Summary of Contents for Clevo E5120Q

  • Page 1 E5120Q/E5120Q-C, E5125/E5125-C, E5128Q, E5128Q-C...
  • Page 3 Preface Notebook Computer E5120Q/E5120Q-C/E5125/E5125-C/E5128Q/E5128Q-C Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the E5120Q/ E5120Q-C/E5125/E5125-C/E5128Q/E5128Q-C series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...

  • Page 8: Power Safety

    Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.

  • Page 9: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 10: System Startup

    Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    IBEXPEAK - M 7/9 ..............B-21 Removing the Keyboard ..............2-17 IBEXPEAK - M 8/9 ..............B-22 Part Lists ..........A-1 IBEXPEAK - M 9/9 ..............B-23 New Card, Mini PCIE ..............B-24 Part List Illustration Location ............A-2 3G, CCD, TPM ................B-25 Top (E5120Q) ................A-3...
  • Page 12 Preface Card Reader/LAN JMB251C ............B-26 LAN (JMC251C), SATA HDD, ODD ......... B-27 Audio Codec VIA1812 ..............B-28 KBC-ITE IT8502E ............... B-29 LED, MDC, BT ................B-30 USB, Fan, TP, Multi-Conn ............B-31 5VS, 3VS, 1.5VS ................B-32 Power 3.3V/5V ................B-33 Power 1.5V/0.75V, 1.8VS ............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the E5120Q/E5120Q-C/E5125/E5125-C/E5128Q/ E5128Q-C series notebook computer. Information about operating the computer (e.g. getting started, and the Setup util- ity) is in the User’s Manual. Information about dri-vers (e.g. VGA & audio) is also found in the User’s Manual. The manual is shipped with the computer.

  • Page 14: Specifications

    Introduction Specifications Processor Options BIOS Intel® Core™ i7 Processor One 32Mb SPI Flash ROM Phoenix™ BIOS i7-640M (2.80GHz), i7-620M (2.66GHz)  4MB L3 Cache & 1066MHz FSB Storage Intel® Core™ i5 Processor Latest Specification Information i5-540M (2.53GHz), i5-520M (2.4GHz),  (Factory Option) One Changeable 12.7mm(h) Super Multi Optical Device Drive The specifications listed here are correct at the...
  • Page 15 Introduction Card Reader Environmental Spec Embedded Multi-In-1 Card Reader Temperature ° ° MMC (MultiMedia Card) / RS MMC Operating: 5 C - 35 SD (Secure Digital) / Mini SD / SDHC/ SDXC Non-Operating: -20°C - 60°C Compatible Relative Humidity MS (Memory Stick) / MS Pro / MS Duo Operating: 20% - 80% Non-Operating: 10% - 90% Communication...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera (Optional) 2. LCD 3. Power Button 4. LED Status Indicators 5. Keyboard 6. Built-In Microphone 7. Touchpad & Buttons 1 - 4 External Locator - Top View with LCD Panel Open...

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 Right Side View 1. Microphone-In RIGHT SIDE VIEW Jack 2. Headphone-Out Jack 3. USB 2.0 Port 4. Optical Device Drive Bay 5.

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. DC-In Jack 2. External Monitor Port LEFT SIDE VIEW 3. RJ-45 LAN Jack 4. HDMI-Out Port 5. 2 * USB 2.0 Ports 6. Vent 7. Multi-in-1 Card Reader Figure 5 REAR VIEW...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Component Bay Cover 3. Vent 4. Hard Disk Bay Cover 5. Speakers 6. USIM Card Cover  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. JMC251C 2. Clock Generator 3. KBC-ITE IT8502E 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. Memory Slots DDR3 SO-DIMM 2. Mini-Card Connector (3.5G Module) 3. Audio Codec 4. USIM Card 5. Mini-Card Connector (WLAN Module) 6. Multi-in-1 Card Reader 7. Platform Controller 8.

