MODEL NUMBER CDC17P0AWW
x
Please keep the manual
for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDC17P0AWW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Comfee CDC17P0AWW

Summary of Contents for Comfee CDC17P0AWW

  • Page 1 MODEL NUMBER CDC17P0AWW Please keep the manual for future reference.
  • Page 2 QUICK START GUIDE Please read the corresponding content for detailed operating method. Connecting to Power Supply The power supply is 120VAC 60Hz The specification of the socket is 10A 120VAC The connection of the drain pipe: Put end of the drain into a sink or bucket. The clamp must be tightened by a screwdriver.
  • Page 3 Prep the Dishware Remove the large residue on the dishware and glasses before placing into the dishwasher. Loading The Dishwasher Place dishes in the dishwasher in order by size and starting from the two ends, then load into the middle. All cutlery are suggested to be tilted to improve cleaning performance.

  • Page 4: Table Of Contents

    CONTENTS Please carefully read this manual before using the dishwasher, it will help you use and maintain the dishwasher properly . IMPORTANT SAFETY INSTRUCTIONS GETTING TO KNOW YOUR APPLIANCE Dishwasher Features Control Panel USING YOUR DISHWASHER Loading The Dishwasher Baskets Loading The Detergent PROGRAMMING THE DISHWASHER Wash Cycle Programs...

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING When using your dishwasher , follow the precautions listed below: This appliance is intended to be used in household and similar applications such as: -Staff kitchen areas in shops, offices and other working environments; -Households; -by clients in hotels, motels and other residential type environments; -bed and breakfast type environments.
  • Page 6 General use Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. Do not operate your dishwasher unless all enclosure panels are properly in place. Open the door very carefully if the dishwasher is operating, there is a risk of water squirting out.
  • Page 7 Disposal For disposing of package and the appliance please go to a recycling centre. Therefore cut off the power supply cable and make the door closing device unusable. Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.

  • Page 8: Getting To Know Your Appliance

    GETTING TO KNOW YOUR APPLIANCE IMPORTANT: Before using this dishwasher for the first time and to get the best performance, read these instructions. Dishwasher features Handle Control panel Kick board Upper Spray Arm Water Tank Cap Lower Spray Arm Filter Detergent Dispenser Tableware Basket Basket...

  • Page 9: Control Panel

    Control panel LOCK To turn on and off. POWER Program Button: Press the button to select wash cycles CYCLES P1(STEAM ) -P2 (GLASS) -P 3(FRUIT). STEAM: High temp for washing baby bottles etc.(Steam Adding). GLASS: Suitable for washing delicate ware with light soiled. FRUIT: Suitable for washing hard surface fruit.

  • Page 10: Using Your Dishwasher

    USING YOUR DISHWASHER Loading The Dishwasher Recommendation Consider buying utensils which are identified as dishwasher-proof. Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further information from detergent manufacturers. For particular items, select a program with lower temperatures. To prevent damage, do not take glass and cutlery out of the dishwasher immediately after the program has ended.
  • Page 11 All utensils are placed in the way that the spray arms can rotate freely during washing. NOTE Very small items should not be washed in the dishwasher as they could easily fall out of the basket. Load hollow items such as cups, glasses, pans etc. with the opening facing downwards so thatwater cannot collect in the container or a deep base.
  • Page 12 Recommended loading layout with 1 serving bowl and 2 settings personal tableware. 2×Dinner plates(10in) 2×Bread and butter plates (6.7in) 2×Dessert bowls(5in) 2×Cups 2×Saucers(5.5in) 2×Glasses(12.5OZ) 2×Dinner forks 2×Salad forks 2×Knives 2×tea spoons × 1 Serving bowl(1L) 1×Oval platter(9.5in) 1×Serving forks 2×Serving spoons Folding Down The Rack Shelves The spikes are used for holding plates and a platters.

  • Page 13: Loading The Detergent

    Loading The Detergent This product don't support to add rinse aid. It only need to add detergent. WARNING Only use detergent specifically for dishwashers. Never use any other rinse aid and detergents. This will damage the appliance. Dishwasher detergent is corrosive! Keep dishwasher detergent out of the reach of children.
  • Page 14 Adding detergent Detergent Dispenser -14-...

  • Page 15: Programming The Dishwasher

    PROGRAMMING THE DISHWASHER Wash Cycle Programs The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. Cycle Selection Description Program Detergent Time Energy...

  • Page 16: Turning On The Appliance

    Turning On The Appliance Starting a wash cycle... Draw out the basket(see the section entitled "Loading the Dishwasher"). Pour in the detergent (see the section“Fill the detergent”). Insert the plug into the socket. The power supply is 120VAC 60HZ, Press the power button to turn on the appliance, Connect the inlet hose to the tap, make sure that the water supply is turned on to full pressure, or add water to the tank manually.

