  • Page 1 W547BL/W548BL/W549BL...
  • Page 3 Preface Notebook Computer W547BL/W548BL/W549BL Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the W547BL/ W548BL/W549BL series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 LCD (W547BL) ................A-6 LCD (W548BL) ................A-7 Overview ..................1-1 LCD (W549BL) ................A-8 Specifications ..................1-2 Bottom ................... A-9 External Locator - Top View with LCD Panel Open ......1-4 DVD DUAL ................. A-10 External Locator - Front & Right Side Views .........1-5 Schematic Diagrams.........
  • Page 12 Preface POWER 1.1V/1VS/1.8VS ............B-26 POWER VCORE1 ............... B-27 DC IN, CHARGER ..............B-28 AUDIO BOARD ................B-29 POWER SW BOARD ..............B-30 Updating the FLASH ROM BIOS..C-1 Download the BIOS ............... C-1 Unzip the downloaded files to a bootable CD/DVD/ or USB Flash drive ................

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the W547BL/W548BL/W549BL series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g. VGA & audio) is also found in the User’s Manual. The manual is shipped with the com- puter.

  • Page 14: Specifications

    Introduction Specifications Processor Options Pointing Device AMD-C Series (Dual-Core) Accelerated Processing Unit Built-in Touchpad - C-70 (1.0GHz) Interface 1MB L2 Cache, 40nm, DDR3-1066MHz, TDP 9W  One USB 2.0 Port Core Logic Two USB 3.0 Ports Latest Specification Information AMD A68M Chipset One HDMI-Out Port The specifications listed here are correct at the One External Monitor Port...
  • Page 15 Introduction Environmental Spec Temperature ° ° Operating: 5 C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80% Non-Operating: 10% - 90% Power Full Range AC/DC Adapter AC Input: 100 - 240V, 50 - 60Hz DC Output: 19V, 1.58A (30W) (Factory Option) 4 Cell Smart Lithium-Ion Battery Pack, 32.56WH (Factory Option) 6 Cell Smart Lithium-Ion Battery Pack,...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera (Optional) 2. Built-In Microphone 3. *PC Camera LED *When the PC camera is in use, the LED will be illuminated in red. 4. LCD 5.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Power Indicator 2. Multi-in-1 Card FRONT VIEW Reader Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone-Out Jack 3. USB 2.0 Port 4.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. RJ-45 LAN Jack 3. External Monitor LEFT SIDE VIEW Port 4. Vent 5. HDMI-Out Port 6. USB 3.0 Ports Figure 5 REAR VIEW Rear View 1.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery Location 2. Bay Cover 3. Vent 4. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Mini-Card Connector 2. Memory Slots DDR3 SO-DIMM 3. CPU 4. Platform Controller 5. KBC-ITE IT8518 6. CMOS Battery Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. USB Port 3.0 3. Keyboard Cable Connector 4. Audio Board Cable Connector 1 - 10 Mainboard Overview - Top (Connectors)

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. ODD Connector 2. HDD Connector 3. Multi-in-1 Card Reader 4. External Monitor Port 5. RJ-45 LAN Jack 6. DC-In Jack 7. LCD Cable Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the W547BL/W548BL/W549BL series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Optical Device: To remove the CCD Module: 1. Remove the optical device page 2 - 5 1.

  • Page 29: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 1 Optical Device 1. Turn the computer off, and turn it over. Removal 2. Remove the screw (Figure 1a out of the bay at point 3. Carefully pull out the optical device (Figure 1b a.
  • Page 30 Disassembly 6. Reverse the process to attach the front bezel with the new optical device at point (Figure 2e). Figure 2 7. Insert the new optical device and carefully slide it into the computer (the device only fits one way. DO NOT Optical Device FORCE IT;...