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. HDMI-Out Port 2. USB Ports 3. Speaker Cable Connector 4. Microphone Cable Connector 5. TouchPad Cable Connector 6. Click Board Connector 7. Audio Board Connector 8. Keyboard Cable Connector 9.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Battery Connector 2. ODD Connector 3. HDD Connector 4. Bluetooth Cable Connector 5. CPU Fan Cable Connector 6. RJ-45 LAN Jack 7. External Monitor Port 8. DC-In Jack 9.
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Disassembly Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the E5120Q/E5120Q-C/E5125/E5125-C/E5128Q/ E5128Q-C series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless other- wise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the Bluetooth Module: 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery Figure 1 Battery Removal 1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a a. Slide latch at point 1 to- 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a wards the unlock symbol...

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 3. Remove the hard disk bay cover (Figure 3b Figure 3 4. Grip the tab and slide the hard disk in the direction of arrow (Figure 3c HDD Assembly 5. Lift the hard disk out of the bay (Figure 3d Removal (cont’d.) 6.

  • Page 32: Removing The Optical (Cd/Dvd) Device

    Disassembly Removing the Optical (CD/DVD) Device Figure 4 Optical Device 1. Turn off the computer, remove the battery (page 2 - 5) and hard disk (page 2 - Removal 2. Remove the screw at point (Figure 4a 3. Use a screwdriver to carefully push out the optical device at point (Figure 4b a.

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 200 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDRIII (DDR3) Up to 1066/1333 MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules sup- ported are 1024MB and 2048MB DDRIII Modules.
  • Page 34 Disassembly 5. Pull the latches to release the second module if necessary. 6. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 7. The module will only fit one way as defined by its pin alignment. Make sure the module is seated as far into the slot as it will go.

  • Page 35: Removing And Installing A Processor

    Disassembly Removing and Installing a Processor Figure 6 Processor Removal Processor Removal Procedure 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - a. Locate the heat sink. 2.
  • Page 36 Disassembly 5. Turn the release latch towards the unlock symbol to release the CPU (Figure 7d). Figure 7 6. Carefully (it may be hot) lift the CPU up and out of the socket (Figure 7e). Processor Removal 7. Reverse the process to install a new CPU. (cont’d) 8.
  • Page 37 Disassembly Processor Installation Procedure Figure 8 1. Insert the CPU (Figure 8a), pay careful attention to the pin alignment, it will fit only one way (DO NOT FORCE Processor Installation IT!), and turn the release latch towards the lock symbol (Figure 8b).

  • Page 38: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 9 3G Module Removal 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - 2. The 3G module will be visible at point on the mainboard (Figure 9a).

  • Page 39: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 10 Wireless LAN 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 10a).

  • Page 40: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 11 Bluetooth Module 1. Turn off the computer, turn it over, and remove the battery (page 2 - 5) and the component bay cover (page 2 - Removal 2. The Bluetooth module will be visible at point on the mainboard (Figure 11a).

  • Page 41: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 12 Keyboard Removal 1. Turn off the computer, and remove the battery (page 2 - 2. Remove screws from the bottom of the computer. Press at point to unsnap the LED cover module (you a. Remove screws from the bottom of the computer.
  • Page 42 Disassembly 2 - 18...

  • Page 43: Part Lists

    Appendix A:Part Lists This appendix breaks down the E5120Q/E5120Q-C/E5125/E5125-C/E5128Q/E5128Q-C series notebook’s construc- tion into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 44: Part List Illustration Location

    The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration E5120Q/E5120Q-C/E5125/ Part Location E5125-C/E5128Q/E5128Q-C page A - 3 Top (E5120Q) page A - 4 Top (E5125) Top (E5128Q) page A - 5 page A - 6 Bottom page A - 7...

  • Page 45: Top (E5120Q

    Top (E5120Q) Figure A - 1 Top (E5120Q) 非耐落 灰色 Top (E5120Q) A - 3...

