1.4.2 The Rear Panel

The following parts are located on the rear panel (View from left to right).
Power socket: The Power socket is where you will connect the power adapter. Please use
LAN 1,2,3,4:
WAN:
Reset button
There are two ways to reset to the router's factory defaults:
1) Use the Factory Defaults function on System Tools -> Factory Defaults page in the
router's Web-based Utility.
2) Use the Factory Default Reset button: Press the Reset button for five seconds and then
wait for the router to reboot.
Wireless antenna: To receive and transmit the wireless data.
MR0-WR941N/MR0-WR941ND
Figure 1-2 Rear Panel sketch
the power adapter provided with this MR0-WR941ND Wireless N Router.
These ports (1, 2, 3, 4) connect the router to the local PC(s)
This WAN port is where you will connect the DSL/cable Modem, or Ethernet
- 5 -