  • Page 31: Removing The Battery

    Disassembly Removing the Battery Figure 3 Battery Removal 1. Turn off the computer, turn it over to first remove the optical device (page 2 - 2. Remove screws from the bottom case (Figure 3a a. Remove screws from the 3. Carefully separate the bottom cover from the top case in the direction of the arrow at point (Figure 3b bottom case.
  • Page 32 Disassembly 5. Remove screws from the battery (Figure 4d Figure 4 6. Turn the battery in the direction of the arrow and lift it out (Figure 4e Battery Removal & 7. Insert a new battery at point in the direction of the arrow .

  • Page 33: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 5 The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm HDD Assembly (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Removal Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 34 Disassembly 3. Slightly lift and pull the hard disk assembly in the direction of arrow (Figure 6b Figure 6 4. Lift the hard disk assembly out of the bay (Figure 6c HDD Assembly 5. Remove the screws and the adhesive cover from the hard disk (Figure 6d Removal (cont’d.)

  • Page 35: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 7 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDRIII (DDR3) Up to 1333/1600 MHz. The main memory can be expanded up to 16GB. The SO-DIMM modules sup- ported are 1024MB and 2048MB DDRIII Modules.
  • Page 36 Disassembly 4. Pull the latches to release the second module if necessary. 5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 6. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go.

  • Page 37: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 8 Keyboard Removal 1. Turn off the computer, turn it over to remove the optical device (page 2 - 5) and battery (page 2 - 2. Press at point to release the cover module (Figure 8a).
  • Page 38 Disassembly 7. Connect the keyboard ribbon cable from the locking collar socket , and be careful not to bend the keyboard rib- Figure 9 bon cable (Figure 9f). Keyboard Assembly 8. Tighten the screws (Figure 9g). 9. Replace the cover module as shown (Figure 9h).

  • Page 39: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, turn it over to remove the optical device (page 2 - 5) and battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 10a).

  • Page 40: Removing The Ccd

    Disassembly Removing the CCD Figure 11 CCD Removal 1. Turn off the computer, turn it over to remove the optical device (page 2 - 5) and battery (page 2 - 2. Carefully remove the rubber screw covers and screws from the front cover (Figure 11a).
  • Page 41 Disassembly 6. Disconnect the cable Figure 12 7. Remove the CCD module (Figure 12f). CCD Removal 8. Reverse the process to install a new CCD module. (cont’d) e. Disconnect the cable. f. Remove the CCD mod- ule.  15. CCD Module Removing the CCD 2 - 17...
  • Page 42 Disassembly 2 - 18...

  • Page 43: Part Lists

    Appendix A:Part Lists This appendix breaks down the W547BL/W548BL/W549BL series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 44: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part W547BL W548BL W549BL Location page A - 3 page A - 4 page A - 5...

  • Page 45: Top (W547Bl

    Top (W547BL) Figure A - 1 Top (W547BL) Top (W547BL) A - 3...

  • Page 46: Top (W548Bl

    Top (W548BL) Figure A - 2 Top (W548BL) A - 4 Top (W548BL)

  • Page 47: Top (W549Bl

    Top (W549BL) Figure A - 3 Top (W549BL) Top (W549BL) A - 5...

  • Page 48: Lcd (W547Bl

    LCD (W547BL) Figure A - 4 LCD (W547BL) 設變 A - 6 LCD (W547BL)

  • Page 49: Lcd (W548Bl

    LCD (W548BL) Figure A - 5 LCD (W548BL) 設變 LCD (W548BL) A - 7...

  • Page 50: Lcd (W549Bl

    LCD (W549BL) Figure A - 6 LCD (W549BL) 設變 A - 8 LCD (W549BL)

  • Page 51: Bottom

    Bottom Figure A - 7 Bottom Bottom A - 9...

  • Page 52: Dvd Dual

    DVD DUAL Figure A - 8 DVD DUAL 非耐落 A - 10 DVD DUAL...
  • Page 53 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the W547BL/W548BL/W549BL notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 54: Schematic Diagrams

    Schematic Diagrams System Block Diagram W54XBL System Block Diagram VDD3,VDD5 W54XBL MAIN BOARD 5V,3V,5VS,3.3VS 1.5VS,1.1VS AUDIO BOARD CRT Connector AMD FUSION APU PHONE JACK x2, USB x1 Ontario FT1 APU_CORE,NB_CORE HDMI Connector POWER SWITCH BOARD 413-BALL 19mmX19mm BGA 1066MHz 1.5V,0.75VS SINGLE CHANNEL DDR3 DDR3 / 1.5V LCD Connector...