  • Page 46: Top (E5125

    Top (E5125) Figure A - 2 Top (E5125) 非 耐 落 灰 色 A - 4 Top (E5125)

  • Page 47: Top (E5128Q

    Top (E5128Q) Figure 3 Top (E5128Q) 非 耐 落 非耐落 非耐落 非耐落 非耐落 灰色 灰色 非 耐 落 灰 色 Top (E5128Q) A - 5...

  • Page 48: Bottom

    Bottom Figure A - 4 Bottom A - 6 Bottom...

  • Page 49: Dvd Dual Drive

    DVD Dual Drive Figure A - 5 DVD Dual Drive 非耐落 志精 DVD Dual Drive A - 7...

  • Page 50: Lcd

    Figure A - 6 頭 厚 非 耐 落 頭厚 非耐落 A - 8 LCD...
  • Page 51 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the E5120Q/E5120Q-C/E5125/E5125-C/E5128Q/E5128Q-C notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table B - 1 SCHEMATIC Diagram - Page Diagram - Page Diagram - Page...

  • Page 52: Schematic Diagrams

    Schematic Diagrams System Block Diagram CLICK BOARD Calpella System Block Diagram VDD3,VDD5 6-71-E51Q2-D01A POWER SWITCH BOARD 14.318 MHz POWER SWITCH+HOTKEY X 3 POWER GPU 1.8VS 6-71-E51QS-D01A Clock Generator Memory Termination RTM875N-632-VB-GRT Arrandale AUDIO BOARD 800/1067 MHz 5V,3V,5VS,3VS,1.5VS, USB+EARPHONE+EXT.MIC DDR3 / 1.5V PROCESSOR 6-71-C4508-D02A DDRIII...

  • Page 53: Clock Generator

    Schematic Diagrams Clock Generator CLKGEN POWER CLOCK GENERATOR C L K _ V C C 1 C L K _ V C C 2 3 . 3 V S C L K _ V C C 1 L 1 5 * 15 m i l _ s ho rt _ 0 6 V D D _ D O T V D D _ S R C _ I / O...
  • Page 54 Schematic Diagrams CPU 1/7 (DMI, PEG, FDI) PROCESSOR ( DMI,PEG,FDI ) U 16 A 20 mil B 2 6 P E G_ I R C O MP _ R R 2 0 9 4 9. 9 _ 1 % _0 4 P E G_ I C OM P I A 2 6 P E G _ I C O MP O...

  • Page 55: Cpu 2/7 (Clk, Misc, Jtag

    Schematic Diagrams CPU 2/7 (CLK, MISC, JTAG) PROCESSOR ( CLK,MISC,JTAG ) 1. 5 V Processor Compensation R 2 03 Signals * 1 K _ 1% _ 0 4 R 2 38 4 9 . 9 _1 % _ 0 4 H _ C O MP 0 R 2 0 6 *1 0 m i l _ s h ort _ 0 4...

  • Page 56: Cpu 3/7 (Ddr3

    Schematic Diagrams CPU 3/7 (DDR3) PROCESSOR ( DDR3 ) U16C U 16D AA 6 S A_C K[0] M _CLK _DD R0 10 AA 7 M _A _DQ[63:0] M _CLK _DD R#0 10 M _B _DQ [ 63 : 0] M _CL K_D DR2 11 S A_C K#[0] S B _CK [ 0 ] M _CK E 0 10...

  • Page 57: Cpu 4/7 (Power

    Schematic Diagrams CPU 4/7 (Power) P ROCES SOR ( PO WER ) U 1 6F PRO CESSOR CORE POWER PROCESS OR UNCORE POWER V C O R E 1 . 1 V S _ V TT V TT TOTAL 2 1A A G 3 5 A H 1 4 V C C 1...

  • Page 58: Cpu 5/7 (Graphics Power

    Schematic Diagrams CPU 5/7 (Graphics Power) PROCESSOR 5/7 ( GRAPHICS POWER ) V G F X _ C O R E U 1 6G A T 2 1 A T 1 9 V A X G 1 A R 2 2 V A X G 2 V A X G _ S E N S E GP U V C C S E N S E 3 5...

