Rear Panel - TP-Link Archer C3000 User Manual

1 3 2 Rear Panel

The following parts are located on the rear panel (View from left to right). Refer to the following for detailed instructions.
Item
Reset button
USB 2.0 port
Internet port
Ethernet (1, 2, 3, 4) ports These ports (1, 2, 3, 4) connect the router to the local PCs.
USB 3.0 port
Power On/Off button
Power port
Pressing this button for about 7 seconds enables the Reset function.
The USB 2.0 port connects to a USB 2.0 storage device or a USB 2.0 printer.
This port is where you will connect the DSL/cable Modem, or Ethernet.
The USB 3.0 port connects to a USB 3.0 storage device or a USB 3.0 printer.
This button powers on or off the router.
This port is where you will connect the power socket via the provided power adapter.
Description
