BACK PANEL
R41 SINGLE RECEIVER
1
R42 DUAL RECEIVER
1
BNC connector for Antenna B.
2
Ground lift switch to help eliminate
ground loops or noise from
other sources.
3
Mic level balanced XLR output for
connecting receiver to an audio mixer.
4
Unbalanced ¼ inch output for
connecting receiver to an amplifier.
2
3
4
5
3
4
2
6
5
6
4
3
1
5
Metal strain relief. Allows power cable
to loop through for added security.
6
DC power jack for external
power supply (12 V).
7
BNC connector for Antenna A.
7
7