  • Page 59: Cpu 6/7 (Gnd

    Schematic Diagrams CPU 6/7 (GND) PROCESSOR ( GND ) U1 6H U16 I AT 20 A E3 4 V SS1 VSS81 AT 17 A E3 3 V SS2 VSS82 AR31 A E3 2 K 2 7 V SS3 VSS83 VSS161 AR28 A E3 1 V SS4...
  • Page 60 Schematic Diagrams CPU 7/7 (RESERVED) PROCESSOR ( RESERVED ) 1 . 5 V U 1 6 E AP 2302G N A J1 3 R 3 6 R S V D 3 2 A J1 2 R S V D 3 3 PCI-Expr ess Confi guration S elect * 1 K _ 1% _ 0 4 A P 2 5...
  • Page 61 Schematic Diagrams DDR3 SO-DIMM_0 SO-DIMM A CHANGE TO STANDARD J D I M M2 A M_ A _ A [ 1 5 : 0 ] M_ A _ D Q [ 6 3 : 0] M _A _ A 0 M _A _D Q0 J D I M M2 B D Q 0...
  • Page 62 Schematic Diagrams DDR3 SO-DIMM_1 SO-DIMM B CHANGE TO STANDARD J DI M M1 A M_ B _ A [ 1 5 : 0] M_ B _ D Q[ 6 3 : 0 ] 5 M _B _A 0 M_ B _ D Q 0 J D I M M1 B DQ 0 M _B _A 1...

  • Page 63: Lvds, Inverter

    Schematic Diagrams LVDS, Inverter 3 . 3 V S EDID Mode PANEL CONNECTOR R N 6 2 . 2 K _ 4P 2 R _0 4 V I N V I N _L C D J _ LC D 1 80m ils P _ D D C _ D A T A L 25...

  • Page 64: Hdmi, Crt

    Schematic Diagrams HDMI, CRT L 27 1 _0 4 5 VS For ESD 5V S HDMI PORT R D 2 R D 3 B A V 99 R E C T I F I E R B A V 99 R E C T I FI E R R 210 FOR INTEL GRAPHIC R D 1...

  • Page 65: Ibexpeak

    Schematic Diagrams IBEXPEAK- M 1/9 IBEXPEAK - M (HDA,JTAG,SATA) R T C V C C 6 -2 2- 32 R7 6 -0 B2 2 0m ils R T C _ X 1 6 -2 2- 32 R7 6 -0 BG V D D 3 20m ils C 40 2...
  • Page 66 Schematic Diagrams IBEXPEAK - M 2/9 IBEXPEAK - M (PCI-E,SMBUS,CLK) 3 . 3 V R N 1 6 2 . 2K _ 4P 2R _ 0 4 S MB _C L K S MB _D A T A U 20 B R N 1 1 2 .

  • Page 67: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 3/9 IBEXPEAK - M (DMI,FDI,GPIO) U 2 0 C B A 1 8 F D I _T X N 0 3 B C 24 F D I _ R XN 0 B H 1 7 F D I _T X N 1 3 D MI _ R X N 0 D MI 0 R XN...

  • Page 68: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 4/9 IBEXPEAK - M (LVDS,DDI) U20D T 48 BJ 46 B LON L_B K LT E N S DV O_ T VC LK I N N T 47 BG 46 N B_E N AV DD L_V DD _E N S DV O_T V CLK INP BJ 48...

  • Page 69: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 5/9 IBEXPEAK - M (PCI,USB,NVRAM) U2 0E A D 0 NV_C E#0 A D 1 NV_C E#1 AP15 B o o t B I O S S t r ap A D 2 NV_C E#2 A D 3 NV_C E#3 A D 4...

  • Page 70: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 6/9 IBEXPEAK - M (GPIO,VSS_NCTF,RSVD) U 2 0 F E D P _ C A R D _D E T # A H 4 5 B MB U S Y # / G P I O 0 C LK OU T _ P C I E 6 N 021 3 S_GP IO CHANG E TO ED P_CARD_D ET#...

