  • Page 1 W550SU1 / W555SUW...
  • Page 3 Preface Notebook Computer W550SU1 / W555SUW Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W550SU1 / W555SUW series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Bottom (W550SU1) ............... A-5 Bottom (W555SUW) ..............A-6 Overview ..................1-1 COMBO ..................A-7 Specifications ..................1-2 DVD DUAL ................... A-8 External Locator - Top View with LCD Panel Open ......1-4 Dummy ODD ................. A-9 External Locator - Front & Right Side Views .........1-5 LCD (W550SU1) .................
  • Page 12 Preface WLAN, 3G, MSATA ..............B-24 HDD, CCD, TPM, Power Con ............. B-25 USB3.0, LED, USB Charger ............B-26 Card Reader (RTL8411B) ............B-27 TP, Audio Con, G-Sensor ............B-28 HDMI, RJ45, Fan ................. B-29 ALC269Q, VT1802S ..............B-30 KBC-ITE IT8587 ................. B-31 5VS, 3VS, 1.5VS CPU ..............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W550SU1 / W555SUW series notebook comput- er. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Infor- mation about dri-vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Storage Intel® Core™ i7 Processor (Factory Option) One 12.7mm(h) Optical Device Type Drive (Super Multi Drive/Blu-Ray Combo Drive/Blu-Ray i7-4702MQ (2.20GHz) Writer Drive) 6MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 37W  (Factory Option) Dummy ODD i7-4600M (2.90GHz) Latest Specification Information One Changeable 2.5"...
  • Page 15 Introduction Mini Card Slots Environmental Spec Slot 1 for WLAN Module or WLAN and Bluetooth Combo Temperature Module ° ° Operating: 5 C - 35 (Factory Option) Slot 2 for 3G Module or mSATA SSD Non-Operating: -20°C - 60°C Relative Humidity Interface Operating: 20% - 80% One HDMI-Out Port...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 3. Built-In Microphone 4. LCD 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Power Indicator 2. Multi-in-1 Card FRONT VIEW Reader Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone-Out Jack 3. USB 2.0 Ports 4.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor LEFT SIDE VIEW Port 4. Vent 5. HDMI-Out Port 6. USB 3.0 Ports Figure 5 REAR VIEW Rear View 1.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Component Bay Cover 3. Vent 4. Hard Disk Bay Cover 5. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector (3G Module) 2. CPU Socket (no CPU installed) 3. Memory Slots DDR3L SO-DIMM 4. Mini-Card Connector (WLAN Module) 5. Audio Codec Realtek LC269Q 6. CMOS Battery 7.

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. USB Port 3.0 3. Speaker Cable Connector 4. Microphone Cable Connector 5. USB Port 2.0 Connector 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. ODD Connector 2. HDD Connector 3. Power Button Cable Connector 4. Keyboard Cable Connector 5. TouchPad Cable Connector 6. Fan Cable Connector 7. Multi-in-1 Card Reader 8. External Monitor Port 9.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W550SU1 / W555SUW series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the 3.75G Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide the latch and hold it 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a in place.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 3. Lift the hard disk bay cover from point (Figure 3b Figure 3 4. Remove the hard disk bay cover (Figure 3b HDD Assembly 5. Grip the tab and slide the hard disk assembly in the direction of arrow (Figure 3c Removal (cont’d.) 6.

  • Page 32: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 4 Optical Device 1. Turn off the computer, and remove the battery (page 2 - Removal 2. Locate the component bay cover and remove screws (Figure 4a 3. Remove the component bay cover (Figure 4b a.
  • Page 33 Disassembly 4. Remove the screw at point (Figure 5c Figure 5 5. Use a screwdriver to carefully push out the optical device at point (Figure 5d Optical Device 6. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The Removal (cont’d.) screw holes should line up).

  • Page 34: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 6 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L Up to 1600 MHz. The main memory can be expanded up to 16GB. The total memory size is automatically de- tected by the POST routine once you turn on your computer.
  • Page 35 Disassembly 5. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the Figure 7 arrows (Figure 7c). The RAM module will pop-up Figure 7d , and you can then remove it RAM Module 6.

  • Page 36: Removing And Installing A Processor

    Disassembly Removing and Installing a Processor Figure 8 Processor Removal Processor Removal Procedure 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and the component bay cover (page 2 - a. Locate the CPU heat sink.
  • Page 37 Disassembly 6. Carefully (it may be hot) remove the heat sink unit off the computer (Figure 9e Figure 9 7. Turn the release latch towards the unlock symbol to release the CPU (Figure 9f). Processor Removal 8. Carefully (it may be hot) lift the CPU up and out of the socket (Figure 9g).
  • Page 38 Disassembly Processor Installation Procedure Figure 10 Processor 1. Insert the CPU (Figure 10a), and pay careful attention to the pin alignment; it will fit only one way (DO NOT Installation FORCE IT!), and turn the release latch towards the lock symbol (Figure 10b).