  • Page 55: Ontario Mem & Pcie I/F, Ap

    Schematic Diagrams Ontario MEM & PCIE I/F, AP ONTARIO MEM & PCIE I/F, AP MEM_ADDR[15:0] MEM_DATA[63:0] U13E MEM_ADDR0 MEM_DATA0 M_ADD0 M_DATA0 MEM_ADDR1 ONTARIO (2.0) MEM_DATA1 M_ADD1 M_DATA1 MEM_ADDR2 PART 1 OF 5 MEM_DATA2 M_ADD2 M_DATA2 MEM_ADDR3 MEM_DATA3 M_ADD3 M_DATA3 MEM_ADDR4 MEM_DATA4 M_ADD4 M_DATA4...

  • Page 56: Ontario Display, Clk, Misc

    Schematic Diagrams Ontario Display, CLK, MISC 3.3VS ONTARIO DISPLAY/CLK/MISC *10K_04 APU_THERMTRIP# CPU_THERMTRIP# 1.8VS *2N3904 U13B R230 1K_04 CPU_SVC ANALOG/DISPLAY/MISC CPU_SVD ONDP_CALR R231 1K_04 150_1%_04 TDP1_TXP0 DP_ZVSS HDMIB_D2BP APU_PWRGD 300_1%_04 TDP1_TXN0 HDMIB_D2BN ON_BLON R221 *10mil_short_04 DP_BLON BLON 3.3V ON_DIGON R217 *10mil_short_04 HDMIB_D1BP TDP1_TXP1 DP_DIGON...

  • Page 57: Ontario Power & Decoupling

    Schematic Diagrams Ontario Power & Decoupling ONTARIO POWER & DECOUPLING 1.8VS VDDCR_CPU U13C C140 C134 C131 C127 U13D C135 10u_6.3V_X5R_06 *1u_6.3V_X5R_04 1u_6.3V_X5R_04 0.1u_10V_X5R_04 VDDCR_CPU_1 VDD_18_1 *1u_6.3V_X5R_04 VSS_1 ONTARIO (2. 0) VSS_50 VDDCR_CPU_2 VDD_18_2 VSS_2 PART 5 OF 5 VSS_51 VDDCR_CPU_3 VDD_18_3 VSS_3 VSS_52...

  • Page 58: Inagua Ddr3 So-Dimms A

    Schematic Diagrams INAGUA DDR3 SO-DIMMS A SO-DIMM A INAGUA DDR3 SO-DIMMS A MEM_ADDR[15:0] MEM_DATA[63:0] JDIMM1A MEM_ADDR0 MEM_DATA0 MEM_ADDR1 MEM_DATA1 MEM_ADDR2 MEM_DATA2 MEM_ADDR3 MEM_DATA3 MEM_ADDR4 MEM_DATA4 MEM_ADDR5 MEM_DATA5 MEM_ADDR6 MEM_DATA6 JDIMM1B MEM_ADDR7 MEM_DATA7 MEM_ADDR8 MEM_DATA8 MEM_ADDR9 MEM_DATA9 1.5V MEM_ADDR10 MEM_DATA10 A10/AP DQ10 MEM_ADDR11 MEM_DATA11...

  • Page 59: Inagua Ddr3 So-Dimms B

    Schematic Diagrams INAGUA DDR3 SO-DIMMS B SO-DIMM B INAGUA DDR3 SO-DIMMS B MEM_ADDR[15:0] MEM_DATA[63:0] JDIMM2A MEM_ADDR0 MEM_DATA0 MEM_ADDR1 MEM_DATA1 MEM_ADDR2 MEM_DATA2 MEM_ADDR3 MEM_DATA3 MEM_ADDR4 MEM_DATA4 MEM_ADDR5 MEM_DATA5 MEM_ADDR6 MEM_DATA6 JDIMM2B MEM_ADDR7 MEM_DATA7 MEM_ADDR8 MEM_DATA8 MEM_ADDR9 MEM_DATA9 1.5V MEM_ADDR10 MEM_DATA10 A10/AP DQ10 MEM_ADDR11 MEM_DATA11...

