LED Group Robus RVB007RGB10I65 Instruction Manual

VIBE IP65 5/10M LED STRIP, RGB
7.2/14.4W/M WITH RGB CONNECTOR
STARTER PACK
RVB007RGB10I65, RVB014RGB05I65
PLEASE READ INSTRUCTION BEFORE COMMENCING INSTALLATION AND RETAIN FOR FUTURE REFERENCES.
! Electrical products can cause death or injury, or damage to property. If in any doubt about the installation or
use of this product, consult a competent electrician
Product technical information and specification may change over time without prior notification
For the latest technical information please visit our web site WWW. ledgrouprobus. com or robusdirect. com

Specifications

Modle NO.: RVB007RGB10I65
Voltage: 24V
Power: 7.2W/m
o
Beam angle: 120
IP: 65
Ta range: -20°C~45°C
Safety class: class III
Dimensions:
L:10m W:12mm D:4mm
Weight: 5.6Kg

Installation:

surface mounted
Warranty: 3 years

Driver for striplight

RVB007RGB10I65
1-5M 5-10M 10-20M
RVB060-PSU
RVB100-PSU
RVB200-PSU
Driver for striplight
RVB014RGB05I65 1-5M
RVB060-PSU
RVB100-PSU
RVB200-PSU
Information for the Product user:
1. Please note the requirement to dispose of Waste Electrical & Electronic Equipment separately from household waste (WEEE marked with
crossed out wheelie bin symbol).
2. Please consider your role in contributing to re-use and recycling by returning this product at end of life to a collection centre for waste electrical
equipment or a Civic Amenity site, or to a retail outlet from which you are purchasing a replacement.
3. This equipment may contain substances that are hazardous to health and the environment if disposed of carelessly. It is important that it is
separated from normal household waste and recycled in the WEEE chain
4. The "crossed out wheelie bin symbol" on a product indicates this equipment must not be disposed of in normal household waste, but should be
disposed of according to local WEEE regulations
The Installation must be carried out by an electrician
LED Group
Western Retail Park
Nangor Road
Dublin 12
Ireland
Issue 1 040914
RVB014RGB05I65
24V
14.4W/m
o
120
65
-20°C~45°C
class III
L:5m W:12mm D:4mm
2.8Kg
surface mounted
3 years
Tel: +353 1 7099000
Fax: +353 1 7099060
Email: info@led.ie
Website: www.led.ie
Note:
Installation
1 Ensure mains supply is switched off before commencing work.
2 If necessary cut LED strip to the required length at the locations
marked on the strip (Every 5 LED's for RVB007, 6 LED's for RVB014).
(See cutting and joining instruction diagram)
Note: This strip is IP65 rated. When cut or joined the IP rating cannot
be guaranteed

3 Mounting the Strip:

a. Self adhesive strip: Remove the protective film to reveal adhesive
strip. Place the strip onto the desired location and press down
firmly. Ensure the strip is secure.
b. Clips: Place the strip along the desired position. Mark the locations
where the clips are required, keeping them equally spaced. Fix clips
to surface using screws. Check that the screws will not impinge
on concealed cables or pipes.
4 The "wire connector" is used extend or join the strip. It is marked with
"+" black wire and "-" red, green and blue wire, which will correspond
with "+, R,G and B on the LED strip. Connect connector to strip. (See
cutting and joining IM).
(Note that when the wire connector is used to connect to
RVBRGB-AMP or extending the strip the connection sequence will be
reversed on the next connection).
5 Please see installation diagram and choose the most suitable
installation method.
Note: When connected in series it is not possible to extend the strip to
lengths longer than which are supplied
However strips may be connected in parallel up to the max rating of
the power supply used
6 Connect the strips to the driver (choose the correct driver based on
the length of the strip). Please use IP box for the connection. (RVBIP1
for wire connector, RVBIP2 for dimmer controller and amplifier
INSTRUCTION MANUAL
ISO 9001:2008
Q UAL IT Y ASSU RE D CO MPANY
1