  • Page 39: Removing The Wireless Lan Module And Keyboard

    Disassembly Removing the Wireless LAN Module and Keyboard Figure 11 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - 5) and the component bay cover (page 2 - Module and 2. The Wireless LAN module will be visible at point on the mainboard and keyboard ribbon cable under the Wire- Keyboard Removal less LAN module...
  • Page 40 Disassembly 6. Disconnect cables (Figure 12e). Figure 12 7. Remove screws from the bottom case. Keyboard Removal 8. Turn the computer over, carefully pry the top case off the bottom case at points (Figure 12g). 9. Separate the top case up and off the bottom case (Figure 12h)
  • Page 41 Disassembly 10. Remove screws from the top case. Figure 13 11. Remove screws from the keyboard shielding plate (Note: when removing special screws , you’ll Keyboard Removal need to use an (#0 head) electric screwdriver - set to a low spin of 300r.p.m. and low torque at 0.1~1.5kgf.cm. The (cont’d) Lock torque should be set to 0.35~0.45kgf.cm, and should not be exceeded or it may cause screw damage).

  • Page 42: Removing The 3.75G Module

    Disassembly Removing the 3.75G Module Figure 14 3G Module Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 12) and the component bay cover (page 2 - 10). 2. The 3.75G module will be visible at point on the mainboard (Figure 14a).

  • Page 43: Removing The Ccd

    Disassembly Removing the CCD Figure 15 CCD Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 12). 2. Carefully remove the rubber screw covers and screws from the front cover (Figure 15a). a. Carefully remove 3.
  • Page 44 Disassembly 6. Disconnect the cable Figure 16 7. Remove the CCD module (Figure 16f). CCD Removal 8. Reverse the process to install a new CCD module. (cont’d) e. Disconnect the cable. f. Remove the CCD mod- ule.  15. CCD Module 2 - 20 Removing the CCD...

  • Page 45: Part Lists

    Appendix A:Part Lists This appendix breaks down the W550SU1 / W555SUW series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 46: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part W550SU1 W555SUW Location page A - 3 page A - 4 Bottom page A - 5...

  • Page 47: Top (W550Su1

    Top (W550SU1) Figure A - 1 Top (W550SU1) Top (W550SU1) A - 3...

  • Page 48: Top (W555Suw

    Top (W555SUW) Figure A - 1 Top (W555SUW) A - 4 Top (W555SUW)

  • Page 49: Bottom (W550Su1

    Bottom (W550SU1) Figure A - 2 Bottom (W550SU1) 頭厚 Bottom (W550SU1) A - 5...

  • Page 50: Bottom (W555Suw

    Bottom (W555SUW) Figure A - 3 Bottom (W555SUW) 頭厚 A - 6 Bottom (W555SUW)

  • Page 51: Combo

    COMBO Figure A - 4 COMBO COMBO A - 7...

  • Page 52: Dvd Dual

    DVD DUAL Figure A - 5 DVD DUAL A - 8 DVD DUAL...

  • Page 53: Dummy Odd

    Dummy ODD Figure A - 6 Dummy ODD Dummy ODD A - 9...

  • Page 54: Lcd (W550Su1

    LCD (W550SU1) Figure A - 7 LCD (W550SU1) 頭厚 A - 10 LCD (W550SU1)

  • Page 55: Lcd (W555Suw

    LCD (W555SUW) Figure A - 8 LCD (W555SUW) 頭厚 LCD (W555SUW) A - 11...
  • Page 56 A - 12...