  • Page 60: Hudson Pcie/Pci/Clock/Fch

    FR AME# LDT_STP# DEVS EL# AL10 W548BL PC IE_ RCLKP IRDY# AF10 PC IE_ RCLKN TRDY# AE10 10K_04 10K_04 W547BL DISP_ CLKP STOP# DISP_CLKP DISP_ CLKN P ERR # DISP_CLKN S ERR # AG15 22p_50V_NPO_04 DISP2 _CLK P R EQ0# AG13...

  • Page 61: Hudson Gpio/Usb/Strap

    Schematic Diagrams Hudson GPIO/USB/Strap HUDSON GPIO/USB/AUDIO/STRAP U16D SWI# R146 *0_04 R323 *10mil_short_04 PCIE_ RST2#/GEVENT4# USBCL K/1 4M_25 M_48 M_ OSC R316 *0_04 RI#/GEVENT22 # 12,19,21 LID_SW# USB_RCOMP R263 10K_1%_04 VDD3 SPI_ CS3#/GBE_STAT1 /GEVENT2 1# USB_RCOMP 11,19,22 SUSB# SLP_S3 # SLP_S5 # 19,22,24 SUSC# R317...

  • Page 62: Hudson Sata/Debug Io/Spi

    Schematic Diagrams Hudson SATA/DEBUG IO/SPI HUDSON SATA/DEBUG IO/SPI U16B HUDSON - M3L Part 2 of 5 AK19 SATA_TX0P SD_CLK/SCLK_0/GPIO73 SATATXP0 AM19 SATATXN0 SATA_TX0N SD_CMD/SLOAD_0/GPIO74 SD_CD#/GPIO75 AL20 3.3V SATARXN 0 SATA_RX0N SD_WP/GPIO76 AN20 AK13 SATARXP0 SATA_RX0P SD_DATA0/SDATI_0/GPIO77 AM13 SD_DATA1/SDATO_0/GPIO78 AN22 AH 15 SATA_TX1P SD_DATA2/GPIO79 SATATXP1...

  • Page 63: Hudson Power Decoupling

    Schematic Diagrams Hudson Power Decoupling HUDSON POWER DECOUPLING 3.3VS U16C 1.1VS 102mA Part 3 of 5 U16E HUDSON-M3L AB17 1007mA VDD IO_33 _PCIGP_1 VDDC R_11_1 C219 C212 C216 C196 AB18 C189 VDD IO_33 _PCIGP_2 VDDC R_11_2 C186 C205 C177 HUDSON-M3L C200 VDD IO_33 _PCIGP_3 VDDC R_11_3...

  • Page 64: Powergood

    Schematic Diagrams POWERGOOD 3.3V 74LVC08PW 1.1V_PWRGD SYS_RST# C217 *0.1u_10V_X5R_04 3.3V PWRGD_VCORE Sheet 11 of 29 3.3V 3.3V R108 3.3V POWERGOOD *10K_04 R107 *10mil_short 74LVC08PW 74LVC08PW R114 *10mil_short SB_PWROK 1.8V_PWRGD SB_PWRGD 74LVC08PW SYS_PWROK R117 *10mil_short ALL_SYS_PWRGD 12,19 R104 *0_04 24,26 DDR1.5V_PWRGD C222 R116 8,19,22...