  • Page 71: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 7/9 IBEXPEAK - M (POWER) 3 . 3 V S R 9 0 H C B 1 6 0 8K F -1 2 1 T2 5 1 . 1 V S _ V T T V C C A _ D A C _ 3.
  • Page 72 Schematic Diagrams IBEXPEAK - M 8/9 Vo lt age R ai l Vol ta ge S0 I ccm ax C urr en t (A ) IBEXPEAK - M (POWER) V_ CP U_I O 1. 1/ 1. 05 < 1 (mA ) V5 RE F <...
  • Page 73 Schematic Diagrams IBEXPEAK - M 9/9 U 2 0 I IBEXPEAK - M (GND) AY 7 H 4 9 V SS [ 1 59 ] VS S[ 2 5 9 ] B1 1 B1 5 V SS [ 1 60 ] VS S[ 2 6 0 ] J 24 V SS [ 1 61 ]...

  • Page 74: New Card, Mini Pcie

    Schematic Diagrams New Card, Mini PCIE 3 . 3 V 3 . 3 V C 45 9 *0 . 1 u_ 1 6 V _Y 5 V _0 4 NEW CARD(Port 8) B U F _ P L T _R S T # U 2 6 *M C 7 4V H C 1 G 08 D F T1 G R 3 36...

  • Page 75: 3G, Ccd, Tpm

    Schematic Diagrams 3G, CCD, TPM MINI CARD 3G(Port 6) 3G POWER G5243A 6-02-05243-9C0 Layo ut Sho w "3.5G(H SD PA ) " N ot e APL3512A 6-02-03512-9C0 3 G_ 3. 3 V 3 . 3V 3 G_ 3 . 3V 3A 1 20mi ls U 12 3A 120m ils...

  • Page 76: Card Reader/Lan Jmb251C

    Schematic Diagrams Card Reader/LAN JMB251C S D _C L K JMC251C 3 . 3 V _ L A N S wi tc hi ng R eg ul at or C 2 7 0 n ear Pin# 41 c lo se t o PI N3 3 D V D D *1 0 p _5 0 V _ N P O _ 06 R 31 7...

  • Page 77: Lan (Jmc251C), Sata Hdd, Odd

    D LM X4 + R 36 6 * 0_ 0 4 D LM X 4- T C T 1 MC T1 E5120Q PJS-08S01B R 28 P 10 1 2 * 0_ 0 4 GST5009 LF 6-21 -B40 10-00 8 4 0 mil...

  • Page 78: Audio Codec Via1812

    Schematic Diagrams Audio Codec VIA1812 CODEC (VIA1812 ) 1 . 5 V R 3 42 * 15 m i l _ s ho rt _ 0 6 C 28 1 C 4 39 5 V S _ A U D 0 .

  • Page 79: Kbc-Ite It8502E

    0 . 1 u_ 1 6 V _Y 5 V _0 4 K B C _ A GN D FOR E4120 FOR E5120Q E C _ V C C K B C _ W R E S E T # 3 .

  • Page 80: Led, Mdc, Bt

    Schematic Diagrams LED, MDC, BT 3 V _ B T Bluetooth(Port8) COSTD OWN J _ B T1 3 . 3V Po rt 1 1 U S B _ P N 1 1 MJ _MDC 1 20 MIL 1. 5 V U S B _ P P 1 1 R 2 92 2 3 , 2 8...

  • Page 81: Usb, Fan, Tp, Multi-Conn

    Schematic Diagrams USB, Fan, TP, Multi-Conn USB PORT*2(Port 0,Port1) FAN CONTROL 5V S _ F A N 5 V S U 1 9 F ON # F O N GN D U S B _ F L G# U S B V C C 0 1 F L G# V O U T 1 V I N...

  • Page 82: 5Vs, 3Vs, 1.5Vs

    Schematic Diagrams 5VS, 3VS, 1.5VS V IN V I N 1 S Y S 5 V S Y S 5 V P C 64 P C 6 3 P C 6 2 0 .1 u_ 5 0 V _ Y 5 V _ 0 6 0 .