  • Page 57: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W550SU1 / W555SUW notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...
  • Page 58 Schematic Diagrams System Block Diagram Audio Board W5xxSU System Block Diagram (Shark Bay) SHEET 37 VDD3,VDD5 SHEET 33 Power Switch Board SHEET 38 5V,3V,5VS,3VS SHEET 31 Haswell Audio Board PS8625 1.05VS SHEET 39 (W550SU) PROCESSOR (EDP TO LVDS) SHEET 32 SHEET 11 ODD Board rPGA946B...
  • Page 59 Schematic Diagrams Processor 1/7- DMI, FDI, PEG Haswell rPGA Processor 1/7 ( DMI,PEG,FDI ) VCCIOA_OUT U17A Haswell rPGA EDS PEG_IRCOMP 24.9_1%_04 PEG_RCOMP PEG_RXN_0 DMI_TXN0 DMI_RXN_0 PEG_RXN_1 DMI_TXN1 DMI_RXN_1 PEG_RXN_2 DMI_TXN2 DMI_RXN_2 PEG_RXN_3 DMI_TXN3 DMI_RXN_3 PEG_RXN_4 PEG_RXN_5 DMI_TXP0 DMI_RXP_0 PEG_RXN_6 DMI_TXP1 DMI_RXP_1 PEG_RXN_7 DMI_TXP2...
  • Page 60 Schematic Diagrams Processor 2/7- CLK, MISC Haswell Processor 2/7 ( CLK,MISC,JTAG ) 1.05V_LAN_M Processor Pullups/Pull downs H_THRMTRIP_R_N *100_04 R301 VCCIO_OUT CPU_RST_N *75_04 R312 62_04 R309 H_PROCHOT# DDR3 Compensation Signals 10K_04 R297 H_CPUPWRGD_R SM_RCOMP_0 R327 100_1%_04 TRACE WIDTH 10MIL, LENGTH <500MILS SM_RCOMP_1 R324 75_1%_04...
  • Page 61 Schematic Diagrams Processor 3/7- DDR3 Haswell Processor 3/7 ( DDR3 ) M_A_DQ[63:0] M_B_DQ[63:0] Haswell rPGA EDS U17C Haswell rPGA EDS U17D M_A_DQ0 AR15 SA_DQ_0 RSVD_AC7 M_A_DQ1 AT14 M_B_DQ0 AR18 SA_DQ_1 SA_CK_N_0 M_A_CLK_DDR#0 SB_DQ_0 RSVD M_A_DQ2 AM14 M_B_DQ1 AT18 M_A_CLK_DDR0 M_B_CLK_DDR#0 SA_DQ_2 SA_CK_P_0 SB_DQ_1...

  • Page 62: Processor 4/7- Power

    Schematic Diagrams Processor 4/7- Power Haswell Processor 4/7 ( POWER ) Short V_VCCDDQ V_VDDQ_DIMM *OPEN-3mm 0.1u_10V_X5R_04 0.1u_10V_X5R_04 VCCIN Haswell rPGA EDS U17E PROCESSOR CORE POWER AA26 V_VCCDDQ ICCMAX Maximum Processor SV 48 AA28 VCCIN AA34 4.2A RSVD AA30 RSVD AA32 RSVD C331 C329...

  • Page 63: Processor 5/7- Gfx Pwr

    Schematic Diagrams Processor 5/7- GFX PWR Haswell Processor 5/7 ( GRAPHICS POWER ) VCCIOA_OUT 3.3VS EDP_RCOMP 24.9_1%_04 EDP_UTIL *10K_04 VCCIO_OUT U17H Haswell rPGA EDS DP_AUXN DDIB_TXBN_0 EDP_AUXN DP_AUXP DDIB_TXBP_0 EDP_AUXP DP_HPD# DDIB_TXBN_1 EDP_HPD EDP_RCOMP 10K_04 Sheet 6 of 45 DDIB_TXBP_1 EDP_RCOMP EDP_UTIL DDIB_TXBN_2...

  • Page 64: Processor 6/7- Gnd

    Schematic Diagrams Processor 6/7- GND Haswell Processor 6/7 ( GND ) Haswell rPGA EDS U17F Haswell rPGA EDS U17G AK34 AL10 AL11 AL12 AL14 AL15 AL17 AL18 AL20 AL21 AL23 AA11 AA25 AA27 AA31 AA29 AB10 AA33 AA35 AM10 AM13 AC25 AM16 AC27...

  • Page 65: Processor 7/7- Rsvd

    Schematic Diagrams Processor 7/7- RSVD Haswell Processor 7/7 ( RESERVED ) CFG Straps for Processor PCI EXPRESS STATIC LANE REVERSAL FOR ALL PEG PORTS 1: (DEFAULT)NORMAL OPERATION; (Default) CFG2 LANE# DEFINITION MATCHES 0: LANE REVERSAL U17I Haswell rPGA EDS CFG2 *1K_04 RSVD_TP RSVD_TP...

  • Page 66: Ddr3 So-Dimm_0

    Schematic Diagrams DDR3 SO-DIMM_0 SO-DIMM A_0 V_VDDQ_DIMM CHANGE TO STANDARD C357 C103 C359 C100 0.1u_10V_X5R_04 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 0.1u_10V_X5R_04 0.1u_10V_X5R_04 JDIMM1A M_A_A[15:0] M_A_DQ[63:0] M_A_A0 M_A_DQ0 JDIMM1B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 V_VDDQ_DIMM V_VDDQ_DIMM M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VDD1 VSS16 M_A_A6 M_A_DQ6 VDD2 VSS17...

  • Page 67: Ddr3 So-Dimm_1

    Schematic Diagrams DDR3 SO-DIMM_1 SO-DIMM B_0 CHANGE TO STANDARD JDIMM2B V_VDDQ_DIMM JDIMM2A M_B_A[15:0] M_B_DQ[63:0] M_B_A0 M_B_DQ0 M_B_A1 M_B_DQ1 VDD1 VSS16 M_B_A2 M_B_DQ2 VDD2 VSS17 M_B_A3 M_B_DQ3 VDD3 VSS18 M_B_A4 M_B_DQ4 VDD4 VSS19 M_B_A5 M_B_DQ5 VDD5 VSS20 M_B_A6 M_B_DQ6 VDD6 VSS21 M_B_A7 M_B_DQ7 VDD7...