  • Page 65: Lvds/Inverter

    Schematic Diagrams LVDS/Inverter PANEL CONNECTOR J_LCD1 For single channel 3.3VS 3.3V R186 4.7K_04 R187 4.7K_04 EDID Mode VIN_LCD R_BRIGHTNESS C291 *0.1u_10V_X5R_04 J_LCD1 80mils LVDS_DDC_DATA *BAV99 RECTIFIER LVDS_DDC_DATA LVDS_DDC_CLK LVDS_DDC_CLK R_BRIGHTNESS R188 *0_04 BRIGHTNESS INV_BLON R189 0_04 ON_VARY LVDS-LCLKN LVDS-L2N LVDS-LCLKN LVDS-L2N LVDS-LCLKP LVDS-L2P...

  • Page 66: Hdmi/Crt

    Schematic Diagrams HDMI/CRT HDMI PORT 5VS_HDMI R D3 * BAV99 RECTIFIER RB551V-30S2 *BAV99 RECTIFIER For ESD *BAV99 RECTIF IER HDMIB_D2BP C240 0.1u_10V_X7R_04 HDMIB_DATA2P HDMIB_D2BN C237 0.1u_10V_X7R_04 HDMIB_DATA2N 0.5_04 5VS_HDMI J_HDMI1 HDMIB_D1BP HDMIB_DATA1P C221 0.1u_10V_X7R_04 116B-1A002-21U HDMIB_D1BN C223 0.1u_10V_X7R_04 HDMIB_DATA1N HDMIB_D0BP C233 0.1u_10V_X7R_04 HDMIB_DATA0P 5VS_HDMI...

  • Page 67: Ccd/Fan

    Schematic Diagrams CCD/Fan 5V_CCD 48 mil 48 mil VOUT MJ_CCD1 1u_6.3V_X5R_04 0.1u_10V_X5R_04 10u_6.3V_X5R_06 *1u_6.3V_X5R_04 NCT3522U 6-02-03522-9C0 CCD_EN CCD_EN 6-02-03512-9C0 From H8 default HI 6-02-02821-9C0 J_CCD1 USB_PN5 USB_PP5 INT_MIC_OUT_R *10mil_short_04 INT_MIC_OUT 50273-0060N-001 Sheet 14 of 29 *100p_50V_NPO_04 *10mil_short_04 AUDGR CCD/Fan Closs to J_INTMIC1 FAN CONTROL 5VS_FAN AX995B(SOT23-6) &...

  • Page 68: Card Reader/Lan Rtl8402

    Schematic Diagrams Card Reader/LAN RTL8402 RTL8402 com m and LAN (RTL8402) From PCH LAN_25MHz meet realtek Freq tolerance 50ppm CARD _3V3 R 332 0.2R 5% SMD0603 VCC _CARD R162 *0_04 LAN _25MHz SD _D0 SD_D0_R R 175 *10m il_short_04 R331 Crystal 8045 &...

  • Page 69: Mini Pcie/Sata Hdd/Odd

    Schematic Diagrams Mini PCIE/SATA HDD/ODD MINI CARD (WLAN,Port 5) 20 mil MINI_3.3V Layout Show "WLAN(Wim ax, 802.11N)" Note C297 3.3V 0.1u_10V_X5R_04 J_MINI1 PCIE_WAKE#_R R199 *0_04 8,15 PCIE_WAKE# WAKE# 3.3VAUX_0 COEX1 1.5V_0 20 mil R198 10K_04 MINI_3.3V COEX2 UIM_PWR VDD3 VDD3 MINI_3.3V R193 *0_04...

  • Page 70: Audio Codec Vt1802S

    Schematic Diagrams Audio Codec VT1802S La yout note: AUDIO CODEC C o m p o n e n t . 3.3VS_AUD VT1802S / VT1802PCE GND and AUDG space is 60m ils ~ 100mils CODEC_GPIO0 R361 *0_04 DVDD_IO For 3.3V HDA Link. EMI Require R337 *10mil_short...