  • Page 83: Power 3.3V/5V

    Schematic Diagrams Power 3.3V/5V S Y S 5 V P D 7 P C 1 6 8 B A T 54 S W GH 0 . 0 1 u _ 50 V _ X 7 R _ 0 4 S Y S 5 V C 8 8 L GA T E 1 Z 3 6 1 3...

  • Page 84: Power 1.5V/0.75V, 1.8Vs

    Schematic Diagrams Power 1.5V/0.75V, 1.8VS 3 . 3 V V I N V D D Q P R 8 8 P R 9 4 P R 96 10 0 K _ 1% _ 0 4 P D 4 (1.5V=1.517V) 1 . 5 M_ 0 4 1 0 _0 6 R B 0 54 0 S 2 P U 3...

  • Page 85: Power 1.1Vs_Vtt

    Schematic Diagrams Power 1.1VS_VTT V I N P D 9 P R 99 1.1VS_VTT=0.75 X (1+PR101 / PR102) R B 05 4 0 S 2 6 .4 9K _1 % _ 04 P C 16 4 P Q 3 9 P Q 38 1 5u _ 2 5V _6 .

  • Page 86: Power Vgfx_Core

    Schematic Diagrams Power VGFX_Core 1 .1V S _ V TT P J 4 4 0 mi l P R 71 10 K _0 4 3. 3 V D F GT _V I D _0 D F GT _V I D _1 D F GT _V I D _2 D F GT _V I D _3 D F GT _V I D _4...

  • Page 87: V-Core

    Schematic Diagrams V-Core V I N FOR EMI P C 1 97 *1 n_ 5 0V _ 0 4 S GN D 2 P R2 2 7 *4 7 K _0 4 P C 1 9 8 1 u_ 2 5V _ 0 8 C S _ P H 1 P R 17 3 2 00 K _1 % _0 6...

  • Page 88: Ac_In, Charger

    * B T D -0 5 TI 1 G P R 14 8 P R 1 41 E5120Q V C H G_ S E L 2 8 7 6. 8 K _ 1 % _0 4 P R 2 1...

  • Page 89: Click Board

    6-52-55002-04B 6-20-94AA0-104 6-52-55001-040 6-52-55001-040 6-20-94A70-104 6-21-91A00-106 6-21-91A00-106 6-52-55002-042 6-52-55002-042 6-21-91A10-106 6-21-91A10-106 6-20-94A70-104 6-20-94A70-104 E5120Q CSW1~ 4 LI FT RI GHT LI FT RI GHT KE Y K EY KE Y K EY CS W1 CS W2 CS W3 CS W4...

  • Page 90: Audio Board/Usb

    Schematic Diagrams Audio Board/USB USB PORT A _U S B V C C A L 5 A _ U S B V C C 2 H C B 1 6 0 8K F -12 1 T 25 60 mil A _ U S B V C C A _U S B V C C A U 1 A C 1...

  • Page 91: Power Switch & Led Board

    Schematic Diagrams Power Switch & LED Board POWER SW & LED & HOT KEY S _ 3 .3V S S _3 .3 V POWER LID SWITCH IC SWITCH S D2 S _ 3 .3V S S _ 3 . 3 V S R2 *B A V 99 R E CT IF I E R S _ 3 .3 V...

  • Page 92: External Odd Board

    Schematic Diagrams External ODD Board ODD BOARD FOR E5120Q QJ _ OD D 2 Q J_ O DD 1 QJ _S ATA_ TX P1 QJ _S ATA_ TX N 1 QJ _S ATA_ R X N 1 QJ _S ATA_ R X P1...

  • Page 93: Sequence

    Schematic Diagrams Sequence E 5 1 2 0 Q D 0 2 P O W E R S E Q U E N C E VCCRT C 3 8 . 8 m s V C C R T C R T C R S T # RTCRS T# SPEC DD_ON #...
  • Page 94 Schematic Diagrams B - 44...

  • Page 95: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 96: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