  • Page 68: Ps8625

    Schematic Diagrams PS8625 3.3VS 3.3VS VDDIO PWM_IN R474 *0_04 PANEL_PWM HCB1005KF-121T20 HCB1005KF-121T20 BCNR3010C-2R2M HCB1005KF-121T20 VDDIOX SW_OUT VDD12 VDDRX R286 R285 10K_04 10K_04 C310 C309 C299 RTD_PLVDD_EN RTD_PLVDD_EN 0.47u_10V_Y5V_04 1u_6.3V_X5R_04 0.47u_10V_Y5V_04 4.7u_6.3V_X5R_06 4.7u_6.3V_X5R_06 *4.7u_6.3V_X5R_06 ENBLT 1u_6.3V_X5R_04 ENBLT C312 C311 PANEL_PWM PANEL_PWM 1u_6.3V_X5R_04 2.2u_6.3V_X5R_04 8625_GNDA...

  • Page 69: Panel, Inverter

    Schematic Diagrams Panel, Inverter PANEL POWER BRIGHTNESS PANEL CONNECTOR (30Pin_eDP & 40Pin_LVDS CO-lay) *10K_04 PLVDD VLED OPEN_2A BRIGHTNESS_R *20mil_04 PANEL_PWM Q11A *MTS3572G6 D02A 3.3V 3.3VS *0.22u_50V_Y5V_06 4.7K_04 R279 *4.7K_06 LED PANEL (LVDS Dual Channel). 4.7K_04 R282 1M_04 *10K_04 VLED *100K_04 Q12A J_LCD2 LVDD_EN#...

  • Page 70: [13] Crt

    Schematic Diagrams 5VS_CRT RB551V-30S2 J_CRT1 3.3VS C10556-11505-L *20mil_04 FCM1005MF-600T01 FRED DAC_RED 2.2K_8P4R_04 *20mil_04 FCM1005MF-600T01 FGRN DAC_GREEN *20mil_04 FCM1005MF-600T01 FBLUE DAC_BLUE C326 C325 C324 DDCDATA DDCDATA HSYNC DAC_DDCADATA DDC_IN1 DDC_OUT1 DDCLK VSYNC DAC_DDCACLK DDC_IN2 DDC_OUT2 HSYNC_C R306 33_04 HSYNC DDCLK DAC_HSYNC SYNC_IN1 SYNC_OUT1 VSYNC_C...

  • Page 71: Lynx 1/9 - Rtc, Hda, Sata

    Schematic Diagrams Lynx 1/9 - RTC, HDA, SATA Lynx Point - M (HDA,JTAG,SATA) RTCVCC BAT54CS3 VDD3 C268 1u_6.3V_X5R_04 RTC_VBAT_1 C393 R249 18p_50V_NPO_04 2011/12/29 20K_1%_04 RTC_RST# R252 6-22-32R76-0B2 6-22-32R76-0BG R385 LPT_PCH_M_EDS 1K_04 C257 JOPEN1 U24A 1u_6.3V_X5R_04 *OPEN_10mil-1MM MC-306_32.768KHz 10M_04 SATA_RXN0 RTC CLEAR J_RTC1 SATA ODD SATA_RXN_0...

  • Page 72: Lynx 2/9 - Lpc, Smbus, Spi, C-Link

    Schematic Diagrams Lynx 2/9 - LPC, SMBUS, SPI, C-LINK NO REBOOT STRAP 3.3VS NO REBOOT STRAP: HDA_SPKR High Enable 3.3V_PCH 10K_04 R153 LPC_SIRQ 2.2K_8P4R_04 SML0_CLK Lynx Point - M (LPC,SMBUS,SPI,C-LINK) SML0_DATA iTPM ENABLE/DISABLE SMB_DATA TPM FUNCTION:SPI_SI High Enable SMB_CLK *1K_04 R334 SPI_SI PCH_GPIO74...

  • Page 73: Lynx 3/9 - Dmi, Fdi, Pwrgd

    Schematic Diagrams Lynx 3/9 - DMI, FDI, PWRGD Lynx Point -M (DMI,FDI,PWRGD) 3.3VS LPT_PCH_M_EDS PM_CLKRUN# U24B R127 8.2K_04 AW22 DMI_RXN0 DMI_RXN_0 AR20 AC_PRESENT R185 *100K_04 DMI_RXN1 DMI_RXN_1 AJ35 FDI_TXN0 FDI_RXN_0 AP17 DMI_RXN2 DMI_RXN_2 AV20 AL35 FDI_TXN1 DMI_RXN3 DMI_RXN_3 FDI_RXN_1 RTCVCC AY22 AJ36 FDI_TXP0...

