
DISHWASHER FEATURES Capacity 14 place settings Dimension 23.89 x 24.5 x 33.74inches W x D x H Weight unpacked 78lb 35.5kg Power Supply 120volts 60Hz Rated power usage Wash motor 50W Heater 840W Water Feed Pressure 20-80psi(138-552kPa) Rinse Aid Dispenser Top Spray Arm Cup Shelf Detergen t Dispenser... -
Page 5: Operating Instructions
OPERATING INSTRUCTIONS Options With the dishwasher door close, you can press When the wash cycle has been selected, you the PRO button to select the wash cycle. A can choose options by pressing the "Options" light on the display will indicate which cycle button. - Page 6 OPERATING INSTRUCTIONS Indicator light Delay Start To delay the start of a selected cycle, press Delay /Start Sanitize pad until the desired delay time shows in the LED When "sanitize" option is selected, the temperature indicator. It allows you to automatically start your of the water will reach a maximum of 70°C (158°F).
- Page 7 OPERATING INSTRUCTIONS NOTE The remaining time could suddenly increase or decrease by several minutes. This means the Smart Sensor has checked the soil level and adjusted for the appropriate water fill level. Running time Running time with Running time with Program Description of Cycle Detergent(g)
-
Page 8: Preparing And Loading Dishes
PREPARING AND LOADING DISHES Dish preparation Scrape away large pieces of food, bones, pits, toothpicks, etc. The continuous filtered wash system will remove the remaining food particles. Burned-on foods should be loosened before loading. Empty liquids from glasses and cups. Foods such as mustard, mayonnaise, vinegar, lemon juice and tomato based products may cause discoloration of stainless steel and plastics if allowed to... - Page 9 PREPARING AND LOADING DISHES Loading the Bottom Rack bottom rack is designed to load plates, soup bowls, plates, saucers and cookwares. The adjustable rack space will allow you to load maximum 13 inch items. Large items should be placed along the edge so they do not interfere with the middle spray arm rotation, and make sure they do not...
- Page 10 PREPARING AND LOADING DISHES Adjustable Upper Rack The upper rack height can be easily adjusted to accommodate loading taller dishes in either rack. To accommodate taller dishes in the bottom rack, there are 2 positions available: Upper Rack Position Lower Rack Position Note: Height should be adjusted without dishes in the racks.
-
Page 11: Dishwasher Dispenser And Detergents
& Filling the detergent dispenser Filling the rinse aid dispenser Rinse aid greatly improves drying and reduces water 1. Push the dispenser cover latch downwards and spots and filming. open it . Rinse agent removes spots and prevents new film build up on your dishes, glasses, flatware, cookware and plastic. -
Page 12: Care And Cleaning
CARE AND CLEANING Because hard water chemicals will clog the Clean the Stainless Steel Inner spray arm jets and bearings, it is necessary Door and Tub to clean the spray arms regularly. Wash the The tub is made of Stainless Steel, it will not rust or corrode if the dishwasher should be scratched or dented. - Page 13 CARE AND CLEANING Clean the Fine Filter Take out the Cylinder Filter and remove the Fine Filter from the dishwasher tub bottom. To remove the Fine Filter you must first remove the bottom spray arm as shown below. Flush the Fine Filter by holding it under running water and replace.
-
Page 14: Solutions To Common Dishwashing Problems
SOLUTIONS TO COMMON DISHWASHING PROBLEMS Solution Problem Possible cause Possible cause Solution Door may not be closed properly Shut the door compl l ete ly make sure it is latched Door may not be closed properly Power supply or power line is not connected Check and connect the power supply Power supply or power line is not connected Dishwasher won’t start... - Page 15 SOLUTIONS TO COMMON DISHWASHING PROBLEMS Problem Possible cause Solution Detergent dispenser Add the detergent and rinse aid as indicated Improper operation of the detergent cover will not shut the manual Water remains in the Previous cycle has not finished or has been Select the proper cycle as indicated by the...