  • Page 71: Usb 3.0

    Schematic Diagrams USB 3.0 USBVCC_2 C395 *0.1u_10V_X5R_04 C412 *0.1u_10V_X5R_04 USBVCC1 C390 220u_6.3V_6.3*6.3*4.2 C410 220u_6.3V_6.3*6.3*4.2 C388 *22u_6.3V_X5R_08 C416 *22u_6.3V_X5R_08 C387 22u_6.3V_X5R_08 C415 22u_6.3V_X5R_08 J_USB1 J_USB2 USB_SS_TX0P_R GND1 C245 0.1u_10V_X7R_04 USB_SS_TX0P SSTX+ SHIELD USB_SS_TX1P_R GND1 C259 0.1u_10V_X7R_04 VBUS USB_SS_TX1P SSTX+ SHIELD USB_SS_TX0N_R C246 0.1u_10V_X7R_04 USB_SS_TX0N...

  • Page 72: Kbc-Ite It8518

    Schematic Diagrams KBC-ITE IT8518 VDD3 KBC_AVDD R261 *15mil_short_06 VDD3 HCB1005KF-121T20 VDD3 C374 C375 C367 C350 C352 R255 C355 C354 C356 *0.1u_10V_X5R_04 10u_6.3V_X5R_06 0.1u_10V_X5R_04 *0.1u_10V_X5R_04 0.1u_10V_X5R_04 100K_04 0.1u_10V_X5R_04 *0.1u_10V_X5R_04 *0.1u_10V_X5R_04 KBC_WRESET# C364 C360 HCB1005KF-121T20 0.1u_10V_X5R_04 KBC_AGND EC_VCC J_KB1 1u_6.3V_X5R_04 3.3VS J_KB1 50583-0240N-001 EC MODULE CHOOSE (FOR DIFFERENCE CPU TYPE) KB-SI0...

  • Page 73: Led

    Schematic Diagrams POWER ON LED BAT LED LED_ACIN LED_PWR LED_BAT_FULL LED_BAT_CHG 220_8P4R_04 BAT LED POWER ON RY-SP155HYYG4-1 RY -SP155HYY G4-1 6-52-55002-04E 6-52-55002-04E 6-52-55002-042 6-52-55002-042 Sheet 20 of 29 3.3VS AIRPLANE LED HDD/ODD LED R182 R183 220_04 220_04 AIRPLANE HDD/ODD RY-SP190YG34-5M RY-SP190YG34-5M R181 AIRPLANE LED#...

  • Page 74: Multi Con/Lid/Click/P Sw

    Schematic Diagrams Multi CON/LID/CLICK/P SW Audio/B CONN.(Port3) CLICK CONN 5VS_TP FOR AUDIO BOARD W549BL R342 *15mil_short_06 C432 C430 1.1A 60mils R341 R340 R158 *10u_6.3V_X5R_06 1u_6.3V_X5R_04 J_TP1 C249 *0.01u_16V_X7R_04 10K_04 10K_04 W549BL USBVCC3 *15mil_short_06 TP_CLK J_AUDIO1 TP_DATA TPBUTTON_L TPBUTTON_R C429 C428 MIC1-R M MIC1-R M MIC1-L M...

  • Page 75: 5Vs, 3.3Vs, 1.1Vs

    Schematic Diagrams 5VS, 3.3VS, 1.1VS VIN1 PR91 *10K_04 PR155 *0_04 VIN1 DDON_LATCH R185 100K_04 PD16 DD_ON 19,22,23 DD_ON_LATCH PR92 1K_04 PWR_SW#_R PR90 1K_04 21,27 M_BTN# M_BTN# PWR_SW# PWR_SW# MDL914S2 INSTANT-ON P2808B0 DD_ON "L" TO "H" FROM EC VDD3 VIN1 DD_ON# 3.3V SUSB SUSC...

  • Page 76: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR83 *0_04 PR77 *10mil_short_04 PC82 1u_10V_Y 5V_06 PR82 PR76 EN_3V EN_5V PC79 100K_04 100K_04 PC77 1000p_50V_X7R_04 1000p_50V_X7R_04 VREG3 PR72 *10K_04 PC170 PC172 PC164 SYS5V LDO3 PC75 PC160 PC162 4.7u_25V_X5R_08 1u_10V_Y 5V_06 PC74 4.7u_25V_X5R_08 PC73 PQ40A 0.1u_50V_Y 5V_06 *4.7u_25V_X5R_08 BOOT2...