  • Page 74: Lynx 4/9 - Crt, Lvds, Pci

    Schematic Diagrams Lynx 4/9 - CRT, LVDS, PCI 3.3VS BLON *1K_04 R239 L_BRIGHTNESS_R *1K_04 R240 DGPU_HOLD_RST# 10K_04 R400 HDMI_CTRLDATA 2.2K_04 R243 HDMI_CTRLCLK 2.2K_04 R246 Lynx Point -M (CRT,LVDS,PCI,DISPLAY) 10K_8P4R_04 Boot BIOS Strap CRIT_TEMP_REP#_R CRIT_TEMP_REP#_R D_GPU_PWM_SELECT# BBS_BIT1 BBS_BIT0 Boot BIOS Location SB_KBCRST# 18,30 SB_KBCRST#...

  • Page 75: Lynx 5/9 - Gpio, Misc, Nctf

    Schematic Diagrams Lynx 5/9 - GPIO, MISC, NCTF Lynx Point - M (GPIO,CPU/MISC,NCTF) 3.3V_PCH R154 10K_04 HOST_ALERT#1 R164 10K_04 PCH_GPIO8 PLL_ODVR_EN R172 *10K_04 U24F LPT_PCH_M_EDS R183 10K_04 PCH_GPIO27_R S_GPIO R162 100_04 S_GPIO_R BMBUSY#/GPIO0 R200 10K_04 PM_LANPHY_ENABLE SMI# SMI# TACH1/GPIO1 R215 *1K_04 PM_LANPHY_ENABLE R170...

  • Page 76: Lynx 6/9 - Pcie, Usb

    Schematic Diagrams Lynx 6/9 - PCIe, USB Lynx Point -M (PCIe,USB) 3.3V_PCH 2.0 P O R T RN13 U S B 2 7 P O R T U S B 3 . 0 U24I LPT_PCH_M_EDS 10K_8P4R_04 USB_OC#01 AW31 USB_OC#1011 PCIE_RXN1_CARD USB_PN0 PERN1/USB3RN3 USB2N0...

  • Page 77: Lynx 7/9 - Pwr

    Schematic Diagrams Lynx 7/9 - PWR Lynx Point -M (POWER) 0.1A 1.5A VCCA_DAC_1_2 1.5VS U24G LPT_PCH_M_EDS 1.05V_LAN_M HCB1608KF-121T25 VCCADAC1_5 AA24 C266 C264 AA26 CRT DAC C277 C274 C153 C210 C222 C194 AD20 VCCADACBG3_3 AD22 10u_6.3V_X5R_06 1u_6.3V_X5R_04 1u_6.3V_X5R_04 1u_6.3V_X5R_04 AD24 AD26 BB44 VCCVRM AD28...

  • Page 78: Lynx 8/9 - Power

    Schematic Diagrams Lynx 8/9 - POWER Lynx Point - M (POWER) 3.3V_PCH 3.3V PJ14 *OPEN-2mm 3.3V_PCH 0.015A 3.3V_PCH PJ15 VDD3 0.261A *OPEN-2mm C225 C238 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 LPT_PCH_M_EDS C242 U24H 0.1u_16V_Y5V_04 3.3V_PCH Default 1.05V_LAN_M VCCSUS3_3 VCCSUS3_3 Sheet 21 of 45 VCCSUS3_3 VCCSUS3_3 R232 *20mil_04...

  • Page 79: Lynx 9/9 - Clk, Gnd

    Schematic Diagrams Lynx 9/9 - CLK, GND Lynx Point -M (GND) Lynx Point -M (CLK) U24K LPT_PCH_M_EDS AA16 AA20 LPT_PCH_M_EDS AA22 U24C AA28 AB12 AB35 CLKOUT_PCIE_N_0 CLKOUT_PEG_A AB34 AB38 BA40 AB36 CLKOUT_PCIE_P_0 CLKOUT_PEG_A_P BD11 PEG_CLKREQ# BD15 PCIECLKRQ0# PCIECLKRQ0#/GPIO73 PEGA_CLKRQ#/GPIO47 AC44 BD19 AD14 AY36...

  • Page 80: Wlan, 3G, Msata

    Schematic Diagrams WLAN, 3G, MSATA 3G/MSATA MINI CARD C297 220u_6.3V_6.3*6.3*4.2 C316 0.1u_16V_Y5V_04 J_3G1 60mils 6-36-00180-202 3G_3.3V WAKE# 3.3V_0 3G_3.3V BT_DATA 1.5V_0 UIM_PWR BT_CHCLK UIM_PWR 3G POWER UIM_DATA UIM_PWR *4.7K_04 UIM_DATA SIM CONN UIM_DATA UIM_CLK CLKREQ# UIM_CLK C314 UIM_RST M S A T A f u n c t i o n REFCLK- UIM_RESET 0.1u_16V_Y5V_04...