  • Page 17: Forget To Add A Dish

    NOTE If you open the door during washing, the machine will pause. When you and press the Start/Pause Button, the machine will keep on working after 10 seconds. Forget to add a dish? A forgotten dish can be added any time before the detergent dispenser opens. If this is the case, follow the instructions below: 1.

  • Page 18: End Of The Wash Cycle

    End Of Wash Cycle When the working cycle has finished, the buzzer of dishwasher will sound 8 seconds, then stop. Turn off the appliance using the ON/OFF button, shut off the water supply and open the door of the dishwasher. Wait a few minutes before unloading the dishwasher to avoid scald, the dishes and utensils are still hot and more susceptible to breakage.

  • Page 19: Maintenance And Cleaning

    MAINTENANCE AND CLEANING Filter System WARNING Never use the dishwasher without filters! Make sure the filter is properly assembled. The performance may be affected and dishes and utensils could become damaged. The filter efficiently removes food particles from the wash water, allowing it to be recycled during the cycle.

  • Page 20: Dishwasher Care

    NOTE To re-install the filter system, complete Step 2 to Step 1. The entire filter assembly should be cleaned once a week. Inspect the filters for blockages after every time the dishwasher has been used. By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water.
  • Page 21 Protect against freezing Please take frost protection measures on the dishwasher in winter. Each time after washing cycles, please operate as follows. 1. Cut off electrical power to the dishwasher. 2. Turn off the water supply and disconnect the water inlet pipe from the water valve.

  • Page 22: Dishwasher Maintenance

    Dishwasher Maintenance After Every Wash After every wash, turn off the water supply to the appliance and leave the door slightly open so that moisture and odors are not trapped inside. Remove The Plug Before cleaning or performing maintenance, always remove the plug from the socket.

  • Page 23: Installation Preparation

    INSTALLATION WARNING Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. Attention The installation of the pipes and electrical equipments should be done by professionals. Installation preparation The installation position of dishwasher should be near the existing water inlet tap and drain outlet and power socket.

  • Page 24: About Power Connection

    About Power Connection WARNING For personal safety: Do not use an extension cord or an adapter plug with this appliance. Do not, under any circumstances, cut or remove the earthing connection from the power cord. Electrical Requirements Please look at the rating label to know the rating voltage and connect the dishwasher to the appropriate power supply.

  • Page 25: Connection Of Drain Hoses

    Connection of drain hoses The clamps must be tightened with a screwdriver. ubber stopper Fix the drain pipe with suction cups The connection of the drain pipe: Put end of the drain into a sink or bucket. How to Drain Excess Water From Hoses If the sink is more than 39 1/4"...

  • Page 26: Troubleshooting Tips

    TROUBLESHOOTING TIPS Before calling for service Reviewing the charts on the following pages may save you from calling for service. Problem Possible Causes What To Do Dishwasher doesn't Fuse blown, or the Replace fuse or reset circuit breaker. start circuit break tripped. Remove any other appliances sharing the same circuit with the dishwasher.
  • Page 27 Problem Possible Causes What To Do Spilled rinse-aid. Always wipe up rinse-aid spills immediately. Stained tub interior Detergent with Make sure that the detergent has no colorant may colorant. have been used. White film on Hard water minerals. To clean the interior, use a damp inside surface sponge with dishwasher detergent and wear rubber gloves.
  • Page 28 Problem Possible Causes What To Do The dishes Not enough detergent Use more detergent, or change are not clean. was dispensed. your detergent. Items are blocking Rearrange the items so that the spray the movement of can rotate freely. the spray arms. The filter combination Clean and/or fit the filter correctly.

  • Page 29: Error Codes

    Problem Possible Causes What To Do Wrong program has The dishes are With a short program, the not drying been selected. washing temperature is lower, decreasing cleaning performance. Choose a program with a long washing time. Use of cutlery with a Water drainage is more difficult with low-quality coating.

  • Page 30: Technical Information

    Technical Information 17 1/4" (438mm) 17 1/4" (438mm) Height Width 16 9/16" (420mm) Depth 17 1/8" (435mm) Voltage connected Load see rating label 0.04 - 1.0MPa Water pressure see rating label Power supply 2 place setting(AHAM) Capacity -30-...

  • Page 31: Warranty

    1 Year Limited Warranty This is the only express warranty for the product and in lieu of any other warranty or condition. This product is warranted to be free from defects in material and workmanship for a period of one year from the date of original purchase. During this period, your exclusive remedy is repair of replacement of this product or any component found to be defective, at our option;...