  • Page 77: Power 1.5V, 0.75V

    Schematic Diagrams Power 1.5V, 0.75V PD11 RB0540S2 VDDQ G5616 PC106 PQ17 10u_6.3V_X5R_06 PC107 0.1u_10V_X7R_04 P1203BV 1.5V VLDOIN VBST VDDQ PR33 *15mil_short_06 TMPC0603H-4R7M-Z01 VTT_MEM DRVH 1.5V PR30 *OPEN_8A VTTGND PC32 PC28 PR99 *15mil_short_06 10u_6.3V_X5R_06 10u_6.3V_X5R_06 PQ18 *5.1_06 VTTSNS DRVL PC31 P1203BV *10u_6.3V_X5R_06 Z2621 PGND...

  • Page 78: Power 1.1V/1Vs/1.8Vs

    Schematic Diagrams POWER 1.1V/1VS/1.8VS PR137 *820K_1%_06 PR138 EN_1.1V PC159 PC158 PC157 PC149 100K_1%_04 PQ28 PC150 SUSC PR136 *62K_1%_04 22,24,26 SUSC MTN7002ZHS3 0.1u_10V_X7R_04 PR139 PC148 PR135 62K_1%_04 PC146 *10mil_short_04 *0.1u_10V_X7R_04 18,21,22,24 DD_ON# 1.1V PQ42A EN_PSV 0.1u_10V_X5R_04 *EMB17A03V 1.1V PJ13 PJ12 *TMPC0603H-1R0M-Z01 OPEN-1mm PR140 VOUT...

  • Page 79: Power Vcore1

    Schematic Diagrams POWER VCORE1 Offset & OFS/VFIXEN VFIX Droop V DDCR_ CP U PR 42 +3.3V 10_04 N B_VDDC R C 334 0.1u_10V_X5R_04 PJ21 JU MP-1m m C 332 *0.01u_16V_X7R _04 CPU_VD DN B_RU N_FB_H Metal VID Codes SGN D5 PJ22 JU MP-1m m CPU_VD DN B_RU N_FB_L...

  • Page 80: Dc In, Charger

    Schematic Diagrams DC IN, CHARGER # Charge Current 1.5A VD D3 PR94 *10mil_short_04 PR 93 *470K_04 # Charge Voltage 12.6V CHARGER PQ15 R 10 10K_04 P2003EVG SMC _BATTERY PC97 0.1u_50V_Y 5V_06 * BAV99 REC TIF IER SMD _BATTERY 6-20-B3Z40-004 for 30W V_BAT ¾aªñJBATTA1 * BAV99 REC TIF IER...

  • Page 81: Audio Board

    Schematic Diagrams AUDIO BOARD W549BL AUDIO BOARD A_USBVCC 60 mil USB PORT 22u_6.3V_X5R_08 22u_6.3V_X5R_08 0.1u_10V_X5R_04 AJ_USB1 AGND AUSB_PN1 AUSB_PN1_R DATA_L Port3 AUSB_PP1 AUSB_PP1_R DATA_H *WCM2012F2S-SHORT US04036BCA081 6-21-B49C0-104 6-21-B49E0-104 6-21-B49D0-104 AGND TO M/B AUDIO JACK Sheet 28 of 29 A_USBVCC AJ_AUDIO1 AUDIO BOARD AJ_MIC1 AMIC1-R...

  • Page 82: Power Sw Board

    Schematic Diagrams POWER SW BOARD POWER SW & LED S_3.3VS POWER SWITCH 330_04 SJ_SW1 20mil Z4301 SMGND SM_BTN# S_3.3VS 20mil *0.1u_10V_X5R_04 WHITE 50578-0040N-001 SMGND HT-150BP 6-52-57001-022 Sheet 29 of 29 6-52-57301-021 SMGND POWER SW BOARD S_3.3VS POWER BUTTON *BAV99 RECTIFIER SPWR_SW1 SM_BTN# TJG-532-V-T/R...

  • Page 83: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 84: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