  • Page 81: Hdd, Ccd, Tpm, Power Con

    Schematic Diagrams HDD, CCD, TPM, Power Con SLB9655TT & NPCT420 COLAY HDD CONNECTOR (CO-LAY) TPM 2.0 13&7 PRXQW J_HDD1 Gen3 J_HDD2 R100 *0_04 3.3V SATA_TXP5_R C415 0.01u_16V_X7R_04 SATA_TXP5_R 6/% PRXQW SATA_TXP5 SATA_TXN5_R SATA_TXN5_R C411 0.01u_16V_X7R_04 0_04 SATA_TXN5 15,30 LPC_AD0 3.3VS LAD0 15,30 LPC_AD1...

  • Page 82: Usb3.0, Led, Usb Charger

    Schematic Diagrams USB3.0, LED, USB Charger USB Charger PORT 3.3VS R393 *0_04 16,30,31,32,9 SUSB# HDD LED AIRPLAN LED R397 0_04 USB_DD_ON# R271 R270 30,31,33 DD_ON PRE# USB_PN0 USB_PN0_R 220_04 220_04 USB_PN0 USB_PP0 USB_PP0_R USB_PP0 WLAN LED R409 10K_04 VDD5 VDD5 C406 SLG55583VTR WLAN ON...

  • Page 83: Card Reader (Rtl8411B

    Schematic Diagrams Card Reader (RTL8411B) LAN (RTL8411B) 4 IN 1 SOCKET SD/MMC/MS/MS Pro CO-LAY Crystal 503 2 SI Z E RSET R159 2.49K_1%_04 Switching Regulator close to PIN48 meet realtek Freq tolerance 50ppm J_CARD-REV1 R160 *1K_04 SD_CD# CD_SD XTAL2 R151 0_06 SD_D2/MS_CLK_R DAT2_SD...

  • Page 84: Tp, Audio Con, G-Sensor

    Schematic Diagrams TP, Audio Con, G-Sensor TP CONN 3.3V G Sensor 5VS_TP 10u_6.3V_X5R_06 C376 R427 *28mil_06 0.1u_10V_X7R_04 C377 C420 C419 3.3V_GSENSOR 3.3V_GSENSOR R429 R428 W54/W55 *10u_6.3V_X5R_06 1u_6.3V_X5R_04 J_TP1 10K_04 10K_04 R360 *20mil_04 TP_CLK TP_CLK TP_DATA TP_DATA TPBUTTON_L TPBUTTON_R C418 C417 C378 0.1u_10V_X7R_04 47p_50V_NPO_04...

  • Page 85: Hdmi, Rj45, Fan

    Schematic Diagrams HDMI, RJ45, Fan HDMI Repeater no level shief, D9,D10,D11 mount HDMI CONNECTOR ISET 3.3VS HDMI_SDA-C HDMI_CTRLCLK HDMI_SCL-C 5VS_HDMI HDMI_CTRLDATA For ESD 1.5VS 1.5VS 5VS_HDMI FLG# VOUT1 R145 R146 2.2K_04 2.2K_04 VIN1 VOUT2 VIN2 VOUT3 *BAV99 RECTIFIER *BAV99 RECTIFIER 31,34 SUSB C178...

  • Page 86: Alc269Q, Vt1802S

    Schematic Diagrams ALC269Q, VT1802S CODEC (ALC269Q_VB7) DVDD_IO PVDD1_2 3.3VS R430 *28mil_06 R433 *20mil_04 C431 C440 C429 C422 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 976/ XQPRXQW $/&4/ PRXQW 5VS_AUD C428 C286 HCB1005KF-121T20 3.3VS 3.3VS_AUD 0.1u_16V_Y5V_04 10u_6.3V_X5R_06 HCB1005KF-121T20 C292 *1u_6.3V_X5R_04 PD# Control 3.3VS_AUD C432 C426 5VS_AUD C430...

  • Page 87: [30] Kbc-Ite It8587

    Schematic Diagrams KBC-ITE IT8587 KBC_AVDD *CV-40mil HCB1005KF-121T20 R111 10K_04 R112 1K_04 VDD3 VDD3 VDD3 C146 C138 C139 C137 10u_10V_Y5V_08 C168 C167 0.1u_10V_X7R_04 0.1u_10V_X7R_04 0.1u_10V_X7R_04 SUS_PWR_ACK AUTO_LOAD_PWR GPJ0/TACH2 5VT/SSCE0#/GPG2 0.1u_10V_X7R_04 *0.1u_10V_X7R_04 GPJ4/DAC4/DCD0# GPJ5/DAC5/RIG0# C158 ME_WE BT_DET# GPJ2/DAC2//TACH0B KSO16/SMOSI/GPC3 KBC_AGND 0.1u_10V_X7R_04 WLAN_EN KSO17/SMISO/GPC5 3.3VS W54/W55...

