The usage of the detector allows to provide more reliable conclusions
determining originality of inspected samples. Final conclusions on
sample originality are always drawn by people who use the detector
based on their own knowledge of characteristics of original banknotes
and securities.

Declaration of Conformity

The detector conforms to the following requirements:
CU TR 004/2011 «On safety of low-voltage equipment»;
CU TR 020/2011 «Electromagnetic compatibility of technical
equipment».

Specifications

Model
Power supply
Watts consumption
Screen, inches/cm
IR wavelength
UV wavelength
Anti-Stokes wavelength
Operating temperature range
Dimensions (WxDxH), mm
Net mass, kg
DoCash mini
DoCash mini Combo
220 V, 50 Hz
Power supply adapter is
included in the standard list
of equipment
no more than 10 W
LCD 4.3/10.9
850/940 nm
360-380 nm
940 nm
from + 5 °С to + 35 °С
120 x 125 x 165
5
0.42