  • Page 88: B - 32 5Vs, 3Vs, 1.5Vs Cpu

    Schematic Diagrams 5VS, 3VS, 1.5VS CPU 3.3VS DD_ON# SUSB SLP_A NMOS PQ14A VDD3 VDD3 SYS15V VDD3 MTNN20N03Q8 3.3VS VDD3 PR139 PR136 PR47 PC34 PR134 PC37 PR45 10K_04 100K_04 1M_04 100_04 100K_04 DD_ON# 25,27 SUSB 28,34 3.3VS_EN1 SLP_A 31,32 PQ34B PQ33 PC116 PC113 PC36...
  • Page 89 Schematic Diagrams 1.05V PR141 280K_04 1.05V_LAN_M VTT_SELECT VTT VR Output Voltages IMAX:5A 1.1 V PC124 PC131 PC134 high (V1.1S_VTT) 1.05 V OCP:10A 4.7u_25V_X5R_08 4.7u_25V_X5R_08 1u_6.3V_X5R_04 PR146 1.05V_LAN_M For CV test PR142 3.3V 10_04 PC122 0_06 PJ27 *CV-40mil PC128 0.1u_50V_Y5V_06 TMPC0603H-1R0M-Z01 PR153 10K_04 1u_6.3V_X5R_04...

  • Page 90: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VDD3/VDD5 VREF PR173 *0_04 PR64 *20mil_04 PC51 1u_6.3V_X5R_04 PR161 PR62 EN_3V EN_5V PC150 130K_04 130K_04 PC49 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 PC136 PC137 PC148 PR61 *10K_04 4.7u_25V_X5R_08 4.7u_25V_X5R_08 1u_6.3V_X5R_04 VDD3 LDO3 SYS5V PC140 PC138 PC139 PC48 0.1u_10V_X5R_04 VDD5 PC145 0.1u_50V_Y5V_06 4.7u_25V_X5R_08...

  • Page 91: Ddr 1.5 Or 1.35V, 0.75Vs Pch 1.5Vs

    Schematic Diagrams DDR 1.5 or 1.35V, 0.75VS PCH 1.5VS 1.5V or 1.35V/0.75VS 1.5V or 1.35V PC93 PC95 PC96 PC94 IMAX:8A RB0540S2 G5616 VDDQ_VTT PC103 PQ30 OCP:15A VDDQ 10u_10V_Y5V_08 MTB11N03Q8 PC29 0.1u_10V_X5R_04 VLDOIN VBST Short PJ20 PR117 Short VDDQ_VTT DRVH VDDQ V_VDDQ_DIMM 2.2_04 PJ19...

  • Page 92: Vcore

    Schematic Diagrams VCore 3.3VS PR78 100K_1%_NTC_04 PR109 300K_1%_0603 SWN3 100K_04 PUT COLSE PC25 PC78 PC28 PC53 TO VCORE PR108 300K_1%_0603 SWN1 *4mm Phase 1 PJ18 PR107 PR106 APGND Inductor VIN_CPU *CV-40mil 75K_1%_04 165K_1%_04 PC62 PC55 PC69 PC89 PC21 PQ28 PR77 0_04 VR_EN PC83...

  • Page 93: Charger, Dc In

    Schematic Diagrams Charger, DC IN SMART CHARGER PR23 *20mil_04 PQ21 EMB20P03V V_BAT VJACK PR94 *10K_06 J_DC_JACK1 PL10 6-15-32023-7B0 HCB2012KF-800T80 50932-00301-001 BTD-05TEAB for W540SU1 PQ19 PQ23A J B A T T A 2 *HCB4532K-800T90 EMB20P03V PR67 EMB17A03V PR12 BTD-06RC1B for W94SU 0.01_1%_32 8.2UH_6.8*7.3*3 0.01_1%_32...

  • Page 94: Audio Board

    Schematic Diagrams Audio Board USB PORT AS_USBVCC 60 mil PCBA CHECK ASC3 ASC2 ASC4 0.1u_16V_Y5V_04 1ASR1 *0_04 4ASR1 *0_04 2ASR1 *0_04 5ASR1 *0_04 ASJ_USB1 Port3 ASGND ASL6 3ASR1 *0_04 6ASR1 *0_04 ASUSB_PN1 ASUSB_PN1_R DATA_L ASUSB_PP1 ASUSB_PP1_R DATA_H *WCM2012F2S-161T03-short US04036BCA081 6-21-B49C0-104 6-21-B49B0-104 ASGND TO M/B...

  • Page 95: Power Switch Board

    Schematic Diagrams Power Switch Board PCBA CHECK POWER SW & LED SS_3.3VS POWER 1SSMR *0_04 4SSMR *0_04 SWITCH 2SSMR *0_04 5SSMR *0_04 SSR1 220_04 3SSMR *0_04 6SSMR *0_04 20mil SSC2 *0.1u_16V_Y5V_04 SSJ_SW1 SSMGND SSMGND SSM_BTN# SSD2 RY-SP150DBW71-5A 20mil SS_3.3VS 6-52-56001-023 6-52-56001-028 85201-04051 6-52-56000-020...

  • Page 96: Audio Board

    Schematic Diagrams Audio Board USB PORT AA_USBVCC AA_USBVCC 60 mil 60 mil AAC3 AAC2 AAC15 AAC16 AAC4 AAC17 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 Port3 Port4 AAJ_USB1 AAJ_USB2 AAGND AAGND *WCM2012F2S-161T03-short AAL6 AAUSB_PN1 AAUSB_PN1_R AAUSB_PN2 AAUSB_PN2_R DATA_L DATA_L AAUSB_PP1 AAUSB_PP1_R AAUSB_PP2 AAUSB_PP2_R DATA_H DATA_H AAL7 *WCM2012F2S-161T03-short US04036BCA081...

  • Page 97: Ext. Odd Board

    Schematic Diagrams Ext. ODD Board ODD BOARD FROM M/B TO ODD QJ_ODD1 QJ_ODD2 PCBA CHECK Q_SATA_TXP1 Q_SATA_TXN1 Q_SATA_RXN1 Q_SATA_RXP1 *0_04 *0_04 QGND QGND *0_04 *0_04 Q_ODD_DETECT# Sheet 40 of 45 Q_5VS Q_5VS *0_04 *0_04 Ext. ODD Board Q_SATA_ODD_DA# 242003-1 C185J9-11308-L GND1~2=WGND QGND QGND...

  • Page 98: Lid Switch Board

    Schematic Diagrams LID Switch Board LID SWITCH BOARD L_VDD3 LJ_LID1 L_LID_SW# 85204-03001 L_GND For 15" L_VDD3 Sheet 41 of 45 L_U1 LID Switch Board L_LID_SW# L_C1 0.1u_16V_Y5V_04 MH248-ALFA-ESO H2_3B5_0D2_3 C44D44N C44D44N L_GND L_GND 6-02-00248-LC2 6-02-00268-LC1 L_GND DMFWP!DP/!! Title Title Title [41] LID SWITCH BOARD [41] LID SWITCH BOARD [41] LID SWITCH BOARD...

  • Page 99: Touch Panel Board

    Schematic Diagrams Touch Panel Board T_5VS TJ_TPT1 TJ_TPT2 T_USB_PN1 Sheet 42 of 45 T_USB_PP1 Touch Panel Board GB5RF101-110N-7H 85205-05001 TGND DMFWP!DP/!! Title Title Title [42] TOUCH PANEL BOARD [42] TOUCH PANEL BOARD [42] TOUCH PANEL BOARD Size Size Size Document Number Document Number Document Number R e v...

  • Page 100: Audio Board

    Schematic Diagrams Audio Board USB PORT PCBA CHECK A_USBVCC 60 mil 1AAR *0_04 4AAR *0_04 0.1u_10V_X5R_04 2AAR *0_04 5AAR *0_04 AJ_USB1 3AAR *0_04 6AAR *0_04 AGND AUSB_PN1 AUSB_PN1_R DATA_L AUSB_PP1 AUSB_PP1_R DATA_H *WCM2012F2S-SHORT US04036BCA081 6-21-B49C0-104 6-21-B49B0-104 AGND Sheet 43 of 45 TO M/B AUDIO JACK Audio Board...

  • Page 101: Power Switch Board

    Schematic Diagrams Power Switch Board POWER SW & LED S_3.3VS POWER SWITCH 330_04 PCBA CHECK 20mil &KHFN  *0.1u_10V_X5R_04 1PPR *0_04 4PPR *0_04 SJ_SW1 SMGND SMGND 2PPR *0_04 5PPR *0_04 SM_BTN# *HT-150BP HT-150BP S_3.3VS 20mil 3PPR *0_04 6PPR *0_04 6-52-57001-022 50578-0040N-001 6-52-57301-021 SMGND...

  • Page 102: Power On Seq

    Schematic Diagrams Power On SEQ W5XXSU EVT SEQ VDD3 VDD5 476us DD_ON 1.04ms 1.76ms 3.3V 56ms PWR_BTN 222.4ms SUSC# 367.4us 1.35V 200us DDR1.35V_PWRGD 34.8us SUSB# 2.02ms 1.72ms 1.5VS 3.3VS 2.57ms 1.2ms 1.05V_LAN_M 2.02ms 1.05V_LAN_PWRGD ALL_SYS_PWRGD Sheet 45 of 45 339ms PM_PCH_PWROK Power On SEQ 392ms...

  • Page 103: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 104: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
